SU12520A-32.768-G datasheet, PDF

Datasheet> All Categories > Passive components> Crystal/resonator> SU12520A-32.768-G

SU12520A-32.768-G: DescriptionParallel - Fundamental Quartz Crystal, 0.032768MHz Nom, ROHS COMPLIANT, GULLWING PACKAGE-2; CategoryPassive components Crystal/resonator; File Size1MB，1 Pages; ManufacturerSunny Electronics Corp; Websitehttp://www.sunny.co.kr; Environmental Compliance

Download Datasheet Parametric Compare View All

SU12520A-32.768-G Overview

Parallel - Fundamental Quartz Crystal, 0.032768MHz Nom, ROHS COMPLIANT, GULLWING PACKAGE-2

SU12520A-32.768-G Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	GULLWING, 2 PIN
Reach Compliance Code	unknow
Other features	BULK
Ageing	3 PPM/YEAR
Crystal/Resonator Type	PARALLEL - FUNDAMENTAL
Drive level	1 µW
frequency stability	0.0049%
frequency tolerance	20 ppm
load capacitance	12.5 pF
Installation features	SURFACE MOUNT
Nominal operating frequency	0.032768 MHz
Maximum operating temperature	60 °C
Minimum operating temperature	-10 °C
Series resistance	50000 Ω
surface mount	YES
Base Number Matches	1

Preview

Download Datasheet

View All

SU12520A-32.768-G Related Products

	SU12520A-32.768-G	SU12520A-32.768-ST&R	SU12520A-32.768-GT&R	SU12520A-32.768-S	SU12520A-75.000-S	SU12520A-75.000-ST&R	SU12520A-75.000-G	SU12520A-75.000-GT&R
Description	Parallel - Fundamental Quartz Crystal, 0.032768MHz Nom, ROHS COMPLIANT, GULLWING PACKAGE-2	Parallel - Fundamental Quartz Crystal, 0.032768MHz Nom, ROHS COMPLIANT PACKAGE-2	Parallel - Fundamental Quartz Crystal, 0.032768MHz Nom, ROHS COMPLIANT, GULLWING PACKAGE-2	Parallel - Fundamental Quartz Crystal, 0.032768MHz Nom, ROHS COMPLIANT PACKAGE-2	Parallel - Fundamental Quartz Crystal, 0.075MHz Nom, ROHS COMPLIANT PACKAGE-2	Parallel - Fundamental Quartz Crystal, 0.075MHz Nom, ROHS COMPLIANT PACKAGE-2	Parallel - Fundamental Quartz Crystal, 0.075MHz Nom, ROHS COMPLIANT, GULLWING PACKAGE-2	Parallel - Fundamental Quartz Crystal, 0.075MHz Nom, ROHS COMPLIANT, GULLWING PACKAGE-2
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to
package instruction	GULLWING, 2 PIN	ROHS COMPLIANT PACKAGE-2	GULLWING, 2 PIN	ROHS COMPLIANT PACKAGE-2	ROHS COMPLIANT PACKAGE-2	ROHS COMPLIANT PACKAGE-2	GULLWING, 2 PIN	GULLWING, 2 PIN
Reach Compliance Code	unknow	unknow	unknow	unknow	unknow	unknow	unknow	unknow
Other features	BULK	TR	TR	BULK	BULK	TR	BULK	TR
Ageing	3 PPM/YEAR	3 PPM/YEAR	3 PPM/YEAR	3 PPM/YEAR	3 PPM/YEAR	3 PPM/YEAR	3 PPM/YEAR	3 PPM/YEAR
Crystal/Resonator Type	PARALLEL - FUNDAMENTAL	PARALLEL - FUNDAMENTAL	PARALLEL - FUNDAMENTAL	PARALLEL - FUNDAMENTAL	PARALLEL - FUNDAMENTAL	PARALLEL - FUNDAMENTAL	PARALLEL - FUNDAMENTAL	PARALLEL - FUNDAMENTAL
Drive level	1 µW	1 µW	1 µW	1 µW	1 µW	1 µW	1 µW	1 µW
frequency stability	0.0049%	0.0049%	0.0049%	0.0049%	0.0049%	0.0049%	0.0049%	0.0049%
frequency tolerance	20 ppm	20 ppm	20 ppm	20 ppm	20 ppm	20 ppm	20 ppm	20 ppm
load capacitance	12.5 pF	12.5 pF	12.5 pF	12.5 pF	12.5 pF	12.5 pF	12.5 pF	12.5 pF
Installation features	SURFACE MOUNT	THROUGH HOLE MOUNT	SURFACE MOUNT	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT	SURFACE MOUNT	SURFACE MOUNT
Nominal operating frequency	0.032768 MHz	0.032768 MHz	0.032768 MHz	0.032768 MHz	0.075 MHz	0.075 MHz	0.075 MHz	0.075 MHz
Maximum operating temperature	60 °C	60 °C	60 °C	60 °C	60 °C	60 °C	60 °C	60 °C
Minimum operating temperature	-10 °C	-10 °C	-10 °C	-10 °C	-10 °C	-10 °C	-10 °C	-10 °C
Series resistance	50000 Ω	50000 Ω	50000 Ω	50000 Ω	30000 Ω	30000 Ω	30000 Ω	30000 Ω
surface mount	YES	NO	YES	NO	NO	NO	YES	YES
Base Number Matches	1	1	1	1	1	1	1	1
