SHEET 1 OF 1
6.10
[.240 in]
n
6.35
[.250 in]
n
6.35
[.250 in]
.55
[.022 in]
12.70
[.500 in]
n
2.38
.85
[.033 in]
WITHOUT LOCKING RING
[.094 in]
WITH STANDARD LOCKING RING
6.86
[.270 in]
n
[.129 in]
3.27
PANEL MOUNTING
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
POS. 1
25
~
16.26
[.640 in]
ON
2-3
OFF
OPEN
2
ON
2-1
THREAD:
1/4-40 UNS-2A
POS. 2
POS. 3
ISOMETRIC
8.90
[.350 in]
1
3
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. CONTACT MATERIAL: SILVER
5. RATING: 5A @120VAC OR 28VDC
2A @250VAC
6. ELECTRIC LIFE: 40,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.
8. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.
9. OPERATING TEMP.: -30°C to 85°C
10. DENOTES CRITICAL PARAMETER.
11. 2002/95/EC (ROHS) COMPLIANT
12. HARDWARE TO BE SHIPPED BULK:
T100011 - LOCK WASHER, QTY 1
T100015 - LOCK RING, QTY 1
T100000 - HEX NUT, QTY 2
A
REV
17695
PCR NO
RELEASED FOR PRODUCTION
DESCRIPTION
9/19/07
DATE
CIRCUI: SPDT
E-SWITCH
MARKING ON
OPPOSITE SIDE
8.89
[.350 in]
1.98
[.078 in]
EPOXY SEAL
.76
[.030 in]
4.70
[.185 in]TYP.
1
2
3
3.96
[.156 in]
1.19
[.047 in]
2.03
[.080 in]
3
3.96
[.156 in]
BF
BY
TITLE
100SP3T4B1M1QEH
2:1
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
SCALE
9/19/2007
BF
ST113043
A
