SHEET 1 OF 1
(X)
SWITCH FUNCTION
POS. 1
13.00
[.512 in]
OFF
OPEN
PANEL CUTOUT
PANEL THICKNESS
0.75 - 1.25
1.25 - 2.00
2.00 - 3.00
X
19.2
19.4
19.6
POS. 2
21.00
[.827 in]
ON
1-1a, 2-2a
15.00
[.591 in]
WHITE MARKING
FULL ILLUMINATED
BLUE ACTUATOR
5.70
`
.50
[.224
`
.020
in]
POS. 2
POS. 1
BLACK BODY
10.50
[.413 in]
1
L
2
1a
2a
CIRCUIT: DPST
NOTE:
2.00
1. DIMENSIONS IN MM [INCH]
[.079 in]
2. GENERAL TOLERANCE: X.X =
±
0.4
X.XX =
±
0.25
3. TERMINAL NUMBERS FOR REF ONLY
22.60
`
.50
4. CONTACT MATERIAL: SILVER
[.890
`
.020
in]
5. CONTACT RATINGS: 16A @ 125VAC [UR, cUR]
10A @ 250VAC [UR, cUR]
1/3HP 125/250VAC [UR, cUR]
6. CONTACT RESISTANCE: 35mΩ MAX. @ 50VAC
7. INSULATION RESISTANCE: 100MΩ MIN. @ 500VAC
8. DIELECTRIC STRENGTH: 1,500VAC FOR 1 MINUTE
9. ELECTRICAL LIFE: 6,000 CYCLES [UR, cUR]
10,000 CYCLES [ENEC14, SEMKO: 10(4)a 250v~]
4.70
50,000 CYCLES [ENEC14, SEMKO: 10(2)a 250v~]
[.185 in]
10. OPERATING TEMPERATURE: -20°C TO 105°C [UR, cUR]
-20°C TO 125°C [ENEC14, SEMKO: 10(4)a 250v~]
-20°C TO 85°C [ENEC14, SEMKO: 10(2)a 250v~]
11. DENOTES CRITICAL PARAMETER
12. 2002/95/EC (ROHS) COMPLIANT
13. LAMP VOLTAGE: 250V
14.40
[.567 in]
n
1.60
[.063 in]
1
1a
.80
[.031 in]
8.00
[.315 in]
1
1a 2a
2
5.00
[.197 in]
9.10
[.358 in]
18.70
[.736 in]
12.50
[.492 in]
12.90
[.508 in]
A
REV
20868
PCR NO
RELEASE FOR PRODUCTION
DESCRIPTION
11/7/12
DATE
EBP
BY
TITLE
RA812C102R-147
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
SCALE
11/7/2012
EBP
38-RA812C102R147
A
