SHEET 1 OF 1
n
11.81
[.465 in]
12.70
[.500 in]
6.86
[.270 in]
5.95
[.234 in]
n
6.35
[.250 in]
PANEL MOUNTING
POS. 1
4.70
[.185 in]
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
n
1.85
5.72 FLAT
[.225 in]
n
3.30
[.130 in]
POS. 3
25
~
[.073 in]
PCB MOUNTING
2
21.34 MAX
[.840 in]
ON
2-3
NONE
N/A
() = MONENTARY
ON
2-1
1
3
1/4-40 UNS - 2A
7.52
[.296 in]
CIRCUIT: SPDT
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. PLATING MATERIAL: SILVER
5. RATING: 5A @ 120VAC OR 28VDC
2A @ 250VAC
6. ELECTRIC LIFE: 40,000 CYCLES
7. INSULATION RESISTANCE: 1,000 M
MIN
.
8. DIELECTRIC STRENGTH: 1,000 V RMS.
9. OPERATING TEMP.: -30°C to 85°C
10. DENOTES CRITICAL PARAMETER.
11. 2002/95/EC (ROHS) COMPLIANT
E-SWITCH
MARKING
.51
[.020 in]
1
2
3
1.44
[.057 in]
8.89
[.350 in]
3
18.70
[.736 in]
.76
[.030 in]
4.70
[.185 in]
1.27
[.050 in]
A
REV
21343
PCR NO
RELEASED FOR PRODUCTION
DESCRIPTION
1/8/13
DATE
EBP
BY
TITLE
100SP1T5B9M51QE
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
SCALE
1/8/2014
EBP
T115047
