P8GG-xxxxE(Hxx)LF
PMF-SERIES
Rev.02-2009
1.5 Watt
Regulated
Single
Output
SIP 12
Case
1 kV
up to
5.2kV
DC I/O Isolation
Cont. Short Circuit Protection
Mainzer Straße 151–153
D-55299 Nackenheim
Tel. +49 6135 7026-0
Fax: +49 6135 931070
www.peak-electronics.de
peak@peak-electronics.de
The PMF series P8GG-xxxxE(Hxx)LF is a family of cost effective 1.5 W
regulated single output DC/DC converters. These converters are in an ultra
miniature SIP12 case. Devices are encapsulated. High performance
features: Regulated Output, 1000VDC up to 5200VDC input/output
isolation, high efficiency operation, output voltage accuracy of ±2%
maximum and input range of ±10% tolerance.
All specifications typical at Ta=25° nominal input voltage and full load unless otherwise specified
C,
Input Specifications
Voltage Range
Input Filter
Input Reflected Ripple Current¹
Output Specifications
Voltage Accuracy
Short Circuit Protection
Line Regulation
Load Regulation
(0% - 100%)
Ripple and Noise
(20Mhz bandwidth)
Temperature Coefficient
General Specifications
Efficiency
I/O Isolation Voltage
(3 sec.)
I/O Isolation Capacity
I/O Isolation Resistance
Switching Frequency
Humidity
Reliability Calculated MTBF
(MIL-HDBK-217F)
Physical Specifications
Case Material
Potting Material
Weight
Environment Specifications
Operating Temperature
Maximum Case Temperature
Storage Temperature
Cooling
RoHS Conform
± 10%
Capacitors
20 mA pk-pk
± 2%
Indefinite
(Automatic Recovery)
± 0.5%
± 0.5% (3.3Vout Models: ± 1.5%)
75 mV pk-pk
± 0.02% / °
C
See Table
1000 VDC
(up to 5200 VDC optional*)
60 pF, typ.
1000 M Ohm
50 kHz
(typ.)
95% rel H
> 1.12 Mhrs
Non Conductive Black Plastic
(UL94V-0 rated)
Epoxy
(UL94V-0 rated)
~ 7.2g, typ.
-25 to +71°
(ambient)
C
100°
C
-40 to +125°
C
Free Air Convection
Soldering 260° max.
(1.5mm from case 10s.)
C,
PMF-Series – P8GG-xxxxE(Hxx)LF – Single Output – SIP12 - Plastic Case
Specification can change without a notice – We accept no liability for any inaccuracy or printing errors.
Page 1/3
Selection Guide
Single
Output
)
)
A)
mA
(mA ad (m
ad (
)
d
ll Lo
Lo
DC
F)²
C)
Loa
t Fu
d (u
(VD
e (V
No
Full
rren
(%)
Loa
ltag
rent
rent
tage
itor
t Vo
t Cu
ncy
Vol
Cur
Cur
t
t
t
ac
pu
pu
cie
Inpu
Inpu
Inpu
Out
Out
Effi
Cap
Order #
SINGLE OUTPUT
P8GG-053R3ELF
P8GG-0505ELF
P8GG-057R2ELF
P8GG-0509ELF
P8GG-0512ELF
P8GG-0515ELF
P8GG-0518ELF
P8GG-0524ELF
P8GG-123R3ELF
P8GG-1205ELF
P8GG-127R2ELF
P8GG-1209ELF
P8GG-1212ELF
P8GG-1215ELF
P8GG-1218ELF
P8GG-1224ELF
P8GG-243R3ELF
P8GG-2405ELF
P8GG-247R2ELF
P8GG-2409ELF
P8GG-2412ELF
P8GG-2415ELF
P8GG-2418ELF
P8GG-2424ELF
5
5
5
5
5
5
5
5
12
12
12
12
12
12
12
12
24
24
24
24
24
24
24
24
70
70
70
90
90
90
90
130
50
50
50
50
50
50
50
50
25
25
25
25
25
25
25
25
432
454
454
454
447
447
447
441
180
189
186
186
186
183
183
183
88
96
96
96
93
93
93
91
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
15
18
24
3.3
5
7.2
9
12
15
18
24
400
300
208.3
166.6
125
100
83.3
62.5
400
300
208.3
166.6
125
100
83.3
62.5
400
300
208.3
166.6
125
100
83.3
62.5
61
66
66
66
67
67
67
68
61
66
67
67
67
68
68
68
62
65
65
65
67
67
67
68
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
If you need other specifications, please enquire.
*OPTIONS:
H30 = 3000 VDC ISOLATION
H52 = 5200 VDC ISOLATION
For other I/O Isolation please see
table on the left hand side and add
“Hxx” before LF
(P8GG-2412EH52LF for
5.2kV)
Notes:
PMF-Series – P8GG-xxxxE(Hxx)LF – Single Output – SIP12 - Plastic Case
Specification can change without a notice – We accept no liability for any inaccuracy or printing errors.
Page 2/3
Package / Pinning / Derating
2.50
(0.10)
3.40
(0.13)
0.30
(0.01)
0.50
(0.02)
32.00
(1.26)
0.68
(0.03)
All dimensions are typical in millimeters (inches).
- Pin diameter: 0.5 +/-0.05 (0.02 +/-0.002)
- Pin pitch tolerance: +/-0.35 (+/-0.014)
- Case tolerance +/-0.5 (+/-0.02)
Specification may change without notice.
8.00
(0.32)
14.00
(0.55)
PEAK
Modelcode
Datecode
1
12
0.50
(0.02)
2.54
(0.10)
27.94
(1.10)
3.40
(0.13)
PIN CONNECTIONS
SINGLE
≥3kV
#
SINGLE
1 +Vin
+Vin
2 N.C.
- Vin
3 N.C.
N.C.
9 N.C.
N.C.
10 - Vout
- Vout
11 +Vout
+Vout
12 - Vin
N.C.
App Notes:
¹ =
Measured Input reflected ripple current with a simulated source inductance of 12uH.
² =
Tested by minimal Vin and constant resistive load.
PMF-Series – P8GG-xxxxE(Hxx)LF – Single Output – SIP12 - Plastic Case
Specification can change without a notice – We accept no liability for any inaccuracy or printing errors.
Page 3/3
