D200 Series
High Power 200W reed relay with 7kV isolation
200W switching power
7kV Isolation across contacts
Low Contact Resistance
PCB Mount
Excellent AC characteristics
The D200 series combines a high power
200W switching capacity with isolation of
7kV across the contacts.
This switching performance is achieved
through the use of high vacuum reed
switches with Tungsten contacts and make
these relays suitable for high reliability
applications, such as test equipment and
high voltage power supplies.
These are PCB Mount relays, though
custom options may be available on
request.
Contact Specification Unit
Switch Action
Contact Material
Isolation across contacts kV
Switching Power Max. W
Switching Voltage Max. V
Switching Current Max. A
Carry Current Max
A
Capacitance across
pF
contacts
Lifetime
operations
Contact Resistance
Insulation Resistance
Coil Specification
Must Operate Voltage
Must Release Voltage
Operate Time
Release Time
Resistance
Relay Specification
Condition
SPNO
Tungsten
7
200
2500
3
5
0.8 typ
10
9
10
6
600
(10
13
)
12V
24V
9
1.25
6.0
1.0
150
20
4
6.0
1.0
780
DC or AC peak
resistive
DC or AC peak
DC or AC peak
DC or AC peak
coil to screen
grounded
dry switching
50W switching
mW
max (typical)
W
min (typical)
5V
V DC
V DC
ms
diode fitted
ms
diode fitted
W
3.75
0.5
6.0
1.0
28
Isolation contact/coil
kV
Insulation resistance contact
to all terminals
W
min (typical)
Envirnonmental
Operating Temp range ºC
Standard Parts
DAT200-05
DAT200-12
DAT200-24
17
10
10
(10
13
)
20 to +70
Coil Voltage Vdc
5
12
24
Mechanical Dimensions
60.0
(2.36")
15.8
(0.62")
CIRCUIT DIAGRAM
Cynergy3 Components Ltd.
7 Cobham Road
Ferndown Industrial Estate
Wimborne, Dorset BH21 7PE
Telephone +44 (0) 1202 897969
Email:sales@cynergy3.com
18.5
(0.73")
4.0
(0.15")
4 Pins 0.635(0.025”) Square
5.1
(0.2")
3
10.2
2
1
4
(0.4")
25.4
(1.0")
50.8
(2.0")
FORM A (NO)
1
3
4
2
ISO
9001
C E R T I F I E D
