SBR2080R
Elektronische Bauelemente
Voltage 80V
20.0 Amp Low V
F
Schottky Barrier Rectifiers
RoHS Compliant Product
A suffix of “-C” specifies halogen & lead-free
FEATURES
Low forward voltage drop
High current capability
High reliability
High surge current capability
Epitaxial construction
TO-220
B
N
D
E
M
P
A
O
MECHANICAL DATA
Case: Molded plastic
Epoxy: UL94V-0 rate flame retardant
Lead: Lead solderable per MIL-STD-202
method 208 guaranteed
Polarity: As Marked
Mounting position: Any
Weight: 2.064 grams (approximate)
H
J
K
L
Millimeter
Min.
Max.
14.22
16.51
9.65
10.67
12.50
14.75
3.56
4.90
0.51
1.45
2.03
2.92
0.31
0.76
3.5
4.5
C
G
F
REF.
J
K
L
M
N
O
P
Millimeter
Min.
Max.
0.7
1.78
0.38
1.02
2.39
2.69
2.50
3.43
3.10
4.09
8.38
9.65
0.89
1.45
L
REF.
A
B
C
D
E
F
G
H
PIN 1
PIN 3
CASE
PIN 2
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(Rating 25°C ambient temperature unless otherwise specified. Single phase half wave, 60Hz, resistive or inductive load.
For capacitive load, de-rate current by 20%.)
Parameter
Maximum Recurrent Peak Reverse Voltage
Working Peak Reverse Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
Per Leg
Per Device
Symbol
V
RRM
V
RSM
V
DC
I
F
I
FSM
V
F
I
R
C
J
R
θJC
dv / dt
T
J
T
STG
Rating
80
80
80
10
20
180
0.74
0.63
0.2
20
280
2
10000
-50~150
-65~150
Unit
V
V
V
A
A
V
mA
pF
°C
/ W
V /
μs
°C
°C
Peak Forward Surge Current, 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
Maximum Instantaneous Forward
Voltage
Maximum DC Reverse Current at Rated
DC Blocking Voltage
3
I
F
=10A, T
J
=25°C, per leg
I
F
=10A, T
J
=125°C, per leg
T
J
=25°C
T
J
=100°C
Typical Junction Capacitance
1
Typical Thermal Resistance
2
Voltage Rate Of Chance (Rated V
R
)
Operating Temperature Range T
J
Storage Temperature Range T
STG
Notes:
1. Measured at 1MHz and applied reverse voltage of 5.0V D.C.
2. Thermal Resistance Junction to Case.
3. Pulse test: 300μs pulse width, 1% duty cycle.
http://www.SeCoSGmbH.com/
Any changes of specification will not be informed individually.
26-Mar-2012 Rev. A
Page 1 of 2
SBR2080R
Elektronische Bauelemente
Voltage 80V
20.0 Amp Low V
F
Schottky Barrier Rectifiers
RATINGS AND CHARACTERISTIC CURVES
Typical Forward Characteristic
100
Typical Forward Current Derating Curve
Average Forward Current (A); per Leg
15
10
Instantaneous Forward Current (A); per Leg
10
5
125℃
100℃
0
20
50
100
150
180
1
50℃
75℃
Tc, Case Temperature (℃)
25℃
Typical Junction Capacitance
1200
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
Forward Voltage (V)
Junction Capacitance (pF)
800
400
Typical Reverse Characteristic
100
0
125℃
0
1
10
100
Revise Voltage (%)
10
100℃
Reverse Curren
t(mA)
Maximum Non- Repetitive Forward
Surge Current
180
75℃
Peak Forwad surge Current (A)
150
1
120
Tj=25℃
8.3mS Single half
Sine Wave
JEDEC Method
50℃
90
0.1
60
25℃
30
0
1
10
100
0.01
30
40
50
60
70
80
Number of Cycles at 60Hz
Reverse Voltage(V)
http://www.SeCoSGmbH.com/
Any changes of specification will not be informed individually.
26-Mar-2012 Rev. A
Page 2 of 2
