WA06W3301FBL datasheet, PDF - EEWORLD Datasheet

WA06W3301FBL: DescriptionArray/Network Resistor, Isolated, 0.0625W, 3300ohm, 50V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 1606, CHIP, ROHS COMPLIANT; CategoryPassive components The resistor; File Size590KB，9 Pages; ManufacturerWalsin Technology Corporation; Environmental Compliance

Download Datasheet Parametric View All

WA06W3301FBL Overview

Array/Network Resistor, Isolated, 0.0625W, 3300ohm, 50V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 1606, CHIP, ROHS COMPLIANT

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Walsin Technology Corporation
package instruction	CHIP, ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	LASER TRIMMABLE, RATED AC VOLTAGE(V): 50
structure	Chip
The first element resistor	3300 Ω
JESD-609 code	e3
Manufacturer's serial number	WA06
Installation features	SURFACE MOUNT
Network Type	ISOLATED
Number of components	1
Number of functions	8
Number of terminals	16
Maximum operating temperature	155 °C
Minimum operating temperature	-55 °C
Package height	0.45 mm
Package length	4 mm
Package shape	RECTANGULAR PACKAGE
Package form	SMT
Package width	1.6 mm
method of packing	BULK
Rated power dissipation(P)	0.0625 W
Rated temperature	70 °C
resistance	3300 Ω
Resistor type	ARRAY/NETWORK RESISTOR
series	WA06W
size code	1606
surface mount	YES
Temperature Coefficient	200 ppm/°C
Terminal surface	Tin (Sn)
Terminal shape	WRAPAROUND
Tolerance	1%
Operating Voltage	50 V

Approval sheet

WA04, WA06

1%,

5%, Convex Type & Concave Type

General purpose chip resistors array

Size 0402x2 (4p2R)

Size 0402x4, 0603x4 (8p4R)

Size 0602x8 (16p8R)

*Contents in this sheet are subject to change without prior notice.

Page 1 of 9

ASC_WA04/06_V15

Oct.2010
