ERA-3SM-TR+ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wireless rf/communication> Radio frequency and microwave> ERA-3SM-TR+

ERA-3SM-TR+: DescriptionWide Band Low Power Amplifier, 0MHz Min, 3000MHz Max,; CategoryWireless rf/communication Radio frequency and microwave; File Size149KB，2 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com; Environmental Compliance

Download Datasheet Parametric Compare View All

ERA-3SM-TR+ Overview

Wide Band Low Power Amplifier, 0MHz Min, 3000MHz Max,

ERA-3SM-TR+ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Mini-Circuits
Reach Compliance Code	unknown
Characteristic impedance	50 Ω
structure	COMPONENT
Maximum input power (CW)	13 dBm
Maximum operating frequency	3000 MHz
Minimum operating frequency
Maximum operating temperature	85 °C
Minimum operating temperature	-25 °C
RF/Microwave Device Types	WIDE BAND LOW POWER
Maximum voltage standing wave ratio	1.9

Preview

Download Datasheet

View All

ERA-3SM-TR+ Related Products

	ERA-3SM-TR+	ERA-4SM-TR+	ERA-4SM-TR	A3BT-502R	ERA-2SM-TR	ERA-1SM-TR+	ERA-1SM-TR	ERA-3SM-TR	ERA-5SM-TR	ERA-5SM-TR+
Description	Wide Band Low Power Amplifier, 0MHz Min, 3000MHz Max,	Wide Band Low Power Amplifier, 0MHz Min, 4000MHz Max,	Wide Band Low Power Amplifier, 0MHz Min, 4000MHz Max,	Lighted and non-lighted/convex versions	Wide Band Low Power Amplifier, 0MHz Min, 6000MHz Max,	Wide Band Low Power Amplifier, 0MHz Min, 8000MHz Max,	Wide Band Low Power Amplifier, 0MHz Min, 8000MHz Max,	Wide Band Low Power Amplifier, 0MHz Min, 3000MHz Max,	Wide Band Low Power Amplifier, 0MHz Min, 4000MHz Max,	Wide Band Low Power Amplifier, 0MHz Min, 4000MHz Max,
Is it Rohs certified?	conform to	conform to	incompatible	-	incompatible	conform to	incompatible	incompatible	incompatible	conform to
Maker	Mini-Circuits	-	-	-	Mini-Circuits	Mini-Circuits	Mini-Circuits	Mini-Circuits	Mini-Circuits	Mini-Circuits
Reach Compliance Code	unknown	unknown	unknown	-	unknown	unknown	unknown	unknown	unknown	unknown
Characteristic impedance	50 Ω	50 Ω	50 Ω	-	50 Ω	50 Ω	50 Ω	50 Ω	50 Ω	50 Ω
structure	COMPONENT	COMPONENT	COMPONENT	-	COMPONENT	COMPONENT	COMPONENT	COMPONENT	COMPONENT	COMPONENT
Maximum input power (CW)	13 dBm	13 dBm	13 dBm	-	15 dBm	15 dBm	15 dBm	13 dBm	13 dBm	13 dBm
Maximum operating frequency	3000 MHz	4000 MHz	4000 MHz	-	6000 MHz	8000 MHz	8000 MHz	3000 MHz	4000 MHz	4000 MHz
Maximum operating temperature	85 °C	85 °C	85 °C	-	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-25 °C	-25 °C	-25 °C	-	-25 °C	-25 °C	-25 °C	-25 °C	-25 °C	-25 °C
RF/Microwave Device Types	WIDE BAND LOW POWER	WIDE BAND LOW POWER	WIDE BAND LOW POWER	-	WIDE BAND LOW POWER	WIDE BAND LOW POWER	WIDE BAND LOW POWER	WIDE BAND LOW POWER	WIDE BAND LOW POWER	WIDE BAND LOW POWER
Maximum voltage standing wave ratio	1.9	1.3	1.3	-	1.9	2.2	2.2	1.9	1.2	1.2
