F-211-1 SUPPLEMENT
ICA–320–SGT
(2,54mm) .100"
ICA SERIES
ICA–624–ZEGG
AUTOMATED INSERTION DIP SOCKETS
Mates with:
APA
ICA
ROW SPACING &
NO. OF CONTACTS
STYLE
OPTION
PLATING
OPTION
(Leave Blank for
Standard Version)
OPTION
Specify from chart below
• Side & end stackable
• Great for auto insertion
• Open body design
(2,54) .100 X No. of Spaces
Row
Spacing
+(2,41)
.095
except
–H is
+ (2,54)
.100
(2,54) .100 X No. of Positions
(2,54)
.100
GG
No. of
Contacts
08
14
16
18
20
22
24
28
22
24
28
32
40
48
= 30µ" (0,76µm)
Gold contact,
10µ" (0,25µm)
Gold Shell
Row
Space
(7,64) .300
(10,16) .400
or
(15,24) .600
*–322
has no cross bar on one end.
(2,54)
.100
–308
–314
–316
–318
–320
.300 (7,62)
–322
*
–324
–328
–422
.400 (10,16)
–624
–628
–632
.600 (15,24)
–640
–648
= .360 (9,14)
Option
Tail
Requires Style
–W or –ZW
Specify desired
= .260 (6,60)
suffix for shorter
Wire-Wrap tail.
Tail
–2
Wire-Wrap
–3
GT
= 30µ" (0,76µm)
Gold contact,
Tin Shell
Requires Style
–S or –ZS
–L
= Locking
Socket
Requires GT
Plating Option
ST
= 10µ" (0,25µm)
Gold contact,
Tin shell (Styles –S
& –ZS only)
SPECIFICATIONS
For complete specifications
see www.samtec.com?ICA
Insulator Material:
Black Glass Filled
Polyester
except -328 is LCP
Contact:
BeCu
Shell:
Brass
Plating:
Au or Sn over 50µ" Ni
Flammability Rating:
UL 94V-O
Insulation Resistance:
5000 MΩ min
Temperature Range:
-55°C to +105°C with Tin
-55°C to +125°C with Gold.
Withstanding Voltage:
1000 VRMS
Current Rating:
1A
Contact Resistance:
10mΩ max
Lead Size Range:
.015" (0,38mm) to .022"
(0,56mm) DIA and most IC leads
Insertion Force:
(Single contact only)
Standard = 9 oz avg, 16 oz max;
Low Insertion Force =
2.5 oz avg, 5.5 oz max
Withdrawal Force:
(Single contact only)
Standard = 2.5 oz avg, 1.5 oz
min; Low Insertion Force =
2.0 oz avg, 0.35 oz min
Lead-Free Solderable:
Wave only
RoHS Compliant:
Yes
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
–S, –ZS, –ZA
= Printed Circuit
-ZS & -ZA = Low Insertion Force
–W, –ZW
= Wire-Wrap
ZW = Low Insertion Force
–ZE
= Elevated
Low Insertion Force
(1,32)
.052
DIA
Y
(4,90)
.193
Z
(12,95)
.510
(1,32)
.052
DIA
(1,32)
.052
DIA
(0,89)
.035
DIA
(13,77)
.542
X
LEAD STYLE
X
DIA
(0,51)
.020
(0,51)
.020
Y
TAIL
(3,18)
.125
(4,57)
.180
Z
(7,62)
.300
(8,89)
.350
–S or –ZS
–ZA
Locking lead
available with –S
and –ZS.
See OPTION.
(0,64)
.025
SQ
(8,86)
.349
(4,32)
.170
Shorter wire-wrap tail
lengths available.
See OPTION.
(3,43)
.136
(0,51)
.020
Insertion Depth = .095" (2,41) to .145" (3,68):
Style S Component Part No. = SC-1P1
Style ZS Component Part No. = EZ-1P1
Style ZA Component Part No. = EZ-6P1
Option L Component Part No. = SC-1L1 or EZ-1L1
–L Option
Insertion Depth = .125" (3,18) to .157" (3,99)
Style W Component Part No. = SC-1W1(1)
Style ZW Component Part No. = EZ-1W1(1)
Style W-2 Component Part No. = SC-1W1(2)
Style ZW-2 Component Part No. = EZ-1W1(2)
Style W-3 Component Part No. = SC-1W1(3)
Style ZW-3 Component Part No. = EZ-1W1(3)
Insertion Depth = .125" (3,18) to .170" (4,32)
Style ZE Component Part No. = EZ-2P3
WWW.SAMTEC.COM
