SHEET 1 OF 1
4.70
[.185 in]
12.70
[.500 in]
1.02
[.040 in]
16.51
[.650 in]
[.073 in]
n
1.85
4.83
[.190 in]
P.C. MOUNTING
KEYWAY
.41
[.016 in]
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
2.92
ON
2-3, 5-6,
8-9
NONE
OPEN
(ON)
2-1, 5-4,
8-7
n
[.115 in]
ISOMETRIC
9.91
[.390 in]
1/4-40NS THD.
8.00
[.315 in]
(ON) = MOMENTARY
2
5
8
1
3
4
6
7
9
ON
OFF
ON
CIRCUI: 3PDT
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. PLATING MATERIAL: SILVER
5. RATING: 2 AMPS @ 250VAC;
5 AMPS @120VAC OR 28VDC
6. ELECTRIC LIFE: 40,000 make-and-break cycles
at full load.
7. INSULATION RESISTANCE: 1,000 Mega-ohm min.
8. DIELECTRIC STRENGTH: 1,000 V RMS @sea level.
9. OPERATING TEMP.: -30°C to 85°C
10.
DENOTES CRITICAL PARAMETER.
E-SWITCH
MARKING ON
OPPOSITE SIDE
1.02
[.040 in]
10.54
[.415 in]
.51
[.020 in]
1
2
3
6.35
[.250 in]
3
6
9
1.27
[.050 in] TYP.
.76
[.030 in] TYP.
4.70
[.185 in] TYP.
4.83
[.190 in] TYP.
A
REV
14196
PCR NO
RELEASED FOR PRODUCTION
DESCRIPTION
7/28/04
DATE
AR
BY
TITLE
SCALE
1003P2T1B6M2QE
2:1
DATE
DR
DWG
REV
