NPN PLASTIC POWER TRANSISTOR
CDL13005R
TO-220
Plastic Package
For Lead Free Parts, Device
Part # will be Prefixed with
"T"
Used in Energy Saving Lights and Power Switch Circuits
ABSOLUTE MAXIMUM RATINGS
DESCRIPTION
Collector Base Voltage
Collector Emitter Voltage
Emitter Base Voltage
Collector Current Continuous
Power Dissipation upto T
a
=25ºC
Power Dissipation upto T
c
=25ºC
Operating And Storage Junction
Temperature Range
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
P
D
P
D
T
j,
T
stg
VALUE
700
400
9
4
2
75
- 55 to +150
UNIT
V
V
V
A
W
W
ºC
ELECTRICAL CHARACTERISTICS (T
c
=25ºC unless specified otherwise)
DESCRIPTION
SYMBOL
TEST CONDITION
I
CBO
V
CB
=700V, I
E
=0
Collector Cut Off Current
V
EB
=9V, I
C
=0
I
EBO
Emitter Cut Off Current
*h
FE
I
C
=1A, V
CE
=5V
DC Current Gain
Ratio Between h
FE1
of Low Current and
h
FE1
I
C
=5mA, V
CE
=5V
h
FE1
/h
FE2
h
FE2
I
C
=1A, V
CE
=5V
h
FE2
of High Current
Collector Emitter Saturation Voltage
Base Emitter Saturation Voltage
Transition Frequency
Switching Time
DESCRIPTION
Fall Time
Storage Time
*h
FE
Classification
Marking
Product is pre-selected in DC Current
Gain (Groups A to E). CDIL reserves the
right to ship any of the group(s) to
customers depending on production
availability.
XX=date code
*Pulse Test t
p
< 300µs, Duty Cycle < 2%
µ
CDL13005RRev040706D
MIN
TYP
10
0.75
MAX
0.1
0.1
50
UNIT
mA
mA
*V
CE (sat)
*V
BE (sat)
f
T
I
C
=2A, I
B
=0.5A
I
C
=2A, I
B
=0.5A
V
CE
=10V, I
C
=500mA, f=1MHz
5
0.6
1.5
V
V
MHz
SYMBOL
t
f
t
s
TEST CONDITION
I
C
=2A, I
B1
= -1
B2
=0.4A
V
CC
=120V
A : 10 - 21
CDL
13005R
A XX
B : 20 - 31
CDL
13005R
B XX
MIN
TYP
MAX
0.8
3.6
UNIT
µs
µs
C : 30 - 41
CDL
13005R
C XX
E : 40 - 50
CDL
13005R
E XX
