8-216894-1 Product Details
Live Product Chat
Standard Board Mount Connectors
Not reviewed for RoHS Compliance
Quick Links
Check Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
Product Highlights:
Number of Positions = 25
Receptacle
PCB Mount Angle = Vertical
Product Series = HDP-20
With Mating Connector Lock
View all Features
TE Internal Number: 8-216894-1
8-216894-1
Superseded
Search for Replacement Parts
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Additional Information:
Product Line Information
Related Products:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Number of Positions
= 25
Gender
= Receptacle
PCB Mount Angle
= Vertical
Product Series
= HDP-20
Mating Connector Lock
= With
Mating Connector Lock Type = Nuts, 4-40 UNC
PCB Retention Feature
= Yes
Shell Type
= Front Metal Shell
Shell Size
= 3
PCB Thickness (in [mm])
= 0.063 [1.60]
Grounding Indents
= Without
Grounding Straps
= Without
PCB Mount Style
= Through Hole
Color Code
= None
Sealed = No
Post Size (mm [in]) = 0.66 [.026]
Color = Black
Shell Material = Steel
Mechanical Attachment:
Panel Attachment
= Without
Boardlock Hole Diameter (mm [in]) = 3.20 [0.126]
Boardlock Material = Brass
Boardlock Plating = Tin
Female Screwlock Material = Brass
Female Screwlock Plating = Tin
Other:
Brand = AMP
Operation/Application:
Application = Standard
Industry Standards:
RoHS/ELV Compliance
= Not reviewed for ELV/RoHS compliance
Lead Free Solder Processes
= Not reviewed for lead free solder process
Contact Related Features:
Contact Mating Area Plating Material
= Gold (30)
Contact Shape = Round
Contact Base Material = Brass
Approved Standards = DIN 41652
Performance Level = Level 2
Housing Related Features:
Housing Flammability Rating = UL 94V-0
Housing Material = Polyester GF
Body Related Features:
PCB Retention Method
= Boardlock(s)
Shell Plating = Tin
Termination Related Features:
Grounding Clips
= Without
Termination Post Length (mm [in])
= 3.18 [0.125]
Solder Tail Contact Plating
= Tin
