DG-106010B
Model No.
Page
GW5BTJ**K03
1 of 18
GW5BTJ**K03 specifications
1. Application
These specifications apply to the light emitting diode module Model No. GW5BTJ**K03.
[ LED module (InGaN Blue LED chip + Phosphor) ]
Main application : Lighting
2. External dimensions and equivalent circuit -------------------------------- Refer to Page 2.
3. Ratings and characteristics --------------------------------------------------- Refer to Page 3 - 5.
3-1. Absolute maximum ratings
3-2. Electro-optical characteristics
3-3. Derating curve
4. Reliability ---------------------------------------------------------------------- Refer to Page 6.
4-1. Test items and test conditions
4-2. Failure criteria
5. Quality level ------------------------------------------------------------------- Refer to Page 7.
5-1. Applied standard
5-2. Sampling inspection
5-3. Inspection items and defect criteria
6. Supplements------------------------------------------------------------------- Refer to Page 8 - 14.
6-1. Chromaticity rank table
6-2. Packing
6-3. Label
6-4. Indication printed on product
7. Precautions -------------------------------------------------------------------- Refer to Page 15 - 17.
8. Characteristics diagram (TYP.) ---------------------------------------------- Refer to Page 18.
