Ferrite Chip Beads
FEATURES
• RUGGED CONSTRUCTION IN STANDARD EIA SIZES
• EFFECTIVE EM/RFI SUPPRESSION UP TO 1 Ghz
• 100% CLOSED MAGNETIC CIRCUIT, AVOIDS CROSSTALK
• BOTH FLOW AND REFLOW SOLDERING APPLICABLE
• OPERATING TEMPERATURE RANGE: -40
O
C TO +125
O
C
NCB Series
RoHS
Compliant
includes all homogeneous materials
*See Part Number System for Details
STANDARD VALUES AND CASE SIZES (mm)
EIA
Size
NIC
Part Number
NCB0201N100TR020F
NCB0201N220TR020F
NCB0201N330TR015F
NCB0201N470TR015F
NCB0201N560TR010F
NCB0201N600TR020F
NCB0201N800TR020F
NCB0201N121TR020F
NCB0201N241TR020F
NCB0201N601TR020F
NCB0402P220TR030F
NCB0402P300TR030F
NCB0402P400TR060F
NCB0402P600TR030F
NCB0402P700TR050F
NCB0402P121TR010F
NCB0402P121TR030F
NCB0402P121TR050F
NCB0402P151TR010F
NCB0402P221TR010F
NCB0402P221TR030F
NCB0402P221TR070F
NCB0402P301TR005F
NCB0402P331TR010F
NCB0402P471TR010F
NCB0402P601TR010F
NCB0402P601TR030F
NCB0402P102TR020F
NCB0402P102TR025F
NCB0402P182TR020F
NCB0603R100TR070F
NCB0603R300TR070F
NCB0603R470TR070F
NCB0603R600TR070F
NCB0603R750TR050F
NCB0603R800TR020F
NCB0603R121TR060F
NCB0603R141TR020F
NCB0603R151TR060F
NCB0603R221TR055F
NCB0603R301TR050F
NCB0603R331TR050F
NCB0603R431TR040F
NCB0603R451TR010F
NCB0603R471TR035F
NCB0603R601TR035F
NCB0603R751TR020F
NCB0603R801TR010F
NCB0603R102TR020F
NCB0603R152TR030F
Impedance
at 100MHz
Ω
(±25% Tol.)
10
22
33
47
56
60
80
120
240
600
22
30
40
60
70
120
120
120
151
220
220
220
300
330
470
600
600
1000
1000
1800
10
30
47
60
75
80
120
140
150
220
300
330
430
450
470
600
750
800
1000
1500
DC
DC
Resistance
Current
Max. (Ω)
Max. (mA)
0.25
200
0.45
200
0.55
150
0.7
150
1
100
0.4
200
0.6
200
0.8
200
1
200
1.7
200
0.2
300
0.2
300
0.12
600
0.25
300
0.15
500
0.3
100
0.3
300
0.25
500
0.3
100
0.4
100
0.4
300
0.4
700
0.75
50
0.5
100
0.65
100
0.8
100
0.8
300
1.2
200
1.1
250
2.2
200
0.2
700
0.2
700
0.2
700
0.2
700
0.3
500
0.3
200
0.25
600
0.3
200
0.25
600
0.3
550
0.35
500
0.35
500
0.3
400
0.7
100
0.45
350
0.5
350
0.7
200
0.9
100
0.7
200
1
300
Continued on page 2
A
(mm)
B
(mm)
C
(mm)
D
(mm)
0201
0.6 ±0.05
0.3 ±0.05
0.3 ±0.05
0.15 ±0.05
0402
1.0 ±0.5
0.50 ±0.15
0.5 ±0.15
0.25 ±0.15
0603
1.6 ±0.2
0.8 ±0.15
0.8 ±0.15
0.4 ±0.2
NEW VALUES
®
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
Specifications are subject to change
1
Ferrite Chip Beads
EIA
Size
1806
NIC
P/N
NCB1806E800TR040F
NCB1806E101TR050F
NCB1806E151TR020F
NCB1812D700TR030F
NCB1812D800TR030F
NCB1812D121TR050F
NCB1812D131TR030F
Impedance
at 100MHz
Ω
(±25% Tol.)
80
100
150
70
80
120
130
DC
Resistance
Max. (Ω)
0.3
0.1
0.5
0.4
0.4
0.3
0.4
DC
Current
Max. (mA)
400
500
200
300
300
500
300
A
(mm)
4.5 ± 0.25
B
(mm)
1.6 ± 0.2
C
(mm)
NCB Series
D
(mm)
0.5 ± 0.3
1.6 ± 0.2
1812
4.5 ± 0.25
3.2 ± 0.2
1.5 ± 0.2
0.5 ± 0.3
PaRt NumBeR SyStem
NCB 0805 A 121 TR 020 F
RoHS Compliant
DC Current Rating (see standard values and case size table)
Packaging: TR = Tape and Reel
Impedance at 100Mhz
3 digit code; first two digits are significant third digit is no. of zeros
Part Thickness Max; A=1.1mm, B=1.3mm, C=1.5mm, D=1.7mm, E=1.8mm, K=2.8mm, L=3.1mm, N=0.35, P=0.65mm, R=0.95mm
Series
Size
NCB PReSSeD PaPeR taPe DImeNSIONS (mm)
Dimensions
A
B
T
W
E
F
P1
P2
Chips/Reel
Fig.
NCB0201N
0.38 ± 0.03
0.68 ± 0.03
0.44 ± 0.03
NCB0402P NCB0603R NCB0805A
0.62 ± 0.03 1.05 ± 0.03 1.50 ± 0.05
1.12 ± 0.03 1.85 ± 0.03 2.30 ± 0.05
0.60 ± 0.03 0.95 ± 0.05 0.95 ± 0.05
8.0 ± 0.1
1.75 ± 0.1
3.5 ± 0.1
2.0 ± 0.1
4.0 ± 0.1
2.0 ± 0.1
10,000
10,000
4,000
4,000
1
1
1
1
FIGURE 1 (PRESSED PAPER TAPE)
P2
P1
E
F
W
A
B
T
NCB emBOSSeD PLaStIC taPe DImeNSIONS (mm)
Dimensions
A
B
T
W
E
F
G
P
Chips/Reel
Fig.
NCB0805C NCB1206B NCB1806E NCB1812D
1.50 ± 0.1 1.94 ± 0.1 1.94 ± 0.1 3.64 ± 0.1
2.35 ± 0.1 3.54 ± 0.1 4.94 ± 0.1 4.94 ± 0.1
1.45 ± 0.1 1.29 ± 0.05 1.90 ± 0.05 1.80 ± 0.05
8.0
12.0
1.75
3.5
5.5
2.0 ± 0.05
4.0 ± 0.1
8.0 ± 0.1
2,000
3,000
2,000
1,000
2
2
2
2
FIGuRe 2 (emBOSSeD PLaStIC taPe)
E ±0.05
4.0±0.1
G
+0.1
φ
1.5-0
0.30 ±0.05
W±0.2
F ±0.1
B
P
A
T
®
For Impedance (Z) over Frequency curves
see
www.RFpassives.com
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
Specifications are subject to change
3
Ferrite Chip Beads
NCB LaND PatteRN DImeNSIONS (mm)
Size
0201
0402
0603
0805
1206
1806
1812
1612
A
0.30
0.80
1.00
1.00
1.00
1.05
1.05
1.70
B
0.32
0.55
0.60
1.20
1.80
1.80
3.50
2.00
C
0.25
0.50
0.80
1.20
2.00
3.30
3.30
2.20
NCB Series
NCB ReeL DImeNSIONS
Dim
A
B
C
D
E
W
t
R
Size: 0201, 0402, 0603, 0805 & 1206
178 ± 2.0
60 ± 1.0
13.0 ± 0.5
21.0 ± 0.8
2.0 ± 0.5
10.0 ± 1.0
2.0 ± 0.5
1.0
Size: 1806 & 1812
14.0 ± 1.0
RECOMMENDED LAND PATTERN (mm)
E
C
B
B
R
A
C
A
D
A
t
w
®
4
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
Specifications are subject to change
