SHEET 1 OF 1
4.70
[.185 in]
n
1.85
[.073 in]
12.70
[.500 in]
4.83
[.190 in]
PCB LAYOUT
11.43
[.450 in]
POS. 3
SWITCH FUNCTION
POS. 1
POS. 2
KEYWAY
2.92
n
[.115 in]
ON
2-3, 5-6
NONE
N/A
ON
2-1, 5-4
POS. 1
25
~
POS. 2
POS. 3
ISOMETRIC
10.55
[.415 in]
2
5
1/4-40 UNS-2A
THREADS
1
3
4
6
8.80
[.346 in]
NOTE:
1. ALL DIMENSIONS IN MM [INCH].
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY.
4. PLATING MATERIAL: GOLD
5. RATING: 0.4 VOLT-AMPS(VA) MAX. @20V MAX.
(AC OR DC)
6. ELECTRIC LIFE: 30,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.
8. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.
9. OPERATING TEMP.: -30°C to 85°C
10. 2002/95/EC (ROHS) COMPLIANT.
11.
DENOTES CRITICAL PARAMETER.
12. HARDWARE TO BE SHIPPED BULK:
T100011 - LOCK WASHER, QTY 1
T100015 - LOCK RING, QTY 1
T100000 - HEX NUT, QTY 2
A
REV
16142
PCR NO
RELEASED FOR PRODUCTION
DESCRIPTION
CIRCUIT: DPDT
100AWDP1T1B1M2RE
(T102274)
.76
[.030 in]
10.40
[.409 in]
5.30
[.209 in]
1
2
3
.76
[.030 in]
3
1.27
[.050 in]
4.83
[.190 in]
EPOXY SEAL
4.70
[.185 in]
6/14/06
DATE
CT
BY
TITLE
SCALE
100AWDP1T1B1M2REH
2:1
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
6/14/2006
CT
ST102274
A
