SHEET 1 OF 1
19.56
[.770 in]
17.53
[.690 in]
2
5
6.10
[.240 in]
1
3 4
CIRCUIT: DPDT
6
6.10
[.240 in]
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
3.86
[.152 in]
ON
2-1, 5-4
NONE
N/A
ON
2-3, 5-6
1.52
[.060 in]
3.96
[.156 in]
3.56
[.140 in]
4
4.70
[.185 in]
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. PLATING MATERIAL: SILVER
5. CONTACT RATING: 5A@120VAC OR 28VDC
2A@250VAC
6. TRAVEL:2.16mm
7. ELECTRIC LIFE: 30,000 ACTUATIONS AT FULL LOAD.
8. CONTACT RESISTANCE: 10 milli-OHMS TYP.
9. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.
10. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.
11. OPERATING TEMP.: -30°C to 85°C
12.
DENOTES CRITICAL PARAMETER.
13. 2002/95/EC (ROHS) COMPLIANT
5
6
7.62
[.300 in]
6
3
.76
[.030 in]
12.70
[.500 in]
4.83
[.190 in]
2.03
[.080 in]
4
5
6
11.43
[.450 in]
1
2
3
B
REV
19570
PCR NO
DRAWING UPDATE / CLEAN-UP
DESCRIPTION
1/7/11
DATE
BGL
BY
TITLE
500SDP1S4M1QEB
2:1
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
SCALE
1/7/2011
BGL
T521020
B
