PHOTOCOUPLER
PS9817A-1,-2
HIGH CMR, 10 Mbps OPEN COLLECTOR OUTPUT TYPE
8-PIN SSOP (SO-8)
−NEPOC
HIGH-SPEED PHOTOCOUPLER
DESCRIPTION
The PS9817A-1 and PS9817A-2 are active-low type high-speed photocouplers that use a GaAlAs light-emitting
diode on the input side and a photodetector IC that includes a photodiode and a signal processor on the same chip on
the output side.
The PS9817A-1 and PS9817A-2 are designed specifically for high common mode transient immunity (CMR) and
low pulse width distortion. The PS9817A-2 is suitable for high density applications.
Series−
FEATURES
• Pulse width distortion (⏐t
PHL
−t
PLH
⏐
= 35 ns MAX.)
• High common mode transient immunity (CM
H
, CM
L
=
±15
kV/
μ
s MIN.)
• 40% reduction of mounting area (5-pin SOP
×
2)
• High-speed (10 Mbps)
• High isolation voltage (BV = 2 500 Vr.m.s.)
• Open collector output
• Ordering number of tape product : PS9817A-1-F3: 1 500 pcs/reel
: PS9817A-2-F3: 1 500 pcs/reel
• Pb-Free product
• Safety standards
• UL approved: File No. E72422
• DIN EN60747-5-2 (VDE0884 Part2) approved: No. 40008347 (Option)
8
7
PS9817A-2
6 5
1. Anode1
2. Cathode1
3. Cathode2
4. Anode2
5. GND
6. V
O
2
7. V
O
1
8. V
CC
3 4
SHIELD
PIN CONNECTION
(Top View)
8
7
PS9817A-1
6 5
1. NC
2. Anode
3. Cathode
4. NC
5. GND
6. V
O
7. NC
8. V
CC
3 4
1
2
APPLICATIONS
• PDP
• FA Network
1
2
SHIELD
• Measurement equipment
TRUTH TABLE
LED
ON
OFF
Output
L
H
Document No. PN10647EJ03V0DS (3rd edition)
Date Published August 2008 NS
The mark <R> shows major revised points.
The revised points can be easily searched by copying an "<R>" in the PDF file and specifying it in the "Find what:" field.
2006, 2008
PS9817A-1,-2
PACKAGE DIMENSIONS (UNIT: mm)
5.21±0.25
8
5
6.0±0.2
1
4
3.95±0.1
3.27±0.2
0.15
+0.10
–0.05
0.1±0.1
1.27
0.4
+0.10
–0.05
0.25 M
0.5±0.3
0.10 S
2
Data Sheet PN10647EJ03V0DS
PS9817A-1,-2
<R>
MARKING EXAMPLE
SnBi PLATING
PS9817A-1
PS9817A-2
9817A-1
NL831
N
N L 8 31
No. 1 pin Mark
Initial of NEC
(Engraved mark)
Type Number
Assembly Lot
9817A-2
NL831
N
N L 8 31
No. 1 pin Mark
Initial of NEC
(Engraved mark)
Type Number
Assembly Lot
Week Assembled
Year Assembled
(Last 1 Digit)
Week Assembled
Year Assembled
(Last 1 Digit)
In-house Code
(L: Pb-Free)
Rank Code
In-house Code
(L: Pb-Free)
Rank Code
Ni/Pd/Au PLATING
PS9817A-1
PS9817A-2
9817A-1
NT831
N
N T 8 31
No. 1 pin Mark
Initial of NEC
(Engraved mark)
Type Number
Assembly Lot
9817A-2
NT831
N
N T 8 31
No. 1 pin Mark
Initial of NEC
(Engraved mark)
Type Number
Assembly Lot
Week Assembled
Year Assembled
(Last 1 Digit)
Week Assembled
Year Assembled
(Last 1 Digit)
In-house Code
(T: Pb-Free)
Rank Code
In-house Code
(T: Pb-Free)
Rank Code
Data Sheet PN10647EJ03V0DS
3
PS9817A-1,-2
<R>
ORDERING INFORMATION
Part Number
Order Number
Solder plating
specification
PS9817A-1
PS9817A-1-F3
PS9817A-2
PS9817A-2-F3
PS9817A-1-V
PS9817A-1-V-F3
PS9817A-2-V
PS9817A-2-V-F3
PS9817A-1
PS9817A-1-F3
PS9817A-2
PS9817A-2-F3
PS9817A-1-V
PS9817A-1-V-F3
PS9817A-2-V
PS9817A-2-V-F3
PS9817A-1-A
PS9817A-1-F3-A
PS9817A-2-A
PS9817A-2-F3-A
PS9817A-1-V-A
PS9817A-1-V-F3-A
PS9817A-2-V-A
PS9817A-2-V-F3-A
PS9817A-1-AX
PS9817A-1-F3-AX
PS9817A-2-AX
PS9817A-2-F3-AX
PS9817A-1-V-AX
PS9817A-1-V-F3-AX
PS9817A-2-V-AX
PS9817A-2-V-F3-AX
Pb-Free
(Ni/Pd/Au)
Pb-Free
(SnBi)
20 pcs (Tape 20 pcs cut)
Embossed Tape 1 500 pcs/reel
20 pcs (Tape 20 pcs cut)
Embossed Tape 1 500 pcs/reel
20 pcs (Tape 20 pcs cut)
Embossed Tape 1 500 pcs/reel
20 pcs (Tape 20 pcs cut)
Embossed Tape 1 500 pcs/reel
20 pcs (Tape 20 pcs cut)
Embossed Tape 1 500 pcs/reel
20 pcs (Tape 20 pcs cut)
Embossed Tape 1 500 pcs/reel
20 pcs (Tape 20 pcs cut)
Embossed Tape 1 500 pcs/reel
20 pcs (Tape 20 pcs cut)
Embossed Tape 1 500 pcs/reel
DIN EN60747-5-2
(VDE0884 Part2)
approved
(Option)
PS9817A-2
PS9817A-1
DIN EN60747-5-2
(VDE0884 Part2)
approved
(Option)
Standard products
(UL approved)
PS9817A-2
PS9817A-1
PS9817A-2
PS9817A-1
Packing Style
Safety Standards
Approval
Standard products
(UL approved)
PS9817A-2
Application Part
Number
PS9817A-1
*1
*1
For the application of the Safety Standard, following part number should be used.
4
Data Sheet PN10647EJ03V0DS
PS9817A-1,-2
ABSOLUTE MAXIMUM RATINGS (T
A
= 25°C, unless otherwise specified)
Parameter
Symbol
Ratings
PS9817A-1
Diode
Forward Current
Reverse Voltage
Detector
Unit
PS9817A-2
15
5
7
7
25
40
*2
I
F
V
R
V
CC
V
O
I
O
*3
20
*1
mA/ch
V/ch
V
V/ch
mA/ch
mW/ch
Vr.m.s.
°C
°C
Supply Voltage
Output Voltage
Output Current
Power Dissipation
P
C
BV
T
A
T
stg
Isolation Voltage
*4
2 500
−40
to +85
−55
to +125
Operating Ambient Temperature
Storage Temperature
*1
Reduced to 0.3 mA/°C at T
A
= 60°C or more.
*2
Reduced to 0.1 mA/°C at T
A
= 60°C or more.
*3
Applies to output pin V
O
(collector pin). Reduced to 1.5 mW/°C at T
A
= 65°C or more.
*4
AC voltage for 1 minute at T
A
= 25°C, RH = 60% between input and output.
Pins 1-4 shorted together, 5-8 shorted together.
RECOMMENDED OPERATING CONDITIONS
Parameter
Low Level Input Voltage
High Level Input Current
Supply Voltage
Pull-up Resistance
TLL (R
L
= 1.0 kΩ, loads)
Symbol
V
FL
I
FH
V
CC
R
L
N
MIN.
0
6.3
4.5
330
10
TYP.
MAX.
0.8
12.5
5.5
4k
5
Unit
V
mA
V
Ω
Data Sheet PN10647EJ03V0DS
5
