Thin Film Chip Resistors
RB series Standard
(Halogen –Free)
5. Ratings & Characteristics
Type
Power
Rating
at 70℃
Rated
Voltage
Max.
Working
Voltage
Max.
Over- Load
Voltage
T.C.R
(PPM/℃)
Document No
Issued date
page
TRB-XX0S031M
2013/01/17
3/13
Resistance Range
Resistance
tolerance(%)
RB04
1/16 W
Refer 5.2
50V
100V
±5
±10
±25
±50
±100
± 25
±50
±100
±5
±10
±25
±50
±100
± 25
± 50
±100
±5
±10
±25
±50
±100
± 25
± 50
±100
±5
±10
±25
±50
±100
10Ω~100KΩ
± 0.1~ ±1.0
RB06
1/10 W
Refer 5.2
75V
150V
1~9.1Ω
± 0.5~ ±1.0
RB06
1/10W
Refer 5.2
75V
150V
10Ω~390KΩ
± 0.1~ ±1.0
RB10
1/8 W
Refer 5.2
150V
300V
1~9.1Ω
± 0.5~ ±1.0
RB10
1/8 W
Refer 5.2
150V
300V
10Ω~800KΩ
± 0.1~ ±1.0
RB12
1/4 W
Refer 5.2
150V
300V
1~9.1Ω
± 0.5~ ±1.0
RB12
1/4 W
Refer 5.2
150V
300V
10Ω~1MΩ
± 0.1~ ±1.0
Operating Temp(℃): -55℃ ~ +155℃
Note : Except for the above standardized products, we also provide the
customized products.
TA-I TECHNOLOGY CO., LTD
Thin Film Chip Resistors
RB series Standard
(Halogen –Free)
6. Reliability Tests:
Test Items
Temperature Coefficient of
Resistance
Rapid Change of Temp.
Short Time Overload
Resistance to Dry Heat
Load Life
Resistance to Solder Heat
Bending
Dielectric
Withstanding
Voltage (Voltage Proof)
Reference
standard
Condition of Test
Document No
Issued date
page
TRB-XX0S031M
2013/01/17
5/13
Test Limits
IEC60115-1-4.8
+25 ~ +125
℃
Refer 5.0
JIS C5201-1-4.8
IEC60115-1-4.19 -55℃(30 min. ) / +155℃(30 min. ),
±(0.5%+0.05Ω)
JIS C 5201-1-4.19 300 cycles
IEC60115-1-4.13
2.5 X rated voltage for 5sec
JIS C5201-1-4.13
IEC60115-1-4.23.2
155±5℃ for 96±4Hrs
JIS C5201-1-4.23.2
±(0.5% + 0.05Ω)
±(0.5% +0.05Ω)
IEC60115-1-4.25.1 1000 hours at rated power , 70℃ ,
±(0.5% +0.05Ω)
1.5hours“ON “, 0.5hour “OFF”
JIS C5201-1-4.25.1
0.1%:±(0.25% +0.05Ω)
IEC60115-1-4.18
260 ±5℃ solder , 10 ±1 sec dwell .
0.5%.1%:±(0.5% +0.05Ω)
JIS C5201-1-4.18
IEC60115-1-4.33
3mm deflection
JIS C5201-1-4.33
IEC60115-1-4.7
JIS C5201-1-4.7
Applying voltage :
0402 & 0603 : 300V
500V for a minute .
The other
±(0.5% +0.05Ω)
No abnormalities such as
flashover,
burning
dielectric breakdown shall
appear.
1000 hours 85°C/85%RH. Note:
Specified conditions: 10% of
Load Life with Humidity
IEC60115-1-4.24 operating power(not exceeding max
±(0.5% +0.05Ω)
JIS C5201-1-4.24 working voltage). Measurement at
24±2 hours after test conclusion.
(MSL: Level 1)
Insulation Resistance
IEC60115-1-4.6
JIS C5201-1-4.6
Applying voltage 100V for 1 minute.
≧1GΩ
At least 95% of surface
area of electrode shall be
covered with new solder.
Solderability
IEC60115-1-4.17 245 ±5℃ solder, 2 ±0.5 sec dwell.
Solder : Sn96.5 / Ag3.0 / Cu0.5
JIS C5201-1-4.17
Note* :RCWV : Rated continuous working voltage .
MSL : Moisture Sensitivity Level .
TA-I TECHNOLOGY CO., LTD
