28,95
8,95
Ansaughaube
6,75
4,6
Verpackt im Gurt nach DIN IEC 60286-3
Tape on Reel Packaging according to DIN IEC 60286-3
Packaging unit: 400 pcs
1,62
Verpackungseinheit: 400 Stück
hood
8,62
5,8
1,2
7,42
2,9
26
0,65
0,5
0,6
0,15
0,8
4,125
330
Abspulrichtung -
Reel off Direction
a1
16
b25
27,55
b1
4,475
2,25
a25
1
24 x 1 = 24
25,45
a1
1,5
Leiterplatten-Layout Vorschlag /
PCB-layout proposal
26
±0,03
1
3
1)
0,9
±0,03
Anforderungsstufe 1
Performance Level 1
Kontaktbereich vergoldet
1)
8 x 3 = 24
0,6
±0,05
0,7
Mating Area gold plating
±0,03
Anschlussbereich verzinnt 4-6 µm
Terminal Area 4-6 µm tin plating
4,5
1,5
Koplanarität der Anschlüsse
≤
0,1 mm
Coplanarity Area of Termination
≤
0,1 mm
Copyright by ERNI GmbH
Proprietary notice pursuant to ISO 16016 to be observed.
0,7
56
Information:
Tolerances
All Dimensions
in mm
Scale
5:1
1
1
0,5
24 x 1 = 24
All rights reserved.
Only for Information.
To ensure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
f
Index
28.01.2014
Date
Designation
Subject to modification without
prior notice.
Drawing will not be updated.
M02 MSpeed Blind Mate 50 THR
1) Durchmesser des Bohrers /
drill tool
www.ERNI.com
Class
354184
MSPEED
I
A3
