METAL SHELL RIBBON
CONNECTOR
14, 24, 36 AND 50 POSITION, FEMALE
THRU-HOLE AND BAIL MOUNT
LR92984
E60980
P
HYSICAL
P
ROPERTIES
I
NSULATION
M
ATERIAL
:
Glass filled
thermoplastic, rated UL 94V-0
C
OLOR
:
Blue
C
ONTACT
M
ATERIAL
:
Beryllium copper: 30µ inches
minimum gold over 50µ inches nickel in contact
zone: tin-lead over nickel in termination area.
E
LECTRICAL
P
ROPERTIES
C
URRENT
R
ATING
:
1 Amp
I
NSULATION
R
ESISTANCE
:
>1000 Megohms @ 500 VDC
D
IELECTRIC
S
TRENGTH
:
>1000 VRMS (Sea Level)
E
NVIRONMENTAL
P
ROPERTIES
T
EMPERATURE
R
ATING
:
-55˚C to 125˚C
A
PPLICATION
T
OOLING
H
AND
T
OOL
use Die
B
ENCH
P
RESS
(
MANUAL
)
use Base Plate
B
ENCH
P
RESS
(
PNEUMATIC
)
use Platen
use Base Plate
779-2100
779-2172
779-3200
779-3184
779-3500XT
779-3130
779-3184
A
CCESSORIES
See pages 92-93
C
ABLE
See pages 108-120
S
TRAIN
R
ELIEF
A
DD
RSR
AFTER NUMBER
OF POSITIONS IN PART NUMBER
Ordering Information
CATALOG
NUMBER
622-14FM
622-24FM
622-36FM
622-50FM
622-14FM1
622-24FM1
622-36FM1
622-50FM1
622-14FM2
622-24FM2
622-36FM2
622-50FM2
622-14FM3
622-24FM3
622-36FM3
622 50FM3
NO. OF
POS.
14
24
36
50
14
24
36
50
14
24
36
50
14
24
36
50
A
12.95 (.510)
23.75 (.935)
36.70 (1.445)
51.82 (2.040)
12.95 (.510)
23.75 (.935)
36.70 (1.445)
51.82 (2.040)
12.95 (.510)
23.75 (.935)
36.70 (1.445)
51.82 (2.040)
12.95 (.510)
23.75 (.935)
36.70 (1.445)
51.82 (2.040)
B
22.81 (.898)
35.51 (1.398)
50.75 (1.998)
68.53 (2.698)
22.81 (.898)
35.51 (1.398)
50.75 (1.998)
68.53 (2.698)
22.81 (.898)
35.51 (1.398)
50.75 (1.998)
68.53 (2.698)
22.81 (.898)
35.51 (1.398)
50.75 (1.998)
68.53 (2.698)
DIMENSIONS IN MM (INCHES)
C
D
35.99 (1.417)
46.78 (1.842)
59.74 (2.352)
74.85 (2.947)
35.99 (1.417)
46.78 (1.842)
59.74 (2.352)
74.85 (2.947)
35.99 (1.417)
46.78 (1.842)
59.74 (2.352)
74.85 (2.947)
35.99 (1.417)
46.78 (1.842)
59.74 (2.352)
74.85 (2.947)
39.12 (1.540)
54.99 (2.165)
67.94 (2.675)
83.06 (3.270)
39.12 (1.540)
54.99 (2.165)
67.94 (2.675)
83.06 (3 270)
39.12 (1.540)
54.99 (2.165)
67.94 (2.675)
83.06 (3.270)
39.12 (1.540)
54.99 (2.165)
67.94 (2.675)
83.06 (3.270)
F
.142 ± .003 Ø THRU
.142 ±.003 Ø THRU
.142 ±.003 Ø THRU
.142 ± .003 Ø THRU
M3.5x0.6-6H THD
M3.5x0.6-6H THD
M3.5x0.6-6H THD
M3.5x0.6-6H THD
4-40 UNC-2B THD
4-40 UNC-2B THD
4-40 UNC-2B THD
4-40 UNC-2B THD
Bail Mount
Bail Mount
Bail Mount
Bail Mount
G
28.19 (1.110)
39.12 (1.540)
51.82 (2.040)
67.06 (2.640)
28.19 (1.110)
39.12 (1.540)
51.82 (2.040)
67.06 (2.640)
28.19 (1.110)
39.12 (1.540)
51.82 (2.040)
67.06 (2.640)
28.19 (1.110)
39.12 (1.540)
51.82 (2.040)
67.06 (2.640)
Thomas & Betts Electronics/OEM Division Tel: 901-252-5000 Fax: 901-252-1312
Dimensions shown are for reference only. Dimensions are in millimeters (inches).
