LC877132A: DescriptionMicrocontroller, 8-Bit, MROM, 10MHz, CMOS, PQFP80, LEAD FREE, QFP-80; CategoryThe embedded processor and controller Microcontrollers and processors; File Size523KB，26 Pages; ManufacturerSANYO; Websitehttp://www.semic.sanyo.co.jp/english/index-e.html

Download Datasheet Parametric View All

LC877132A Overview

Microcontroller, 8-Bit, MROM, 10MHz, CMOS, PQFP80, LEAD FREE, QFP-80

LC877132A Parametric

Parameter Name	Attribute value
Maker	SANYO
Parts packaging code	QFP
package instruction	QFP,
Contacts	80
Reach Compliance Code	unknown
Has ADC	YES
Other features	ALSO AVAILABLE IN TQFP80 PACKAGE; ALSO OPERATES AT 2.5V MINIMUM SUPPLY
Address bus width
bit size	8
maximum clock frequency	20 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	S-PQFP-G80
Number of I/O lines	67
Number of terminals	80
Maximum operating temperature	70 °C
Minimum operating temperature	-30 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	QFP
Package shape	SQUARE
Package form	FLATPACK
Certification status	Not Qualified
ROM programmability	MROM
speed	10 MHz
Maximum supply voltage	6 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	OTHER
Terminal form	GULL WING
Terminal location	QUAD
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

LC877132A Preview

CMOS IC

LC877148A/40A/32A/24A

8-Bit Single Chip Microcontroller

LC877148A

8 bit Single Chip Microcontroller incorporating 48KB ROM and 1536 byte RAM on chip

LC877140A

8 bit Single Chip Microcontroller incorporating 40KB ROM and 1536 byte RAM on chip

LC877132A

8 bit Single Chip Microcontroller incorporating 32KB ROM and 1536 byte RAM on chip

LC877124A

8 bit Single Chip Microcontroller incorporating 24KB ROM and 1536 byte RAM on chip

Overview

The LC877148A, LC877140A LC877132A and LC877124A are 8-bit single chip microcontrollers with the

following on-chip functional blocks :

- CPU: operable at a minimum bus cycle time of 100 ns

- On-chip ROM Maximum Capacity : LC877148A 48K bytes

LC877140A 40K bytes

LC877132A 32K bytes

LC877124A 24K bytes

- On-chip RAM capacity: 1536 bytes

- LCD controller / driver

- 16 bit timer / counter (can be divided into 8 bit timer)

- 16 bit timer (can be divided into 8 bit timers,

8-bit timer can be PWM)

- Four 8-bit timer with prescalers

- Timer for use as date / time clock

- Synchronous serial I/O port (with automatic block transmit / receive function)

- Asynchronous / synchronous serial I/O port

Two sets of 12-bit PWM.

- 12-channel × 8-bit AD converter

Ver:1.05

M2003

May 20, 2003

Kubota

1/26

LC877148A/40A/32A/24A

Small signal detector

High-speed clock counter

System clock divider

19-source 10-vectored interrupt system

Features

(1) Read-Only Memory (ROM)

- 49152 × 8 bits (LC877148A)

- 40960 × 8 bits (LC877140A)

- 32768 × 8 bits (LC877132A)

- 24576 × 8 bits (LC877124A)

(2) Random Access Memory (RAM): 1536 × 9 bits (LC877148A, LC877140A, LC877132A, LC877124A)

(3) Minimum Bus Cycle Time: 100 ns (10 MHz)

Note: The bus cycle time indicates ROM read time.

(4) Minimum Instruction Cycle Time (tCYC) : 300 ns (10MHz)

(5) Ports

- Input/output ports

Data direction programmable for each bit individually :

Data direction programmable in nibble units :

(When N-channel open drain output is selected, data can

- Input ports :

- Output ports :

- LCD ports

Segment output :

Common output :

Bias terminals for LCD driver

Other functions

Input/output ports :

Input ports :

- Oscillator pins :

- Reset pin :

- Power supply :

20 (P1n, P70-P73, P8n)

8 (P0n)

be input in bit units.)

2 (XT1,XT2)

2(PWM2,PWM3)

32 (S00-S15,S24-S39)

4 (COM0-COM3)

3 (V1-V3)

32(PAn,PBn,PDn,PEn)

7 (PLn)

2 (CF1,CF2)

1 (

RES

)

6 (VSS1-3,VDD1-3)

(6) LCD controller

- Seven display modes are available (static, 1/2, 1/3, 1/4 duty × 1/2, 1/3 bias)

- Segment output and common output can be switched to general purpose input/output ports.

(7) Small signal detection (MIC signals etc)

- Counts pulses with the level which is greater than a preset value

- 2 bit counter

2/26

LC877148A/40A/32A/24A

(8) Timers

- Timer 0: 16 bit timer / counter with capture register

Mode 0: 2 channel 8-bit timer with programmable 8 bit prescaler and 8 bit capture register

Mode 1: 8 bit timer with 8 bit programmable prescaler and 8 bit capture register + 8 bit

Counter with 8-bit capture register

Mode 2: 16 bit timer with 8 bit programmable prescaler and 16 bit capture register

Mode 3: 16 bit counter with 16 bit capture register

- Timer 1: PWM / 16 bit timer with toggle output function

Mode 0: 2 channel 8 bit timer with 8-bit prescaler (with toggle output)

Mode 1: 2 channel 8 bit PWM with 8-bit prescaler

Mode 2: 16 bit timer with 8-bit prescaler (with toggle output) Toggle output from lower 8 bits is

also possible.

Mode 3: 16 bit timer with 8-bit prescaler (with toggle output) Lower order 8 bits can be used as

PWM.

- Timer 4: 8-bit timer with 6-bit prescaler

- Timer 5: 8-bit timer with 6-bit prescaler

- Timer 6: 8-bit timer with 6-bit prescaler(with toggle output)

- Timer 7: 8-bit timer with 6-bit prescaler(with toggle output)

- Base Timer

1) The clock signal can be selected from any of the following :

Sub-clock (32.768kHz crystal oscillator), system clock, and prescaler output from timer 0

2) Interrupts of five different time intervals are possible.

(9) High-speed clock counter

- Countable up to 20 MHz clock (when using 10MHz main clock)

- Real time output

(10) Serial-interface

- SIO 0: 8 bit synchronous serial interface

1) LSB first / MSB first is selectable

2) Internal 8 bit baud-rate generator (fastest clock period 4 / 3 Tcyc)

3) Consecutive automatic data communication (1-256 bits)

- SIO 1: 8 bit asynchronous / synchronous serial interface

Mode 0: Synchronous 8 bit serial IO (2-wire or 3-wire, transmit clock 2–512 Tcyc)

Mode 1: Asynchronous serial IO (half duplex, 8 data bits, 1 stop bit, baud rate 8–2048Tcyc)

Mode 2: Bus mode 1 (start bit, 8 data bits, transmit clock 2–512 Tcyc)

Mode 3: Bus mode 2 (start detection, 8 data bits, stop detection)

(11) AD converter

-8 bits × 12 channels

(12) PWM

Two sets of 12-bit Periodic variable PWM

(13) Remote control receiver circuit (connected to P73 / INT3 / T0IN terminal)

-Noise rejection function (noise rejection filter’s time constant can be selected from 1 / 32 / 128 Tcyc)

(14) Watchdog timer

- The watching time period is determined by an external RC.

- Watchdog timer can produce interrupt or system reset

3/26

LC877148A/40A/32A/24A

(15) Interrupts: 19 sources, 10 vectors

1) Three priority (low, high and highest) multiple interrupts are supported. During interrupt handling,

an equal or lower priority interrupt request is postponed.

2) If interrupt requests to two or more vector addresses occur at once, the higher priority interrupt takes

precedence. In the case of equal priority levels, the vector with the lowest address takes

precedence.

No.

• Priority

Vector

Selectable Level

00003H

X or L

0000BH

X or L

00013H

H or L

0001BH

H or L

00023H

H or L

0002BH

H or L

00033H

H or L

0003BH

H or L

00043H

H or L

0004BH

H or L

Level : X > H > L

Interrupt signal

INT0

INT1

INT2/T0L

INT3/Base timer

T0H

T1L/T1H

SIO0

SIO1

ADC/MIC/T6/T7

Port 0/T4/T5/PWM2,3

• For equal priority levels, vector with lowest address takes precedence.

(16) Subroutine stack levels: 768 levels max.

(17) Multiplication and division

- 16 bit × 8 bit (executed in 5 cycles)

- 24 bit × 16 bit (12 cycles)

- 16 bit ÷ 8 bit (8 cycles)

- 24 bit ÷ 16 bit (12 cycles)

Stack is located in RAM.

(18) Oscillation circuits

- On-chip RC oscillation for system clock use.

- CF oscillation for system clock use. (Rf built in, Rd external)

- Crystal oscillation low speed system clock use. (Rf built in, Rd external)

- On-chip frequency variable RC oscillation circuit for system clock use.

(19) System clock divider

- Low power consumption operation is available

- Minimum instruction cycle time (300ns, 600ns, 1.2µs, 2.4µs, 4.8µs, 9.6µs, 19.2µs, 38.4µs, 76.8µs can

be switched by program (when using 10MHz main clock)

(20) Standby function

- HALT mode

HALT mode is used to reduce power consumption. During the HALT mode, program execution

is stopped but peripheral circuits keep operating (some parts of serial transfer operation stop.)

1) Oscillation circuits are not stopped automatically.

2) Released by the system reset or interrupts.

4/26

LC877148A/40A/32A/24A

-HOLD mode

HOLD mode is used to reduce power consumption. Program execution and peripheral circuits

are stopped.

1) CF, RC and crystal oscillation circuits stop automatically.

2) Released by any of the following conditions.

(1) Low level input to the reset pin

(2) Specified level input to one of INT0, INT1, INT2.

(3) Port 0 interrupt

-X’tal HOLD made

X’tal HOLD mode is used to reduce power consumption. Program execution is stopped.

All peripheral circuits except the base timer are stopped.

1) CF and RC oscillation circuits stop automatically.

2) Crystal oscillator operation is kept in its state at HOLD mode inception.

3) Released by any of the following conditions

(1) Low level input to the reset pin

(2) Specified level input to one of INT0, INT1, INT2.

(3) Port 0 interrupt

(4) Base-timer interrupt

(21) Package

- QFP80

- TQFP80

『Lead

Free Product』

(22) Development tools

- Evaluation chip : LC876091

- Emulator: EVA62S + ECB876600C (Evaluation chip board) + SUB877100 + POD80QFP(14×14) or

POD80SQFP

: ICE-B877300 + SUB877100 + POD80QFP(14×14)or POD80SQFP

- Flash ROM version: LC87F71C8A

5/26
