T314034: DescriptionALL DIMENSIONS IN MM [INCH]; File Size235KB，1 Pages; ManufacturerE-Switch; Websitehttp://www.e-switch.com

Download Datasheet View All

T314034 Overview

ALL DIMENSIONS IN MM [INCH]

Preview

Download Datasheet

View All

SHEET 1 OF 1

4.70

[.185 in]

1.85

TYP.

[.073 in]

4.83

[.190 in]

3.18

[.125 in]

31.50

[1.240 in]

P.C. MOUNTING

SWITCH FUNCTION

POS. 1

POS. 2

POS. 3

13.48

[.531 in]

POS. 1

POS. 2

POS. 3

9.27

[.365 in]

(ON)

2-3

OFF

OPEN

(ON)

2-1

ISOMETRIC

7.59

[.299 in]

(ON) = MOMENTARY

7.87

[.310

in]

11.68

[.460 in]

4.11

[.162 in]

E-SWITCH

MARKING ON

OPPOSITE SIDE

EPOXY SEAL

.51

[.020 in]

1.27

[.050 in]

6.35

[.250 in]

9.14

[.360 in]

4.70

[.185 in]

CIRCUI: DPDT

NOTE:

1. ALL DIMENSIONS IN MM [INCH]

2. GENERAL TOLERANCE: X.X=±0.4

X.XX=±0.25

3. TERMINAL NUMBERS FOR REF ONLY

4. PLATING MATERIAL: SILVER

5. RATING: 2 AMPS @250VAC

5 AMPS @120VAC OR 28VDC

6. ELECTRIC LIFE: 50,000 MAKE-AND-BREAK CYCLES

AT FULL LOAD.

7. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.

8. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.

9. OPERATING TEMP.: -30°C to 85°C

10.

DENOTES CRITICAL PARAMETER.

.76

[.030 in] TYP.

4.70

[.185 in]

19.05

[.750 in]

REV

14573

PCR NO

RELEASED FOR PRODUCTION

DESCRIPTION

12/13/04

DATE

TITLE

SCALE

300SP4J1BLKVS4QE

2:1

DATE

DWG

REV

THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY

TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED

12/13/04

T314034
