PTDA 2,5/ 5-5,0 GNYE/BN/BU - 1704078
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
PCB terminal block, nominal current: 24 A, pitch: 5 mm, number of positions: 5, connection method: Push-in
spring connection, mounting: Wave soldering, conductor/PCB connection direction: 45 °, color: multi-color
Key Commercial Data
Packing unit
GTIN
GTIN
Custom tariff number
4046356672740
85369010
1
Technical data
Dimensions
Length [ l ]
Pitch
Dimension a
Width [ w ]
Height
Height [ h ]
Solder pin [P]
Pin spacing
Hole diameter
16 mm
5 mm
20 mm
26.4 mm
16 mm
19.5 mm
3.5 mm
5 mm
1.3 mm
General
Range of articles
Rated surge voltage (III/3)
Rated surge voltage (III/2)
Rated surge voltage (II/2)
Rated voltage (III/3)
Rated voltage (III/2)
Rated voltage (II/2)
Connection in acc. with standard
Nominal current I
N
Nominal cross section
Stripping length
PTDA 2,5/
4 kV
4 kV
4 kV
320 V
400 V
630 V
EN-VDE
24 A
2.5 mm²
10 mm
12/30/2018 Page 1 / 4
https://www.phoenixcontact.com/in/products/1704078
PTDA 2,5/ 5-5,0 GNYE/BN/BU - 1704078
Technical data
General
Number of positions
5
Connection data
Conductor cross section AWG min.
Conductor cross section AWG max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded min.
2 conductors with same cross section, stranded max.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, max.
24
14
0.2 mm²
2.5 mm²
0.2 mm²
2.5 mm²
0.5 mm²
2.5 mm²
0.5 mm²
1 mm²
Standards and Regulations
Connection in acc. with standard
EN-VDE
CUL
Environmental Product Compliance
China RoHS
Environmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
Classifications
eCl@ss
eCl@ss 4.0
eCl@ss 4.1
eCl@ss 5.0
eCl@ss 5.1
eCl@ss 6.0
eCl@ss 7.0
eCl@ss 8.0
eCl@ss 9.0
27141111
27141109
27141190
27261100
27261100
27440401
27440401
27440401
ETIM
ETIM 3.0
ETIM 4.0
ETIM 5.0
ETIM 6.0
EC001121
EC002637
EC002643
EC002643
12/30/2018 Page 2 / 4
https://www.phoenixcontact.com/in/products/1704078
PTDA 2,5/ 5-5,0 GNYE/BN/BU - 1704078
Classifications
UNSPSC
UNSPSC 6.01
UNSPSC 7.0901
UNSPSC 11
UNSPSC 12.01
UNSPSC 13.2
30211801
39121432
39121432
39121432
39121432
Approvals
Approvals
Approvals
CCA / IECEE CB Scheme / VDE Gutachten mit Fertigungsüberwachung / EAC / cULus Recognized
Ex Approvals
Approval details
CCA
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
250 V
24 A
0.2-2.5
DE1 34029
IECEE CB Scheme
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
http://www.iecee.org/
DE1-46805
250 V
24 A
0.2-2.5
VDE Gutachten mit
Fertigungsüberwachung
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
http://www2.vde.com/de/Institut/Online-Service/
VDE-gepruefteProdukte/Seiten/Online-Suche.aspx
250 V
24 A
0.2-2.5
40030462
12/30/2018 Page 3 / 4
https://www.phoenixcontact.com/in/products/1704078
PTDA 2,5/ 5-5,0 GNYE/BN/BU - 1704078
Approvals
EAC
D
300 V
10 A
24-14
B.01742
cULus Recognized
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm E60425-20030211
B
300 V
15 A
24-14
Phoenix Contact 2018 © - all rights reserved
