Top-emitting 0805 (2013)
HT-170 Series
Harvatek Surface Mount LED Data Sheet
HT-170 Series
Official Product
Tentative Product
Product: HT-170 Series
****************
MAR. 27, 2012
Version of 1.2
Data Sheet No.
HT-170 Series
Page
1/23
Specifications are subject to change without notice. Data and
drawings herein are copyrighted.
Top-emitting 0805 (2013)
HT-170 Series
DISCLAIMER............................................................................................................................3
PRODUCT SPECIFICATIONS……………………………………………………………………….4
ATTENTION: E
LECTROSTATIC
D
ISCHARGE
(ESD)
PROTECTION
...............................................5
LABEL SPECIFICATIONS.......................................................................................................6
PRODUCT CHARACTERISTICS............................................................................................11
A
BSOLUTE
M
AXIMUM
R
ATINGS
...............................................................................................11
Precaution for Use
............................................................................................................12
P
ACKAGE
O
UTLINE
D
IMENSION
...............................................................................................14
R
ECOMMENDED
S
OLDERING
P
ATTERN FOR
R
EFLOW
S
OLDERING
..............................................13
C
HARACTERISTIC
C
URVES FOR
YG, Y, D, SD
AND
UR..............................................................15
C
HARACTERISTIC
C
URVES FOR
UYG, UY, UD
AND
USD..........................................................16
C
HARACTERISTIC
C
URVES FOR
NB, NG
AND
TW....................................................................17
C
HARACTERISTIC
C
URVES FOR
A
LL
C
OLORS
(R
ADIATION
P
ATTERN
).........................................18
PACKAGING.........................................................................................................................18
T
APE
D
IMENSION
...................................................................................................................18
R
EEL
D
IMENSION
...................................................................................................................19
P
ACKING
..............................................................................................................................20
DRY PACK.............................................................................................................................21
REFLOW SOLDERING..........................................................................................................22
PRECAUTIONS.....................................................................................................................23
R
EWORKING
.........................................................................................................................23
C
LEANING
............................................................................................................................23
RELIABILITY.........................................................................................................................24
REVISION HISTORY..............................................................................................................25
Official Product
Tentative Product
Product: HT-170 Series
****************
MAR. 27, 2012
Version of 1.2
Data Sheet No.
HT-170 Series
Page
2/23
Specifications are subject to change without notice. Data and
drawings herein are copyrighted.
Top-emitting 0805 (2013)
HT-170 Series
DISCLAIMER
HARVATEK reserves the right to make changes without further notice to any products herein
to improve reliability, function or design. HARVATEK does not assume any liability arising out
of the application or use of any product or circuit described herein; neither does it convey any
license under its patent rights, nor the rights of others.
LIFE SUPPORT POLICY
HARVATEK’s products are not authorized for use as critical components in life support
devices or systems without the express written approval of the President of HARVATEK or
HARVATEK INTERNATIONAL. As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for surgical
implant into the body, or (b) support or sustain life, and (c) whose failure to perform when
properly used in accordance with instructions for use provided in the labeling, can be
reasonably expected to result in a significant injury of the user.
2. A critical component in any component of a life support device or system whose failure to
perform can be reasonably expected to cause the failure of the life support device or system,
or to affect its safety or effectiveness.
Official Product
Tentative Product
Product: HT-170 Series
****************
MAR. 27, 2012
Version of 1.2
Data Sheet No.
HT-170 Series
Page
3/23
Specifications are subject to change without notice. Data and
drawings herein are copyrighted.
Top-emitting 0805 (2013)
HT-170 Series
Product Specifications
Test
Product
Emission Color
Technology
Current
I (mA)
F
Luminous
Intensity
I (mcd)
V
Forward
Voltage
V (V)
F
Orderable
Part Number
HT-170YG-YYYY
HT-170Y-YYYY
HT-170D-YYYY
HT-170SD-YYYY
HT-170UR-YYYY
HT-170UYG-YYYY
HT-170YG
HT-170Y
HT-170D
HT-170SD
HT-170UR
HT-170UYG
Yellow Green
Yellow
Orange
Red
Bright Red
Ultra Bright
Yellow Green
Ultra Bright
Yellow
Ultra Bright
Orange
Ultra Bright Red
Blue
True Green
White
GaP
GaAsP
GaAsP
GaAsP
AlGaAs
AlInGaP
20
20
20
20
20
20
18 typ
9 typ
9 typ
14 typ
21 typ
50 typ
2.2 typ
2.1 typ
2.1 typ
2.1 typ
1.8 typ
2.0 typ
HT-170UY
AlInGaP
20
90 typ
1.9 typ
HT-170UY-YYYY
HT-170UD
AlInGaP
20
90 typ
1.9 typ
HT-170UD-YYYY
HT-170USD
HT-170NB
HT-170NG
HT-170TW
AlInGaP
InGaN
InGaN
InGaN
20
20
20
20
60 typ
80 typ
140 typ
220 typ
1.9 typ
3.3 typ
3.3 typ
3.3 typ
HT-170USD-YYYY
HT-170NB-YYYY
HT-170NG-YYYY
HT-170TW-YYYY
Official Product
Tentative Product
Product: HT-170 Series
****************
MAR. 27, 2012
Version of 1.2
Data Sheet No.
HT-170 Series
Page
4/23
Specifications are subject to change without notice. Data and
drawings herein are copyrighted.
Top-emitting 0805 (2013)
HT-170 Series
Specification
Resin
Carrier tape
Reel
Label
Packing bag
Carton
Others:
Water clear
Per EIA 481-1A specs
Per EIA 481-1A specs
HT standard
220x240mm
HT standard
Material
Epoxy resin
Conductive black tape
Conductive black
Paper
Aluminum laminated bag/ no-zipper
Paper
Quantity
4000pcs per reel
One reel per bag
Each immediate box consists of 5 reels. The 5 reels may not necessarily have the same lot number or the same
bin combinations of Iv,
λ
D
and Vf. Each reel has a label identifying its specification; the immediate box consists of
a product label as well.
ATTENTION: Electrostatic Discharge (ESD) protection
The symbol to the left denotes that ESD precaution is needed. ESD protection for
GaP and AlGaAs based chips is necessary even though they are relatively safe in
the presence of low static-electric discharge. Parts built with AlInGaP, GaN,
or/and InGaN based chips are
STATIC SENSITIVE devices.
ESD precaution must be taken
during design and assembly.
If manual work or processing is needed, please ensure the device is adequately protected
from ESD during the process.
Compliant and Certified
ISO9002, QS9000 and ISO14001 Certified
RoHS Compliant
Official Product
Tentative Product
Product: HT-170 Series
****************
MAR. 27, 2012
Version of 1.2
Data Sheet No.
HT-170 Series
Page
5/23
Specifications are subject to change without notice. Data and
drawings herein are copyrighted.
