BT137X-800E
4Q Triac
1 May 2015
Product data sheet
1. General description
Planar passivated sensitive gate four quadrant triac in a SOT186A "full pack" plastic
package intended for use in general purpose bidirectional switching and phase control
applications. This sensitive gate "series E" triac is intended to be interfaced directly to
microcontrollers, logic integrated circuits and other low power gate trigger circuits.
2. Features and benefits
•
•
•
•
•
•
•
Direct triggering from low power drivers and logic ICs
High blocking voltage capability
Isolated package
Low holding current for small load currents and lowest EMI at commutation
Planar passivated for voltage ruggedness and reliability
Sensitive gate
Triggering in all four quadrants
3. Applications
•
•
General purpose motor control
General purpose switching
4. Quick reference data
Table 1.
Symbol
V
DRM
I
TSM
I
T(RMS)
Quick reference data
Parameter
repetitive peak off-
state voltage
non-repetitive peak on- full sine wave; T
j(init)
= 25 °C;
state current
t
p
= 20 ms;
Fig. 4; Fig. 5
RMS on-state current
full sine wave; T
h
≤ 73 °C;
Fig. 1; Fig. 2;
Fig. 3
Static characteristics
I
GT
gate trigger current
V
D
= 12 V; I
T
= 0.1 A; T2+ G+;
T
j
= 25 °C;
Fig. 7
V
D
= 12 V; I
T
= 0.1 A; T2+ G-;
T
j
= 25 °C;
Fig. 7
-
4
10
mA
-
2.5
10
mA
Conditions
Min
-
-
-
Typ
-
-
-
Max
800
65
8
Unit
V
A
A
Scan or click this QR code to view the latest information for this product
TO
-2
20F
NXP Semiconductors
BT137X-800E
4Q Triac
Symbol
Parameter
Conditions
V
D
= 12 V; I
T
= 0.1 A; T2- G-;
T
j
= 25 °C;
Fig. 7
V
D
= 12 V; I
T
= 0.1 A; T2- G+;
T
j
= 25 °C;
Fig. 7
Min
-
-
Typ
5
11
Max
10
25
Unit
mA
mA
5. Pinning information
Table 2.
Pin
1
2
3
mb
Pinning information
Symbol Description
T1
T2
G
n.c.
main terminal 1
main terminal 2
gate
mounting base; isolated
Simplified outline
mb
Graphic symbol
T2
sym051
T1
G
1 2 3
TO-220F (SOT186A)
6. Ordering information
Table 3.
Ordering information
Package
Name
BT137X-800E
TO-220F
Description
plastic single-ended package; isolated heatsink mounted; 1
mounting hole; 3-lead TO-220 "full pack"
Version
SOT186A
Type number
BT137X-800E
All information provided in this document is subject to legal disclaimers.
© NXP Semiconductors N.V. 2015. All rights reserved
Product data sheet
1 May 2015
2 / 13
NXP Semiconductors
BT137X-800E
4Q Triac
7. Limiting values
Table 4.
Limiting values
In accordance with the Absolute Maximum Rating System (IEC 60134).
Symbol
V
DRM
I
T(RMS)
I
TSM
Parameter
repetitive peak off-state voltage
RMS on-state current
non-repetitive peak on-state
current
full sine wave; T
h
≤ 73 °C;
Fig. 1; Fig. 2;
Fig. 3
full sine wave; T
j(init)
= 25 °C;
t
p
= 20 ms;
Fig. 4; Fig. 5
full sine wave; T
j(init)
= 25 °C;
t
p
= 16.7 ms
I t
dI
T
/dt
2
Conditions
Min
-
-
-
-
-
-
-
-
-
-
-
Max
800
8
65
71
21
50
50
10
50
2
5
0.5
150
125
003aaa969
Unit
V
A
A
A
2
I t for fusing
rate of rise of on-state current
2
t
p
= 10 ms; SIN
I
G
= 20 mA; T2+ G+
I
G
= 20 mA; T2+ G-
I
G
= 50 mA; T2- G+
I
G
= 20 mA; T2- G-
A s
A/µs
A/µs
A/µs
A/µs
A
W
W
°C
°C
I
GM
P
GM
P
G(AV)
T
stg
T
j
25
I
T(RMS)
(A)
20
peak gate current
peak gate power
average gate power
storage temperature
junction temperature
003aaa970
over any 20 ms period
-
-40
-
10
I
T(RMS)
(A)
8
73 °C
15
6
10
4
5
2
0
10
- 2
10
- 1
1
10
surge duration (s)
0
- 50
0
50
100
T
h
(°C)
150
f = 50 Hz; T
h
= 73 °C
Fig. 1.
RMS on-state current as a function of surge
duration; maximum values
Fig. 2.
RMS on-state current as a function of heatsink
temperature; maximum values
BT137X-800E
All information provided in this document is subject to legal disclaimers.
© NXP Semiconductors N.V. 2015. All rights reserved
Product data sheet
1 May 2015
3 / 13
NXP Semiconductors
BT137X-800E
4Q Triac
12
P
tot
(W)
8
aaa-017680
conduction
angle, α
(degrees)
30
60
90
120
180
form
factor
a
2.816
1.967
1.570
1.329
1.110
α = 180°
α
120 °
90°
α
60°
30°
71
T
h(max)
(°C)
80
89
98
107
116
4
0
0
2
4
6
8
I
T(RMS)
(A)
10
125
α = conduction angle
a = form factor = I
T(RMS)
/ I
T(AV)
Fig. 3.
Total power dissipation as a function of RMS on-state current; maximum values
80
I
TSM
(A)
60
003aae693
40
I
T
20
I
TSM
t
1/f
T
j(init)
= 25 °C max
0
1
10
10
2
10
3
number of cycles
10
4
f = 50 Hz
Fig. 4.
Non-repetitive peak on-state current as a function of the number of sinusoidal current cycles; maximum
values
BT137X-800E
All information provided in this document is subject to legal disclaimers.
© NXP Semiconductors N.V. 2015. All rights reserved
Product data sheet
1 May 2015
4 / 13
