T212014 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > T212014

Preview

T212014: DescriptionALL DIMENSIONS IN MM [INCH]; File Size158KB，1 Pages; ManufacturerE-Switch; Websitehttp://www.e-switch.com

Download Datasheet View All

T212014 Overview

ALL DIMENSIONS IN MM [INCH]

Preview

Download Datasheet

View All

SHEET 1 OF 1

5.08

[.200 in]

2.54

[.100 in]

1.09

[.043 in]

5.08

[.200 in]

8.13

[.320 in]

P.C. MOUNTING

6.00

SWITCH FUNCTION

POS. 1

POS. 2

POS. 3

[.236 in]

4.39

[.173 in] FLAT

2-3

OFF

OPEN

2-1

POS. 3

5.59

[.220 in]

.51

[.020 in]

4.01

[.158 in]

5.08

[.200 in]

POS. 2

POS. 1

4.93

[.194 in]

[.100 in]

ISOMETRIC

2.54

CIRCUIT: SPDT

NOTE:

1. ALL DIMENSIONS IN MM [INCH]

2. GENERAL TOLERANCE: X.X=±0.4

X.XX=±0.25

3. TERMINAL NUMBERS FOR REF ONLY

4. PLATING MATERIAL: GOLD

5. RATING: 0.4VA MAX. @20V MAX. AC OR DC

6. ELECTRIC LIFE: 30,000 MAKE-AND-BREAK CYCLES

AT FULL LOAD.

7. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.

8. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.

9. OPERATING TEMP.: -30°C to 85°C

10.

DENOTES CRITICAL PARAMETER.

.51

[.020 in]

2.54

[.100 in]

.76

[.030 in]

3.30

[.130 in]

5.08

[.200 in]

REV

14830

PCR NO

REVISED AND REDRAWN

DESCRIPTION

4/8/05

DATE

TITLE

SCALE

200MSP3T2B2M7RE

2:1

DATE

DWG

REV

THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY

TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED

10/7/96

T212014
