P6DG-xxxxELF
PM4-SERIES
Rev.11-2008
1 Watt
Regulated
Single
Output
DIP14
Case
1 kV
DC I/O Isolation
Low Ripple and Noise
Mainzer Straße 151–153
D-55299 Nackenheim
Tel. +49 6135 7026-0
Fax: +49 6135 931070
www.peak-electronics.de
peak@peak-electronics.de
The PM4 series P6DG-xxxxELF is a family of cost effective 1 W regulated
single output DC/DC converters. These converters are in an ultra miniature
DIP14 case. Devices are encapsulated. High performance features:
Regulated Output, 1000VDC input/output isolation, high efficiency
operation, output voltage accuracy of ±2% maximum, input range of ±10%
tolerance and low output ripple and noise.
All specifications typical at Ta=25° nominal input voltage and full load unless otherwise specified
C,
Input Specifications
Voltage Range
Input Filter
Input Reflected Ripple Current¹
Output Specifications
Voltage Accuracy
Short Circuit Protection
Line Regulation
Load Regulation
(0% - 100%)
Ripple and Noise
(20Mhz bandwidth)
Temperature Coefficient
General Specifications
Efficiency
I/O Isolation Voltage
(3 sec.)
I/O Isolation Capacity
I/O Isolation Resistance
Switching Frequency
Humidity
Reliability Calculated MTBF
(MIL-HDBK-217F)
Physical Specifications
Case Material
Potting Material
Weight
Environment Specifications
Operating Temperature
Maximum Case Temperature
Storage Temperature
Cooling
RoHS Conform
± 10%
Capacitors
20 mA pk-pk
± 2%
Short Term
± 0.5%
± 0.5% (3.3Vout Models: ± 1.0%)
50 mV pk-pk
± 0.02% / °
C
See Table
1000 VDC
60 pF, typ.
1000 M Ohm
50 kHz
(Variable)
95% rel H
> 4.261 Mhrs
Non Conductive Black Plastic
(UL94V-0 rated)
Epoxy
(UL94V-0 rated)
~ 2.7g, typ.
-40 to +85°
(ambient)
C
100°
C
-40 to +125°
C
Free Air Convection
Soldering 260° max.
(1.5mm from case 10s.)
C,
PM4-Series – P6DG-xxxxELF – Single Output – DIP14 – Plastic Case
Specification can change without a notice – We accept no liability for any inaccuracy or printing errors.
Page 1/3
Selection Guide
Single
Output
)
)
mA)
(mA ad (mA
ad (
)
o
d
Lo
DC
C)
Loa
ull L
uF)²
(VD
e (V
No
F u ll
)
nt F
ad (
g
t
t
e
urre
o lta
y (% citor Lo
rren
rre n
ltag
ut V
ut C
ienc
t Vo
t Cu put Cu
a
p
p
Inpu
In p u
In
O ut
O ut
E ffic
Cap
Order #
SINGLE OUTPUT
P6DG-053R3ELF
P6DG-0505ELF
P6DG-057R2ELF
P6DG-0509ELF
P6DG-0512ELF
P6DG-0515ELF
P6DG-123R3ELF
P6DG-1205ELF
P6DG-127R2ELF
P6DG-1209ELF
P6DG-1212ELF
P6DG-1215ELF
P6DG-243R3ELF
P6DG-2405ELF
P6DG-247R2ELF
P6DG-2409ELF
P6DG-2412ELF
P6DG-2415ELF
5
5
5
5
5
5
12
12
12
12
12
12
24
24
24
24
24
24
30
35
45
40
35
35
20
20
20
20
20
20
10
10
10
10
10
10
350
317
327
298
298
298
146
132
132
128
122
126
73
76
76
61
63
63
3.3
5
7.2
9
12
15
3.3
5
7.2
9
12
15
3.3
5
7.2
9
12
15
333
200
138.9
111.1
83.3
66.7
333
200
138.9
111.1
83.3
66.7
333
200
138.9
111.1
83.3
66.7
57
63
61
67
67
67
57
63
63
65
68
66
57
60
60
68
66
66
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
If you need other specifications, please enquire.
Notes:
PM4-Series – P6DG-xxxxELF – Single Output – DIP14 – Plastic Case
Specification can change without a notice – We accept no liability for any inaccuracy or printing errors.
Page 2/3
Package / Pinning / Derating
7.62
(0.30)
10.16
(0.40)
0.25
(0.01)
PIN CONNECTIONS
#
SINGLE
1
- Vin
7
N.C.
8
Omitted
9
+Vout
10
Omitted
11
- Vout
14
+Vin
others Omitted
App Notes:
¹ =
Measured Input reflected ripple current with a simulated source inductance of 12uH.
² =
Tested by minimal Vin and constant resistive load.
- Operation under no-load conditions will not damage these devices, but they will not observe the listed specifications.
PM4-Series – P6DG-xxxxELF – Single Output – DIP14 – Plastic Case
Specification can change without a notice – We accept no liability for any inaccuracy or printing errors.
Page 3/3
