FKC08 SERIES
8 WATTS
DC-DC CONVERTER
FEATURES
•
8 WATTS OUTPUT POWER
•
OUTPUT CURRENT UP TO 2A
•
STANDARD 1.25 X 0.80 X 0.40 INCH
•
HIGH EFFICIENCY UP TO 88%
•
2:1 WIDE INPUT VOLTAGE RANGE
•
FIVE-SIDED CONTINUOUS SHIELD
•
FIXED SWITCHING FREQUENCY (300kHz)
•
STANDARD 24 PIN DIP PACKAGE & SMD TYPE PACKAGE
•
CE MARK MEETS 2006/95/EC, 2011/95/EC AND 2004/108/EC
•
SAFETY MEETS UL60950-1, EN60950-1 AND IEC60950-1
•
ISO9001 CERTIFIED MANUFACTURING FACILITIES
•
COMPLIANT TO RoHS EU DIRECTIVE 2011/65/EU
OPTIONS
SMD TYPE
APPLICATIONS
Wireless Network
Telecom/Datacom
Industry Control System
Measurement Equipment
Semiconductor Equipment
DESCRIPTION
The FKC08 series offer 8 watts of output power from a package in an IC
compatible 24pin DIP configuration. FKC08 series have 2:1 wide input voltage of
9-18, 18-36 and 36-75VDC. The FKC08 have features 1600VDC of isolation, short
circuit protection and as well as five sided shielding.
T E C H N I C A L S P E C I F I C AT I O N
OUTPUT SPECIFICATIONS
Output power
Voltage accuracy
Minimum load
Line regulation
Load regulation
LL to HL at Full Load
Single (DIP)
No Load to Full Load Single (SMD)
Dual (SMD,DIP)
20MHz bandwidth
All specifications are typical at nominal input, full load and 25ºC otherwise noted
INPUT SPECIFICATIONS
8 Watts, max.
± 1%
0%
± 0.2%
± 0.5%
± 1%
± 1%
± 5%
See table
0.02% / ºC, max.
200µs
150%
Input filter
Input surge voltage
12VDC input
24VDC input
48VDC input
Input voltage range
12VDC nominal input
24VDC nominal input
48VDC nominal input
9 ~ 18VDC
18 ~ 36VDC
36 ~ 75VDC
Pi type
36VDC 100ms,max.
50VDC 100ms,max.
100VDC 100ms,max.
20mAp-p
Input reflected ripple current
Start up time
Cross regulation (Dual) Asymmetrical load 25% / 100% FL
Ripple and noise
Temperature coefficient
Transient response recovery time 25% load step change
Over load protection
Short circuit protection
% of FL at nominal input
Nominal input and
Power up
700ms
constant resistive load
Remote ON/OFF (Note 5)
(Positive logic)
DC-DC ON
Open or 3.5V < Vr < 12V
DC-DC OFF
Short or 0V < Vr < 1.2V
Input current of remote control pin Nominal input
-0.5mA ~ 0.5mA
Remote off state input current
Nominal input
2.5mA
Continuous, automatics recovery
GENERAL SPECIFICATIONS
Efficiency
Isolation voltage
Input to Output
Input(Output) to Case
500VDC
See table
1600VDC, min. 1minute
DIP 1600VDC, min. 1minute
SMD 1000VDC, min. 1minute
10 ohms, min.
300pF, max.
300kHz±10%.
IEC60950-1, UL60950-1, EN60950-1
Nickel-coated copper
Non-conductive black plastic
Epoxy (UL94-V0)
1.25 X 0.80 X 0.40 Inch
(31.8 X 20.3 X 10.2 mm)
DIP
16g (0.55oz)
SMD
18g (0.62oz)
BELLCORE TR-NWT-000332
3.053 x 10
6
hrs
MIL-HDBK-217F
1.213 x 10
6
hrs
9
Isolation resistance
Isolation capacitance
Switching frequency
Design meet safety standard
Case material
Base material
Potting material
Dimensions
Weight
MTBF (Note 1)
ESD
Radiated immunity
EN61000-4-2
EN61000-4-3
10 V/m
2kV
1kV
Conducted immunity
EN61000-4-6
10 Vr.m.s
Page 1 of 3
www.pduke.com
±
Surge (Note 7)
EN61000-4-5
±
Fast transient (Note 7) EN61000-4-4
±
±
±
ENVIRONMENTAL SPECIFICATIONS
Operating ambient temperature
Maximum case temperature
Storage temperature range
Thermal impedance
Thermal shock
Vibration
Relative humidity
Nature convection
-40ºC ~ +85ºC (with derating)
+100ºC
-55ºC ~ +125ºC
20ºC/Watt
MIL-STD-810F
MIL-STD-810F
5% to 95% RH
EMC CHARACTERISTICS
EMI (Note 6)
EN55022
Air
Contact
Class A, Class B
8kV
6kV
Perf. Criteria A
Perf. Criteria A
Perf. Criteria A
Perf. Criteria A
Perf. Criteria A
2013/6/4
FKC08 SERIES
8 WATTS
DC-DC CONVERTER
Model
Number
FKC08-12S33
FKC08-12S05
FKC08-12S12
FKC08-12S15
FKC08-12D05
FKC08-12D12
FKC08-12D15
FKC08-24S33
FKC08-24S05
FKC08-24S12
FKC08-24S15
FKC08-24D05
FKC08-24D12
FKC08-24D15
FKC08-48S33
FKC08-48S05
FKC08-48S12
FKC08-48S15
FKC08-48D05
FKC08-48D12
FKC08-48D15
Input
Range
9 ~ 18 VDC
9 ~ 18 VDC
9 ~ 18 VDC
9 ~ 18 VDC
9 ~ 18 VDC
9 ~ 18 VDC
9 ~ 18 VDC
18 ~ 36 VDC
18 ~ 36 VDC
18 ~ 36 VDC
18 ~ 36 VDC
18 ~ 36 VDC
18 ~ 36 VDC
18 ~ 36 VDC
36 ~ 75 VDC
36 ~ 75 VDC
36 ~ 75 VDC
36 ~ 75 VDC
36 ~ 75 VDC
36 ~ 75 VDC
36 ~ 75 VDC
Output
Voltage
3.3 VDC
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
3.3 VDC
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
3.3 VDC
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
Output Current
Output
Min. load Full load Ripple & Noise
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
2000mA
1500mA
666mA
533mA
± 800mA
± 333mA
± 267mA
2000mA
1500mA
666mA
533mA
± 800mA
± 333mA
± 267mA
2000mA
1500mA
666mA
533mA
± 800mA
± 333mA
± 267mA
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
50mVp-p
No load
Input Current
10mA
15mA
13mA
20mA
15mA
20mA
20mA
10mA
30mA
13mA
15mA
15mA
15mA
13mA
7mA
8mA
10mA
10mA
8mA
8mA
7mA
(2)
Eff
(%)
80
83
88
87
83
87
85
80
83
86
85
82
86
85
80
83
86
86
85
87
87
(3)
Capacitor
Load max
3300µF
1600µF
350µF
240µF
± 1000µF
± 160µF
± 100µF
3300µF
1600µF
350µF
240µF
± 1000µF
± 160µF
± 100µF
3300µF
1600µF
350µF
240µF
± 1000µF
± 160µF
± 100µF
(4)
Note
BELLCORE TR-NWT-000332. Case 1: 50% Stress, Temperature at 40ºC.
MIL-HDBK-217F Notice2 @Ta=25 ºC, Full load(Ground, Benign, controlled environment).
2. Typical value at nominal input voltage and no load.
3. Typical value at nominal input voltage and full load.
4. Test by minimum input and constant resistive load.
5. The ON/OFF control pin voltage is referenced to –INPUT.
6. The FKC08 series standard module meets EN55022 Class A and Class B with external components.
For more detail information, please contact with P-DUKE.
7. An external input filter capacitor is required if the module has to meet EN61000-4-4, EN61000-4-5.
The filter capacitor Power Mate suggest: Nippon chemi-con KY series, 220µF/100V.
CAUTION:
This power module is not internally fused. An input line fuse must always be used.
1.
Page 2 of 3
www.pduke.com
2013/6/4
