3261I Series – RF SIGNAL CHOKES
A. Electrical Specifications:
Part
Number
Rev. A
Color Dots
1
2
3
Inductance
(nH) ± 5%
90
100
110
120
130
140
150
165
180
200
220
240
280
310
350
Q
Test Freq.
(Min.)
(MHz)
80
80
80
80
80
80
80
80
80
80
80
70
70
70
70
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR (Ω)
Max.
0.035
0.035
0.035
0.035
0.035
0.045
0.045
0.045
0.045
0.045
0.058
0.058
0.058
0.058
0.058
Rated
Current
(mA)
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
BLK
WHT
BLK
3361I-90NJH
BRN
BLK
BLK
3361I-R10JH
BRN
BRN
BLK
3361I-R11JH
BRN
RED
BLK
3361I-R12JH
BRN
ORG
BLK
3361I-R13JH
BRN
YEL
BLK
3361I-R14JH
BRN
GRN
BLK
3361I-R15JH
BRN
BLU
GRN
3361I-R17JH
BRN
GRY
BLK
3361I-R18JH
RED
BLK
BLK
3361I-R20JH
RED
RED
BLK
3361I-R22JH
RED
YEL
BLK
3361I-R24JH
RED
GRY
BLK
3361I-R28JH
ORG
BRN
BLK
3361I-R31JH
ORG
GRN
BLK
3361I-R35JH
Note: “J”: Tolerance ±5%, H – Internal control code.
B. Dimensions: mm (Inch)
Series
3361I Series
Tol.
a
6.0
(0.236)
±0.5
(0.020)
b
6.0
(0.236)
±0.5
(0.020)
c
9.0
(0.354)
+1.0 (0.039)
-0.5 (0.020)
d
6.5
(0.256)
Max.
e
3.0
(0.118)
+1.0 (0.039)
-0.5 (0.020)
f
0.5
(0.020)
±0.05
(0.002)
g
4.5
(0.177)
±0.5
(0.020)
h
4.5
(0.177)
±0.5
(0.020)
C. General Information:
1.
2.
3.
4.
5.
6.
7.
For high frequency up to 1.0GHz.
High Q up to 150MHz.
Electrical specifications at 25°C.
Temperature stability: 150ppm/°C.
Operating temperature: -30°C to +85°C
Unspecified values and stricter tolerance less than 1% are available upon request.
MSL: Level 1.
D. Applications:
1.
2.
3.
4.
5.
Computers & Game Consoles
Set Top Boxes & Cables Modems
Mobile Communication Devices (Radios, etc.)
LCD, DVD, BRP
For LC filters, CATV diplex filters.
Frontier Electronics Corp.
®
http://www.frontierusa.com
Page
1
of
1
667 E. Cochran St., Simi Valley, CA 93065
Phone: 1-805-522-9998, Fax: 1-805-522-9989
