WE VALUE YOUR BUSINESS
FREE SAMPLES — FAST!
We’ll be happy to provide you with free samples for your next project. Our samples
usually ship the same day so you can evaluate our products for your next design. It’s as
simple as calling your sales rep today or using our convenient web sample request.
QUICK QUOTES
Our customer-driven sales team will provide quotes quickly, usually within hours of being contacted. Our aim is to
provide you with pricing information fast, so you can place your order and receive it on time.
CUSTOM CONNECTORS
Whether your next design requires a unique connector or just something simple like a molded-in key, Sullins is
ready to provide you with a solution to your particular design challenge. We can design a custom connector for
your project with little or no additional cost. Call our sales team today and experience the Sullins Advantage.
And, since we manufacture most of our connectors in California, we can usually have a custom product ready in
just days.
FREE CONSULTATION
Our engineering and technical teams are experts in edgecard connector and header design. We can help with
engineering consultation for a variety of connector applications and a broad range of products. Call us and utilize
our technical resources on your next design.
QUICK TURNAROUND
Your project is important to us, so fast delivery is our primary goal. Our average lead times are less than five days,
and many orders ship the same day. We strive to provide you with the best quality products in record time. Great
products, delivered fast! Our goal is to keep your project on track.
EASY PRODUCT SEARCH
Returning customer? Quickly find a product by part number by using our index on pages 127 - 131.
CONTACT US
E-mail
info@sullinscorp.com
Online
www.sullinscorp.com
Phone
toll-free 888.774.3100
international 760.744.0125
Fax
Mail
801 E. Mission Road
San Marcos, CA 92069
USA
760.744.6081
www.sullinscorp.com
|
760-744-0125
|
toll-free 888-774-3100
|
fax 760-744-6081
|
info@sullinscorp.com
1
TABLE OF CONTENTS
Sullins Edgecards
GENERAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
PART NUMBER OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
1.00 mm [.039” ] Contact Centers
15.49 mm Profile, Dip Solder/Card Extender/SMT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
21.84 mm Profile, Right Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
15.49 mm PCI Express Dip Solder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
15.49 mm PCI Express Card Extender for Straddle Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
.050” [1.27 mm] Contact Centers
.610” Profile, Dip Solder/Card Extender/SMT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
.915” Profile, Right Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
.610” Profile, [MCA] Dip Solder/Card Extender/SMT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
.915” Profile, [MCA] Right Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
.610” Profile, [PCI] Dip Solder/Card Extender/SMT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
.915” Profile, [PCI] Right Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Bi-Level, .050” [1.27 mm] / .100” [2.54 mm] Contact Centers
Bi-Level, High Density, Card Extender, Dip Solder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Bi-Level, High Density, Right Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Male Edgecards, .100” [2.54 mm] Contact Centers
.540” Profile, Male Edgecard, Dip Solder/Right Angle/Card Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
.100” [2.54 mm] Contact Centers
.431” Profile, Dip Solder/Eyelet/Right Angle for .062”[1.57] or .031”[0.79] Mating PCB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
.431” Profile, Dip Solder/Eyelet/Right Angle for .093”[2.36] Mating PCB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
.550” or .610” Profile, Press Fit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
.610” Profile, Dip Solder/Wire Wrap/Right Angle/Card Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
.610” Profile, Dip Solder/Wire Wrap/Right Angle for .093”[2.36] or .125”[3.18] Mating PCB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
.610” Profile, .400” Wide Body for .093”[2.36] Mating PCB, Dip Solder/Wire Wrap/Right Angle/Card Extender . . . . . . . . . . . . .42
.610” Profile, Dip Solder/ Wire Wrap/Right Angle [ISA] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
.690” Profile, Make Before Break Dip Solder/Card Extender/Right Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
.125” [3.18 mm] Contact Centers
.431” Profile, Dip Solder/Eyelet/Right Angle for .062”[1.57] or .031”[0.79] Mating PCB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
.610” Profile, Dip Solder/Wire Wrap/Right Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
.610” Profile, Dip Solder/Wire Wrap/Right Angle for .093”[2.36] or .125”[3.18] Mating PCB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
.150” [3.81 mm] Contact Centers
.550” Profile, Dip Solder/Wire Wrap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Bi-Level, .078” [1.98 mm] / .156” [3.96 mm] Contact Centers
Bi-Level, High Density, Right Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
.156” [3.96mm] Contact Centers
.431” Profile, Dip Solder/Eyelet/Right Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
.431” Profile, Special Body Configuration, Dip Solder/Eyelet/Right Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
.610” Profile, Dip Solder/Wire Wrap/Right Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
.610” Profile, Dip Solder/Wire Wrap/Right Angle for .093”[2.36] or .125”[3.18] Mating PCB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
.720” Profile, .045” sq../.031” x .062” Wire Wrap/Dip Solder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
.720” Profile, .045” sq. Make Before Break Wire Wrap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
2
www.sullinscorp.com
|
760-744-0125
|
toll-free 888-774-3100
|
fax 760-744-6081
|
info@sullinscorp.com
TABLE OF CONTENTS
Sullins Headers
.050” [1.27 mm] Contact Centers
.050” [1.27mm] Contact Centers, Male Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
.050”[1.27mm] Contact Centers, Female Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
.079” [2.00 mm] Contact Centers
.079” [2mm] Contact Centers, Male Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
.079”[2mm] Contact Centers, Female Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
.100” [2.54 mm] Contact Centers
.100” [2.54mm] Contact Centers, Male Breakaway Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
.100” [2.54 mm] Contact Centers, Female Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
Micro Plastics Edgecards
GENERAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
PART NUMBER OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
.100” [2.54 mm] Contact Centers
.431” Profile, Dip Solder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
.431” Profile, Card Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
.431” Profile, Eyelet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
.610” Profile, Wire Wrap & Dip Solder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
.550” Profile, .025” Square Card Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
.610” Profile, Right Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94
.610” Profile, Special 18/31 with Barrier, Dip Solder/ Wire Wrap [ISA] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
.125” [3.18 mm] Contact Centers
.431” Profile, Dip Solder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98
.431” Profile, Card Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100
.431” Profile, Eyelet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
.610” Profile, Wire Wrap & Dip Solder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
.550” Profile, .025” Square Card Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
.610” Profile, Right Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108
.150” [3.81 mm] Contact Centers
.550” Profile, .025” Square & .026” Round Dip Solder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
.156” [3.96 mm] Contact Centers
.431” Profile, Dip Solder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
.431” Profile, Card Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
.431” Profile, Eyelet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
.610” Profile, Wire Wrap & Dip Solder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
.550” Profile, .025” Square Card Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
.610” Profile, Right Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122
.720” Profile, .045” Square Wire Wrap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124
Polarizing Keys
Polarizing Keys, In Between Contact & In Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .126
Part Number Index
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
www.sullinscorp.com
|
760-744-0125
|
toll-free 888-774-3100
|
fax 760-744-6081
|
info@sullinscorp.com
3
Sullins Edgecards
GENERAL SPECIFICATIONS
RoHS COMPLIANT
All parts are currently manufactured with recommended materials to meet RoHS standards. All contacts
have 50u” of nickel underplating, and a large selection of plating options: Pure tin matte, overall gold,
or selective gold plating. For complete part number information or operating/processing temperature
parameters, visit the RoHS section of our website, or refer to page 5 of this catalog.
Sullins Edgecards
MATERIALS
Insulator
• PBT, Valox*, Thermoplastic Polyester
• PPS, Ryton*, Polyphenylene Sulfide
• PEEK, Polyetheretherketone
• PA9T, High Temperature Polyamide
• Other materials available. Consult Factory
Contacts
Phosphor Bronze (Standard), Beryllium Copper, Beryllium Nickel, Spinodal**, Brass
Plating
Gold and/or Tin over .000050” Nickel Underplate, Lead Free
UL/CUL File Number:
E64287
Cage Code:
54453
MECHANICAL
Board Insertion Force
16 oz Maximum per contact pair using .062”[1.58mm] thick steel test blade
Board Withdrawal Force
1 oz Minimum per contact pair using .062”[1.58mm] thick steel test blade
Special Insertion/Withdrawal forces available upon request
ELECTRICAL
Insulation Resistance: 5,000 Mega Ohm
Dielectric Withstanding Voltage
Contact Centers:
Voltage:
Current Rating:
Voltage Drop:
Contact Resistance:
.039”[1mm] .050”[1.27mm] .100”[2.54mm] .125”[3.18mm] .150”[3.81mm] .156”[3.96mm]
125 VDC
250 VDC
600 VDC
800 VDC
1500 VDC
1800 VDC
225 VAC
300 VAC
750 VAC
750 VAC
900 VAC
950 VAC
1 to 5 amp per contact
30 milli volt at rated current
30 milli ohm maximum at rated current
ENVIRONMENTAL
Solvent resistance:
Operating Temperature:
Perchloroethylene, Freon 113, Freon 11, Trichloroethylene
PBT
PPS
-65
0
to +130
0
C
-65
0
to +200/220
0
C***
Phosphor Bronze
Beryllium Copper
-65
0
to +125
0
C
-65
0
to +150
0
C
PEEK -65
0
to +250
0
C***
Spinodal**
-65
0
to +200
0
C
Beryllium Nickel***
-65
0
to +300
0
C
PA9T -65
0
to +150
0
C
(Continuous temperatures, higher for short duration. Contact Factory for details.)
* Or equivalent.
** Consult factory for special soldering guidelines.
*** Consult factory.
4
www.sullinscorp.com
|
760-744-0125
|
toll-free 888-774-3100
|
fax 760-744-6081
|
info@sullinscorp.com
Sullins Edgecards
PART NUMBER OPTIONS
E B M 43 D RT H - Sxxx
MATERIALS (Insulator/Contact)
E = PBT & Phosphor Bronze
OPERATING TEMPERATURE: -65°C to +125°C
PROCESSING TEMP: 260°C FOR 10 sec. MAX.
(230°C, 30 sec.)
R = PPS & Phosphor Bronze
OPERATING TEMPERATURE: -65°C to +125°C
PROCESSING TEMPERATURE: 260°C FOR 120 sec. MAX.
G = PA9T & PHOSPHOR BRONZE
OPERATING TEMPERATURE: -65°C to +125°C
PROCESSING TEMPERATURE: 260° FOR 120 sec. MAX.
H = PBT & Beryllium Copper
OPERATING TEMPERATURE: -65°C to +125°C
PROCESSING TEMP: 260°C FOR 10 sec. MAX.
(230°C, 30 sec.)
A = PPS & Beryllium Copper
OPERATING TEMPERATURE: -65°C to +150°C
PROCESSING TEMPERATURE: 260°C FOR 120 sec. MAX.
J = PA9T & Beryllium Copper
OPERATING TEMPERATURE: -65°C to +150°C
PROCESSING TEMPERATURE: 260°C FOR 120 sec. MAX.
M = White PA9T/Beryllium Copper
OPERATING TEMPERATURE: -65°C to +150°C
F = PPS & Spinodal (Consult Factory)
OPERATING TEMPERATURE: -65°C to +200°C
C = PPS & Beryllium Nickel (Consult Factory)
OPERATING TEMPERATURE: -65°C to +200°C
PROCESSING TEMPERATURE: 260°C FOR 120 sec. MAX.
W = PEEK & Beryllium Nickel (Consult Factory)
OPERATING TEMPERATURE: -65°C to +250°C
N = Nylon 6T & Phosphor Bronze
OPERATING TEMPERATURE: -10
0
C to +85
0
C
PROCESSING TEMPERATURE: 260
0
C for 10 sec. MAX.
MODIFICATION CODE
(Consult Factory)
OMIT FOR STANDARD
MOUNTING STYLE
H = Clearance Holes, .125” [3.18mm] Dia
N = No Mounting
S = Side Mounting, .125” [3.18mm] Dia
I
= #4-40 Threaded Insert
F = Floating Bobbin
W = .430” Ears, Flush Mounting, .125” [3.18mm] Dia
D = .250” Ears, Flush Mounting, .125” [3.18mm] Dia
P = Clearance Holes, .142” [3.61mm] Dia.
B = Open Card Slot
X = .430” Ears, Flush Mounting, #4-40 Threaded Insert
T = .250” Ears, Flush Mounting, #4-40 Threaded Insert
Q = Straddle Mount
Z = .250” Ears, Flush, Side Mounting
Sullins Edgecards
TERMINATION TYPE
Card Extender
HR = .050” & 1mm Contact Centers
KR,KN = .025”[.64mm] Square Post, Cantilever
Dip Solder - High Profile
RS = .025 [.64mm] Square Tail, Loop Bellows
CS, SC = .025” [.64mm] Square Tail, Hairpin Bellows
TK = .026” [.66mm] Round Tail, Loop Bellows
CT, CW = .015” x .025” Tail, Hairpin Bellows
CK = .026” [.66mm] Round Tail, Loop Bellows
HH = 1mm [.039”] Contact Centers
HH, HL, HN = .050” Contact Centers
KS, KD = .025”[.64mm] Square Post, Cantilever
Dip Solder - Low Profile
SX, SU = Crimp to Center for Single Readout
RT, RK, RY = .140” [3.56mm] Row Spacing
RX, RF, RU, RP = .200” [5.08mm] Row Spacing
RJ = .250”[6.35mm] Row Spacing
Eyelet
RE, TE, SE = Eyelet Tail
Press Fit
.200”[5.08mm] Row Spacing .100”[2.54mm] Row Spacing
JB = .025”[.64mm] Sq. Post JF = .025”[.64mm] Sq. Post
JC = .025”[.64mm] Sq. Post JG = .025”[.64mm] Sq. Post
JW = .025”[.64mm] Sq. Post JY = .025”[.64mm] Sq. Post
JX = .025”[.64mm] Sq. Post JZ = .025”[.64mm] Sq. Post
Right Angle
RA, SA = Right Angle, Full Bellows
TA, TB, TM = Right Angle, Loop Bellows
CA, CB, CC = Right Angle, Hairpin Bellows
HA = Right Angle, .050” & 1mm Contact Centers
HB = Right Angle, .050” Contact Centers
KA, KE, KU, KJ = .025”[.64mm] Square Post, Cantilever
Surface Mount
HF = Surface Mount, .050” & 1mm Contact Centers
Wire Wrap
RM = .025”[.64mm] Square Post, Loop Bellows
CM, MC = .025” [.64mm] Square Post, Hairpin Bellows
KK = .031” [.79mm] x .062” [1.58mm] Post
KL = .031” [.79mm] x .062” [1.58mm] Post Twisted 90°
KM = .025”[.64mm] Square Post, Cantilever
WW = .045” [1.14mm] Square Post
Bi-Level Terminations
LR = Card Extender
LT = Dip Solder
KB = Right Angle
Male Edgecards
MW, MS = Dip Solder
MA, MV, MB = Right Angle
MD, MJ, MK = Right Angle
MR, MN = Card Extender
MM = Wire Wrap
CONTACT FINISH - RoHS Compliant
All platings are Lead Free and have .000050” Nickel underplate
B
C
G
Y
=
=
=
=
S =
M =
E =
E
B
K
C
A
J
M
=
=
=
=
=
=
=
Contact Surface
.000010” Gold
.000030” Gold
.000010” Gold
.000030” Gold
Contact Surface
.000010” Gold
.000030” Gold
.000100” Pure Tin, Matte
1.00mm [.039”]
.050” [1.27 mm]
.078” [1.98 mm]
.100” [2.54 mm]
.125” [3.18 mm]
.150” [3.84 mm]
.156” [3.96 mm]
Termination
.000100” Pure Tin, Matte
.000100” Pure Tin, Matte
.000005” Gold
.000005” Gold
Overall Plating
.000010” Gold
.000010” Gold
.000100” Pure Tin, Matte
CONTACT CENTERS
NUMBER OF CONTACT POSITIONS
See applicable specification page
READOUT
D
D
H
M
=
=
=
=
Dual
Dual Row/ Crimp to Center for Single Readout
Half Loaded
Male Edgecard
Sullins Electronics: Zero Lead Time
Sullins Electronics: Sullins
Underwriters Labs: UL
Ametek: Spinodal
Registered Trademarks
Sabic Innovative Plastics: Valox
Phillips 66: Ryton
Gardner-Denver Co.: Wire Wrap
RTP Compounder: PEEK
Specifications are subject to change without notice.
www.sullinscorp.com
|
760-744-0125
|
toll-free 888-774-3100
|
fax 760-744-6081
|
info@sullinscorp.com
5
京公网安备 11010802033920号
EEWORLD
