SHEET 1 OF 1
1.27
[.050 in]
8.40
[.331 in]
8.50
[.335 in]
2.54
[.100 in]
14.20
[.559 in]
L2
L1
2.50
[.098 in]
3.70
[.146 in]
2.55
[.100 in]
BLACK
BUTTON
6
5
4
5.00
[.197 in]
5.40
[.213 in]
CLEAR
LED
WINDOW
3
2
1
[.031 in]
2.65
[.104 in]
n
.80
B
P.C.B. LAYOUT
1
2
3
21.45
[.844 in]
3.40
B
8.50
[.335 in] [.134 in]
PUSH
4
L2
.50
[.020 in]
3.70
[.146 in]
2.54
[.100 in]
1.27
B
[.050 in]
6
L2
L1
5
4
3
2
1
6.40
(
[.252 in]
)
6
3
5
6
BLUE
+ L1 LED
L2 -
CIRCUIT DIAGRAM
.40
[.016 in]
2.70
[.106 in]
5.40
[.213 in]
2.50
[.098 in]
B
LED SPECS
11.80
[.465 in]
5.00
[.197 in]
FORWARD CURRENT
FORWARD VOLTAGE
LUMINOUS INTENSITY
UNITS
mA
V
MCD
BLUE
20
3.5-4.0
1,500
NOTES:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=
`
0.4
X.XX=
`
0.25
3. TERMINAL NUMBERS FOR REF. ONLY
4. CONTACT RATING: 0.1A @ 30VDC
5. TRAVEL: FULL = 2.5
`
0.3; LOCK = 1.5
`
0.3mm'S
6. OPERATING FORCE: 250
`
100gf
7. ELECTRICAL LIFE: 10,000 CYCLES
8. DENOTES CRITICAL PARAMETER
9. CONTACT MATERIAL: SILVER
10. CONTACT RESISTANCE: 50m OHM MAX.
11. OPERATING TEMPERATURE: -20c TO +70c
12. INSULATION RESISTANCE: 100M OHMS MIN.
13. LED COLOR: BLUE
14. 2002/95/EC (RoHS) COMPLIANT AND HALOGEN FREE
12/30/10
1/20/10
DATE
BGL
rc
BY
B
19554
DIM CHANGES & UPDATE
A
18806
New-Release
TITLE
SCALE
TL2205EEBPBB
2:1
DATE
REV
PCR NO
DESCRIPTION
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
1/20/2010
DR
rc
DWG
B401012
REV
B
