PKJ 4113A PIT/PKJ4113 PIT/PKJ 4713 PIT
Advanced Data Sheet
75-150W DC/ DC Power Modules
48 V Input; 12V @ 6.3-12.5A Output
• High Efficiency 93% Typ at full load
• Fast Dynamic Response, 100us,
+/- 150 mVpeak Typ
• Heatsinks available as an option for extended
operation
• MTBF > 3 million hours in accordance with
Bellcore TR-332
• High power density, up to 55 W/in
3
• Wide input voltage range (34-75V) according
to ETSI Specifications
• Industry standard footprint & pin-out
• 1,500 Vdc isolation voltage
• Max case temperature +100
o
C
• Demonstrated compliance with isolation
requirements equivalent to Basic Insulation
per UL 60950
• UL 1950/UL
C
1950 Recognized
• TUV to EN60 950 Type Approved
The PKJ series represents a "third generation" of
High Density DC/DC Power Modules providing
greater than 90% efficiency. Ericsson uses propri-
etary drive and control circuits with planar magnet-
ics and low resistivity multilayer PCB technology,
and advanced patented topology with active syn-
chronous rectification in an industry standard half
brick package with unparalleled performance.
The product features fast dynamic response times
and low output ripple, which are important param-
eters when supplying high quality DC power to
low voltage logics and Wireless applications. The
PKJ converter's excellent high efficiency and ad-
vanced design are well suited for limited board
space and high dynamic load applications.
Ericsson's PKJ Power Modules address the converg
ing "New Telecoms" market by specifying the input
voltage range in accordance with ETSI specifica-
tions. The PKJ series also offers the flexibility of
using an optional heatsink when needed, enabling
reduced airflow, extended reliability or higher ambi-
ent temperature operation. Included in the PKJ
series are over-voltage protection, under voltage
protection, over temperature protection, soft-start,
and short circuit protection.
These modules are manufactured using highly auto-
mated manufacturing lines with a world-class quali-
ty commitment which is reflected in our standard
five year warranty. Ericsson Inc., Microelectronics
has been an ISO 9001 certified supplier since 1991.
For a complete product program please reference the back
cover.
E
PKJ 4113A PIT/PKJ 4113 PIT/PKJ 4713 PIT
General
Pin
1
2
3
4
5
6
7
8
9
Connections
Designation
-
IN
CASE
RC
+
IN
-
OUT
- SEN
TRIM
+ SEN
+ OUT
Function
Negative Input
Connected to baseplate
Remote Control to turn on and off
the output
Positive Input
Negative Output
Negative Remote Sense
Output Voltage Adjust
Positive Remote Sense
Positive Output
Input
T
C
< T
C max
Characteristics
V
I
V
Ioff
V
Ion
C
I
I
Iac
I
I max
Input voltage range
1)
Turn-off input voltage Ramping from higher
voltage
Turn-on input voltage
Input capacitance
Reflected ripple
current
Maximum input
current
5 Hz to 20 MHz
V
I
= 36V
PKJ 4113A PIT
PKJ 4113 PIT
PKJ 4713 PIT
I
O
=0, V
I
= 53 V
V
I
=53 V, RC open
2.5
0.05
Ramping from lower
voltage
Conditions
min
34
31
33
34
2.8
20
36
typ
max
75
Unit
Vdc
Vdc
Vdc
µF
mA
p-p
Weight
Maximum 85 g
4.93
3.27
2.46
7.5
2.5
A
A
A
W
W
Case
Aluminum baseplate with metal standoffs.
P
Ii
P
RC
Input idling power
Input stand-by
power
(turned off with RC)
Maximum input
voltage on trim pin
Pins
Pin material: Brass
Pin plating: Tin/Lead over Nickel.
Trim
6.0
Vdc
Note:
1) The input voltage range 34...75 V meets the requirements in the European
Telecom Standard prETS 300 132-2 for Normal input voltage range in 48 V and
60 V DC power systems, – 40.5...–57.0 V and –50.0...–72.0 V respectively.
Mechanical Data
2.40
[61,0]
OVERALL
WIDTH
0.20
[5,1]
0.300
[7,62]
- IN
-OUTPUT
2.28
[57,9] OVERALL LENGTH
1.900
[48,26]
0.21
[5,3]
PIN
EXT.
0.50
[12,7]
OVERALL
HEIGHT
0.50
[12,72]
0.400
[10,16]
-SENSE
CASE
0.400
[10,16]
0.700
[17,78]
2.00
[50,8]
0.600
[15,24]
RC
BOTTOM VIEW
TRIM
1.000
[25,40]
+SENSE
0.400
[10,16]
+ IN
+OUTPUT
1.400
[35,56]
0.040 [1,02] DIA. PLATED
BRASS PINS
TYPICAL 7 PLACES
Standoff
0.02
[0.5]
M3 X [0,5] MOUNTING INSERTS
TYPICAL 4 PLACES
MAX. SCREW TORQUE: 3.9 IN-LBS.[0,44 N-M]
0.19
[4,82]
Dimensions: inches [mm]
Tolerances: .xx ± 0.02 [ ,x ± ,5]
.xxx ±0.010 [,xx ± ,25]
0.080 [2,06] DIA. PLATED
BRASS PINS
TYPICAL 4 PLACES
2
EN/LZT 108 3486 R2B © Ericsson Inc., Microelectronics, December 2001
PKJ 4113A PIT/PKJ 4113 PIT/PKJ 4713 PIT
Output
T
C
= –40…+100°C, V
I
= 36...75V unless otherwise specified.
Characteristics
Output voltage initial
setting and accuracy
Output adjust range
V
O
Output voltage
tolerance band
Line regulation
Load regulation
V
t r
t
t r
t
s
I
O
Load transient
voltage deviation
Load transient
recovery time
Start-up time
Output current
From V
I
connection to V
O
= 0.9
×
V
Onom
Conditions
T
C
=+25 °C, V
I
= 53 V, I
O
=I
Omax
I
O
=I
Omax
I
O
=0 to I
O max
I
O
=I
O max
V
I
= 53V, I
O
=0 to I
O max
,
Load step = 0.25 x I
Omax
di/dt = 1A/us
Device
Output
min
11.8
9.6
11.64
3
3
+/-100
150
30
0
0
0
50
12.5
8.3
6.25
150
100
75
13.5
9.0
7.0
14.5
10.5
8.0
16.5
12.0
10.0
75
-53
14.9
15.5
16.0
12.0
9.0
18.0
14.0
12.0
100
typ
12.0
max
12.2
13.3
12.36
10
10
Unit
All
All
All
All
All
All
All
All
PKJ 4113A PIT
PKJ 4113 PIT
PKJ 4713 PIT
V
V
V
mV
mV
mV
µs
ms
A
V
Oi
P
Omax
Max output power
At V
O
= V
Onom
PKJ 4113A PIT
PKJ 4113 PIT
PKJ 4713 PIT
PKJ 4113A PIT
PKJ 4113 PIT
PKJ 4713 PIT
PKJ 4113A PIT
PKJ 4113 PIT
PKJ 4713 PIT
W
I
lim
Current limit threshold
V
O
= 0.96 V
Onom
@ T
C
<100
o
C
A
I
sc
Short circuit current
W
mV
p-p
dB
V
V
Oac
SVR
OVP
Output ripple & noise
Supply voltage
rejection (ac)
Over voltage protection
I
O
=I
O max, f < 20 MHz
f < 1kHz
V
I
= 53V,
All
All
Al
Miscellaneous
Characteristics
η
P
d
f
S
Efficiency
Power dissapation
Conditions
I
O
= I
Omax
, V
I
= 53V, T
C
= +25
o
C
I
O
= I
Omax
, V
I
= 53V, T
C
= +25
o
C
I
O
= 0...1.0 x I
Omax
Device
All
PKJ 4113A PIT
PKJ 4113 PIT
PKJ 4713 PIT
All
min
typ
93
11.3
7.5
5.6
300
max
Unit
%
W
kHz
Switching frequency
Absolute Maximum Ratings
Characteristics
T
C
T
S
V
I
V
ISO
V
RC
I
2
t
Maximum Operating Case Temperature
Storage temperature
Input voltage:
Continuous
Transient (100ms)
Isolation voltage
(input to output test voltage)
Remote control voltage
Inrush transient
1,500
15
1
min
– 40
– 40
– 0.5
max
+100
+125
+80
+100
Unit
Typical Characteristics
96%
°C
°C
V dc
V dc
Vdc
A
2
s
84%
82%
0
2
4
6
8
10
12
Output Current (A)
Efficiency (%)
V dc
94%
92%
90%
88%
86%
PKJ 4113A, 4113, & 4713 PIT Efficiencies
36V
53V
72V
Stress in excess of Absolute Maximum Ratings may cause permanent
damage. Absolute Maximum Ratings, sometimes referred to as "no
destruction limits," are normally tested with one parameter at a time
exceeding the limits of output data or electrical characteristics. If exposed
to stress above these limits, function and performance may degrade in an
unspecified manner.
EN/LZT 108 3486 R2B © Ericsson Inc., Microelectronics, December 2001
3
Product Program
V
I
V
O
/I
O
max
12V/12.5A
12V/8.3A
12V/6.25A
P
O
max
150 W
100 W
75 W
Ordering No.
PKJ 4113A PIT
PKJ 4113 PIT
PKJ 4713 PIT
48/60 V
The PKJ 4113A PIT, PKJ 4113 PIT, and PKJ 4713
PIT DC/DC power modules are available with the
different options listed in the Product Options Table.
Please check with the factory for availability.
Product Options
Product Options
Option
Negative remote on/off
logic, Industry Standard
trim (i.e. V
o
Adjust)
Positive remote on/off logic
Lead length 0.145"± 0.010"
Suffix
-
Example
PKJ 4113 PIT
P
LA
PKJ 4113 PIPT
PKJ 4113 PITLA
Information given in this Advanced Specification is
believed to be accurate and reliable. No responsibility is
assumed for the consequences of its use for any
infringement of patents or other rights of third parties that
may result from its use. No license is granted by
implication or otherwise under any patent or patent rights
of Ericsson Microelectronics. These products are sold
only according to Ericsson Microelectronics' general
conditions of sale, unless otherwise confirmed in writing.
Specifications are subject to change without notice.
Ericsson Inc., Microelectronics
1700 International Pkwy., Suite 200
Richardson, Texas 75081
Phone: 877-ERICMIC
www.ericsson.com/microelectronics
For sales contacts, please refer to our website
or call: 877-374-2642 or fax: 972-583-8355
The latest and most complete information can
be found on our website!
Advanced Data Sheet
AE/LZT 108 3486 R2B
© Ericsson Inc., Microelectronics, December 2001
