RS3GR7G

Description
Rectifier Diode, 1 Phase, 1 Element, 3A, 400V V(RRM), Silicon, DO-214AB, GREEN, PLASTIC, SMC, 2 PIN
CategoryDiscrete semiconductor    diode
File Size420KB,4 Pages
ManufacturerTaiwan Semiconductor
Websitehttp://www.taiwansemi.com/
Environmental Compliance
Download Datasheet Parametric View All

RS3GR7G Overview

Rectifier Diode, 1 Phase, 1 Element, 3A, 400V V(RRM), Silicon, DO-214AB, GREEN, PLASTIC, SMC, 2 PIN

RS3GR7G Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerTaiwan Semiconductor
package instructionGREEN, PLASTIC, SMC, 2 PIN
Reach Compliance Codenot_compliant
ECCN codeEAR99
applicationEFFICIENCY
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)1.3 V
JEDEC-95 codeDO-214AB
JESD-30 codeR-PDSO-C2
JESD-609 codee3
Humidity sensitivity level1
Maximum non-repetitive peak forward current100 A
Number of components1
Phase1
Number of terminals2
Maximum operating temperature150 °C
Minimum operating temperature-55 °C
Maximum output current3 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Maximum repetitive peak reverse voltage400 V
Maximum reverse current10 µA
Maximum reverse recovery time0.15 µs
surface mountYES
Terminal surfaceMatte Tin (Sn)
Terminal formC BEND
Terminal locationDUAL

RS3GR7G Preview

CREAT BY ART
RS3A - RS3M
3.0 AMP. Surface Mount Fast Recovery Rectifiers
SMC/DO-214AB
Features
For surface mounted application
Glass passivated junction chip
Built-in strain relief, ideal for automated
placement
Plastic material used carries Underwriters
Laboratory Classification 94V-0
Fast switching for high efficiency
High temperature soldering:
260℃ / 10 seconds at terminals
Green compound with suffix "G" on packing
code & prefix "G" on datecode
Mechanical Data
Case: Molded plastic
Terminals: Pure tin plated, Lead free
Polarity: Indicated by cathode band
Packing: 16mm tape per EIA STD RS-481
Weight: 0.21 grams
Ordering Information (example)
Part No.
RS3A
Package
SMC
Packing
850 / 7" REEL
Packing code
R7
Packing code
(Green)
R7G
Maximum Ratings and Electrical Characteristics
Rating at 25
ambient temperature unless otherwise specified.
Parameter
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
Peak Forward Surge Current, 8.3 ms Single Half Sine-wave
Superimposed on Rated Load (JEDEC method)
Maximum Instantaneous Forward Voltage (Note 1)
@3A
Maximum Reverse Current @ Rated VR
T
A
=25
T
A
=125
Symbol
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
Trr
Cj
R
θjA
R
θjL
T
J
T
STG
RS
3A
50
35
50
RS
3B
100
70
100
RS
3D
200
140
200
RS
3G
400
280
400
3
100
1.3
10
250
RS
3J
600
420
600
RS
3K
800
560
800
RS
3M
1000
700
1000
Unit
V
V
V
A
A
V
uA
Maximum Reverse Recovery Time (Note 2)
Typical Junction Capacitance (Note 3)
Typical Thermal Resistance
Operating Temperature Range
Storage Temperature Range
Note 1: Pulse Test with PW=300 usec, 1% Duty Cycle
150
60
50
15
250
500
nS
pF
O
C/W
O
O
- 55 to + 150
- 55 to + 150
C
C
Note 2: Reverse Recovery Test Conditions: I
F
=0.5A, I
R
=1.0A, I
RR
=0.25A
Note 3: Measured at 1 MHz and Applied Reverse Voltage of 4.0V D.C.
Version:G13
RATINGS AND CHARACTERISTIC CURVES (RS3A THRU RS3M)
FIG. 2 TYPICAL REVERSE CHARACTERISTICS
FIG.1 FORWARD CURRENT DERATING CURVE
3.5
3
INSTANTANEOUS REVERSE CURRENT (uA)
AVERAGE FORWARD CURRENT
(A)
100
2.5
2
10
TA=125℃
1.5
1
RESISTIVE OR
INDUCTIVE LOAD
0.5
0
0
1
TA=75℃
25
50
75
100
125
150
LEAD TEMPERATURE (
o
C)
TA=25℃
0.1
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
150
FIG. 3 MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
8.3mS Single Half Sine Wave
JEDEC Method
PEAK FORWARD SURGE
CURRENT (A)
125
100
75
50
FIG. 5 TYPICAL FORWARD CHARACTERISTICS
100
Pulse Width=300us
1% Duty Cycle
INSTANTANEOUS FORWARD CURRENT (A)
25
0
1
TA=25℃
10
NUMBER OF CYCLES AT 60 Hz
100
10
TA=125℃
100
FIG. 4 TYPICAL JUNCTION CAPACITANCE
CAPACITANCE (pF)
TA=25℃
f=1.0MHz
Vsig=50mVp-p
1
TA=25℃
TA=40℃
0.1
0.4
10
1
10
REVERSE VOLTAGE (V)
100
0.6
0.8
1
1.2
1.4
1.6
1.8
2
FORWARD VOLTAGE (V)
Version:G13
Ordering information
Part No.
RS3x
(Note)
Package
SMC
SMC
Packing
850 / 7" REEL
3K / 13" REEL
Packing code
R7
R6
M6
Packing code
(Green)
R7G
R6G
M6G
3K / 13" Plastic REEL
SMC
Note: "x" is Device Code from "A" thru "M".
Tape & Reel specification
Reel Size Tape Size
7"
16mm
Reel Size Tape Size
13"
16mm
A
±2.0
178
A
max
330
B
±0.4
1.9
B
±0.5
2
C
+0.5;-0.2
13
C
±0.5
13
D
min
21
D
min
20.2
N
±1.0
62
N
±0.5
75
G
+0.8;-0
16.2
G
+2.0;-0
16.4
T
max
18.6
T
max
22.4
Unit (mm)
Suggested PAD Layout
Symbol
A
B
C
D
E
Unit(mm)
3.3
2.5
6.8
4.4
9.3
Version:G13
Dimensions
DIM.
A
B
C
D
E
F
G
H
I
Unit(mm)
Min
2.90
6.60
5.59
2.00
1.00
7.75
0.10
0.15
1.26
Max
3.20
7.11
6.22
2.62
1.60
8.13
0.20
0.31
1.56
Unit(inch)
Min
0.114
0.260
0.220
0.079
0.039
0.305
0.004
0.006
0.050
Max
0.126
0.280
0.245
0.103
0.063
0.320
0.008
0.012
0.061
Marking Diagram
P/N
G
YW
F=
= Specific Device Code
= Green Compound
= Date Code
Factory Code
Version:G13
