SPR2: Descriptionpower carbon film leaded resistor; File Size297KB，3 Pages; ManufacturerKOA Speer; Websitehttp://www.koaspeer.com/

Download Datasheet View All

SPR2 Overview

power carbon film leaded resistor

Preview

Download Datasheet

View All

power carbon film leaded resistor

features

•

Fixed metal film resistor available (specify “SPRX”)

Flameproof silicone coating equivalent to (UL94V0)

High reliability performance

Suitable for automatic machine insertion

Marking: Light green body color

Color-coded bands on 1/2W - 1W

Alpha-numeric black marking on 2W - 5W

•

Products with lead-free terminations meet EU RoHS

and China RoHS requirements

•

Surface mount style “N” forming is suitable for

automatic mounting

dimensions and construction

Ceramic Body

Type

SPR1/4

SPRX1/4

SPR1/2

SPRX1/2

Marking

Flame Retardant Coating

End

Cap

Lead

Wire

SPR1

SPRX1

SPR2

SPRX2

SPR3

SPRX3

SPR5

SPRX5

.13±.012

(3.3±0.3)

.244±.02

(6.2±0.5)

.354±.039

(9.0±1.0)

.472±.039

(12.0±1.0)

.610±.039

(15.5±1.0)

.965±.039

(24.5±1.0)

Dimensions

inches

(mm)

C (max.)

d nominal

.138

(3.5)

.280

(7.1)

.437

(11.1)

.591

(15.0)

.709

(18.0)

1.10

(28.0)

.067±.012

(1.7±0.3)

.098±.02

(2.5±0.5)

.138±.02

(3.5±0.5)

.165±.031

(4.2±0.8)

.236±.039

(6.0±1.0)

.354±.039

(9.0±1.0)

.031

(0.8)

.018

(0.45)

.024

(0.6)

.945 Min.

(24.0 Min.)

.787 Min.

(20.0 Min.)

1.18±.118

(30.0±3.0)

1.50±.118

(38.0±3.0)

* Lead length changes depending on taping and forming type.

ordering information

New Part #

SPR

Type

SPR

SPRX

1/2

Power

Rating

1/4: 0.25W

1/2: 0.5W

1: 1W

2: 2W

3: 3W

5: 5W

Termination

Material

C: SnCu

T52

Taping and Forming

Axial: T26, T52, T521, T631

Stand-off Axial: L52, L521, L631

Radial: VT, VTP, VTE, GT

L, U, M, N Forming

Packaging

A: Ammo

R: Reel

TEB:

Embossed

plastic

(N forming)

103

Nominal

Resistance

±2%, ±5%:

2 significant figures

+ 1 multiplier

“R” indicates decimal

on value <10Ω

±1%: 3 significant

figures + 1 multiplier

“R” indicates decimal

on value <100Ω

Tolerance

F: ±1%

G: ±2%

J: ±5%

For further information

on packaging, please

refer to Appendix C.

Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.

12/18/12

KOA Speer Electronics, Inc.

• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com

139

resistors

SPR
