Crimp
PH
CONNECTOR
Disconnectable Crimp style connectors
• Reliable contact
Emboss Tape
2.0mm
(.079") pitch
Features –––––––––––––––––––––––
The contact has long dimples near the center to ensure a good
connection at all times, even under conditions of vibration and
mechanical abuse, and when used with low voltage and low
current circuits.
• Easy and effective crimping
Although the contact is compact, it has a long wire strip
holding length of 2.6 +/- 0.4mm (.102" +/-.016"). This long
length simplifies automatic crimping and the crimping of
shielded wires.
• Fully shrouded header
The fully shrouded header has walls on all four sides to
prevent improper connection to the mating housing and to
prevent the instruction of flux and other contaminants.
• High solderable square post
The square post is copper-undercoated and tin/lead-plated for
superior solderability and for whisker prevention.
This is a thin, low-profile 2.0mm (.079")
pitch connector 7.5mm (.295") in height
after mounting and 4.5mm (.177") in width.
It is designed to meet the demand for
high-density connection of internal wires
to printed circuit boards. It is compact,
highly reliable and low in cost.
• Printed circuit board retention mechanism
The solder side of the header has a retention mechanism that
prevents it from floating during soldering. As a result, the
header can be positioned accurately.
• Compatible with the KR insulation
displacement connector
The same shrouded header can be used for either PH crimp-
style connector or KR insulation displacement connector. This
allows both types of connector to be used interchangeably
without replacing the header.
• Surface mount model (SMT)
This connector is also available in a surface mount
configuration. Its housing is made of heat resistant resin so
that it is not adversely affected during reflow soldering.
Because of its tiny size and ability to be surface mounted, this
connector meets the demand for high-density mounting of
components inside electronic products.
Specifications ––––––––––––––––––
2
3
4
5
6
• Current rating: 2.0A AC, DC (AWG #24)
• Voltage rating: 100V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/10m
Ω
max.
After environmental testing/20m
Ω
max.
• Insulation resistance:
1,000M
Ω
min.
• Withstanding voltage: 800V AC/minute
• Applicable wire: AWG #32 to #24
• Applicable PC board thickness: 0.8 to 1.6mm(.031" to .063")
* Contact JST for details
Standards –––––––––––––––––––––
Recognized file No. E60389
Certified file No. LR20812
File No. R75087 (conforms to DIN/VDE 0627)
9
PH
CONNECTOR
Through-hole type shrouded header –––––––––––––––––––––––––––––––––––––––––
The shrouded headers are interchangeable with those of the KR, KRD and CR insulation displacement connectors (see pages 139, 141 & 137)
Top entry type
(2 circuits)
B
4.5(.177)
1.7(.067)
Model No.
Dimensions mm(in.)
A
2.0( .079)
4.0( .157)
6.0( .236)
8.0( .315)
Q´ty / box
Top
entry
type
1,000
1,000
1,000
1,000
1,000
500
500
500
500
500
500
250
250
250
250
(3 circuits or more)
B
4.5(.177)
1.7(.067)
Cir-
cuits
2
3
4
Top
entry
type
Side
entry
type
B
5.9( .232)
7.9( .311)
9.9( .390)
11.9( .469)
Side
entry
type
1,000
1,000
500
500
500
500
250
250
250
250
250
250
250
200
200
B 2B-PH-K S 2B-PH-K
B 3B-PH-K S 3B-PH-K
B 4B-PH-K S 4B-PH-K
B 5B-PH-K S 5B-PH-K
6.0(.236)
6.0(.236)
5
6
7
8
9
10
11
12
B 6B-PH-K S 6B-PH-K
10.0( .394) 13.9( .547)
B 7B-PH-K S 7B-PH-K
12.0( .472) 15.9( .626)
B 8B-PH-K S 8B-PH-K
14.0( .551) 17.9( .705)
B 9B-PH-K S 9B-PH-K
16.0( .630) 19.9( .783)
B10B-PH-K S10B-PH-K
18.0( .709)
21.9( .862)
3.4
(.134)
1.95
(.077)
A
0.5
(.020)
1.95
(.077)
2.0
(.079)
A
0.5
(.020)
3.4
(.134)
B11B-PH-K S11B-PH-K
20.0( .787) 23.9( .941)
B12B-PH-K S12B-PH-K
22.0( .866) 25.9(1.020)
B13B-PH-K S13B-PH-K
24.0( .945) 27.9(1.098)
B14B-PH-K S14B-PH-K
26.0(1.024) 29.9(1.177)
B15B-PH-K S15B-PH-K
28.0(1.102) 31.9(1.256)
B16B-PH-K S16B-PH-K
30.9(1.181) 33.9(1.335)
Material and Finish
Post: Brass, copper-undercoated, tin/lead-plated
Wafer: Nylon 66, UL94V-0, ivory
Side entry type
4.8(.189)
1.7(.067)
13
14
B
15
16
6.25(.246)
3.4
(.134)
1.95
(.077)
2.0
(.079)
A
0.5
(.020)
1.6
(.063)
6.0(.236)
Note:
1.When ordering a natural-colored (white) shrouded header, please specify a
model number with suffix “S” (Example: B3B-PH-K-S).
¨
2.16-circuit headers are not TUV approved.
Through-hole type PC board layout
(viewed from soldering side)
and Assembly layout –––
Top entry type
4.5
(.177)
Side entry type
2.0
±
0.05
1.9
min.
(.079±.002) (.075)
6.25
min.
(.246)
9.1(.358)
4.8
(.189)
6.25
(.246)
2.0
±
0.05 1.9
min.
(.079
±
.002) (.075)
2.8
min.
(.110)
0.7
+ 0.1
0
.004
(.028
+ 0
)dia.
8.0(.315)
6.0(.236)
0.1
0.7
+ 0
.004
(.028
+ 0
)dia.
Note:
1. Tolerances are non-cumulative ±0.05mm(±.002") for all centers.
2. Hole dimensions differ according to the kind of printed circuit board and piercing method. If printed circuit boards made of hard material such as FR-4 are used,
the hole dimensions should be larger. The hole dimensions shown above are reference values.
Contact JST for details.
11
PH
CONNECTOR
SMT type shrouded header –––––––––––––––––––––––––––––––––––––––––––––––––
•The shrouded headers are interchangeable with those of the KR, KRD and CR insulation displacement connectors (see pages 139, 141 & 137).
¨
•SMT type shrouded headers are not TUV approved.
SM type
Top entry type
B
1.95
(.075)
A
2.0(.079)
5.0
(.197)
1.9(.075)
3.1
(.122)
Model No.
Cir-
cuits
2
4
5
7
6.6(.260)
Dimensions mm(in.)
A
2.0(.079)
6.0(.236)
8.0(.315)
Top entry
type
B2B-PH-SM
B4B-PH-SM
-
Side entry
type
-
-
B
5.9(.232)
9.9(.390)
11.9(.469)
15.9(.626)
21.9(.862)
23.9(.941)
C
4.7(.185)
8.7(.343)
10.7(.421)
14.7(.579)
20.7(.815)
22.7(.894)
Q´ty /
box
1,000
500
500
500
250
250
S 5B-PH-SM
B7B-PH-SM S 7B-PH-SM
12.0(.472)
-
-
10
11
S10B-PH-SM
18.0(.709)
S11B-PH-SM
20.0(.787)
Material and Finish
1.0
(.039)dia.
1.35(.053)
C
3.2
(.126)
Post:
Wafer:
Brass nickel-undercoated, tin-plated
PPS, UL94V-0, natural (dark brown)
Side entry type
B
1.95
(.077)
A
2.0(.079)
5.0(.197)
1.9(.075)
1.35(.053)
C
0.8(.031)
1.0
(.039)dia.
1.6
3.0
(.063)
(.118)
6.0(.236)
3.4(.134)
SM3 type
Top entry type
B
2.975
(.117)
A
2.0(.079)
5.0
2.0
(.197) [ (.079) ]
1.9(.075)
Model No.
Cir-
cuits
2
3
4
5
6.6(.260)
Dimensions mm(in.)
A
2.0( .079)
4.0( .157)
6.0( .236)
8.0( .315)
10.0( .394)
12.0( .472)
14.0( .551)
16.0( .630)
18.0( .709)
20.0( .787)
22.0( .866)
24.0( .945)
26.0(1.024)
Top entry
type
Side entry
type
B
7.9( .311)
9.9( .390)
11.9( .469)
13.9( .547)
15.9( .626)
17.9( .705)
19.9( .783)
21.9( .862)
23.9( .941)
25.9(1.020)
27.9(1.098)
29.9(1.177)
31.9(1.256)
Q´ty /
reel
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
B 2B-PH-SM3-TB S 2B-PH-SM3-TB
B 3B-PH-SM3-TB S 3B-PH-SM3-TB
B 4B-PH-SM3-TB S 4B-PH-SM3-TB
B 5B-PH-SM3-TB S 5B-PH-SM3-TB
B 6B-PH-SM3-TB S 6B-PH-SM3-TB
B 7B-PH-SM3-TB S 7B-PH-SM3-TB
B 8B-PH-SM3-TB S 8B-PH-SM3-TB
B 9B-PH-SM3-TB S 9B-PH-SM3-TB
B10B-PH-SM3-TB S10B-PH-SM3-TB
B11B-PH-SM3-TB
-
6
7
8
2.2
(.087)
1.4
(.055)
9
10
11
12
B12B-PH-SM3-TB S12B-PH-SM3-TB
B13B-PH-SM3-TB S13B-PH-SM3-TB
-
Side entry type
13
14
S14B-PH-SM3-TB
Material and Finish
5.5(.217)
2.4(.094)
Post:
Copper alloy, copper-undercoated, tin/lead-plated
Wafer: Nylon 46, UL94V-0, natural (ivory)
Solder tab: Brass, copper-undercoated, tin/lead-plated
1.6
(.063)
6.0(.236)
2.0
2.95 (.079)
(.116)
A
B
2.6
[ (.102) ]
Note: The products listed above are supplied on embossed-tape.
12
