REVISION J
**ONLY AVAILABLE TO EXISTING CUSTOMERS**
"D"
"E"
"F"
0.50 .020
ZHR5-XX-XX-X-RA-K-TR
PACKING OPTION
-TR: TAPE & REEL
OPTION
-K: POLYIMIDE FILM PAD
(SEE FIG 4, SHT 2)
(SEE NOTE 6)
(USE K-DOT-157X275-283-005)
ORIENTATION
-RA: RIGHT ANGLE
DESIGNED & DIMENSIONED
IN MILLIMETERS[INCHES]
DO NOT
SCALE FROM
THIS PRINT
No OF POSITIONS
(PER ROW)
-20: 20 POS
-30: 30 POS
-40: 40 POS
-50: 50 POS
LEAD STYLE
-02: CONTACT ON TOP
AND BOTTOM
PLATING
*-T: 100-250u" TIN ALL OVER
-F: 3u" Au ON THE CONTACT AREA,
FLASH GOLD ON THE TAIL
(* = NOT RELEASED FOR PRODUCTION)
POSITION #1
INDICATOR
"G" REF
C
"A"
L
9.90 .390
C
0.10[.004]
"A"
0.50 .020 REF
"B" REF
"A" REF
"C" REF
02
04
40
14.06 .554 REF
3.95 .156
1.65 .065
1.10 .043 REF
7.90 .311
REF
0.85 .033
1.40 .055
0.18 .007 REF
1.32 .052
REF
9.40 .370
REF
3.55 .140
REF
7.10 .280
REF
NOTES:
FLEX LOCKING KEY
ZHR5-20-02-X-RA-TR
FLEX LOCKED SHOWN
FIG 3
1.32 .052
5.81 .229
FIG 2
REF
CAM OPENED SHOWN
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN MM [IN].
TOLERANCES ARE:
DECIMALS
8.30 .327
REF
1. C REPRESENTS A CRITICAL DIMENSION.
2. MINIMUM PUSHOUT FORCE: 2.22N[.5 LB].
3. PARTS TO BE PACKAGED IN TAPE AND REEL AS STANDARD
4. FOR QUANTITIES UP TO 49 PIECES, NO LEADER, TRAILER OR
REEL WILL BE SUPPLIED.
FOR QUANTITIES OF 50-124, NO LEADER OR TRAILER WILL BE SUPPLIED.
5. PARTS TO BE SHIPPED WITH CAM IN THE OPENED POSITION.
6. LEAVE BLANK FOR NO K-DOT. ONLY AVAILABLE TO EXISTING CUSTOMERS
AS OF REVISION G.
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
0.20 .008
01
03
ZHR5-20-02-X-RA-TR SHOWN
FIG 1
39
X.X: 0.3 [.01]
2
X.XX: 0.13 [.005]
X.XXX: 0.051 [.0020]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
INSULATOR: LCP, COLOR: NATURAL
CAM: LCP, COLOR: BLACK
CONTACT: PHOS BRONZE
SHIELD: BRASS
MAX FLASH ALLOWED: .05[.002]
MAX GATE VESTIGE: .05[.002]
DO NOT SCALE DRAWING
SHEET SCALE: 4:1
0.5mm FPC CONN, ZIF,HS, RUGGED
ZHR5-XX-XX-X-RA-K-TR
04/01/2009
SHEET
1
OF
2
F:\DWG\MISC\MKTG\ZHR5-XX-XX-X-RA-K-TR-MKT.SLDDRW
BY:
CLAY W
REVISION J
C
0.40±0.08 .016±.003
(FILL C-285-01-X TOP CONTACT)
C-285-01-X
ZHR5-XX-RA-02
IN-PROCESS 1
C
0.25
- 0.10
.010
- .0039
0.10[.004]
+0.05
+.0020
C
0.15 .006
C
SECTION "A"-"A"
(FILL C-264-01-X BOTTOM CONTACT)
C-264-01-X
C
0.45±0.08 .0177±.003
C
IN-PROCESS 2
'C'
0.40±0.08 .016±.003
0.10[.004]
0.15 .006
3.99 .157
REF
C
C
0.635 .025
.25 [.010]
6.99 .275 REF
"H" .25 [.010]
(ASSEMBLE ZHR5-XX-RA-02-CAM)
(CAM TO BE BUILT IN OPEN POSITION)
IN-PROCESS 3
FIG 4
-K: POLYIMIDE FILM PAD OPTION
(SHOWN: ZHR5-XX-XX-X-RA-K)
ZHR5-XX-RA-02-CAM
C
(ASSEMBLE SHIELD SH28-XX-X)
(CAM TO BE BUILT IN OPEN POSITION)
IN-PROCESS 4
DETAIL 'C'
SCALE 8 : 1
F:\DWG\MISC\MKTG\ZHR5-XX-XX-X-RA-K-TR-MKT.SLDDRW
0.00±0.03 .000±.001
(DISTANCE FROM TOP ROW
TO BOTTOM ROW)
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
SH28-XX-X
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 4:1
0.5mm FPC CONN, ZIF,HS, RUGGED
ZHR5-XX-XX-X-RA-K-TR
04/01/2009
SHEET
2
OF
2
BY:
CLAY W
