Barrier Strips
Tri-Barriers
0.375" PITCH
SERIES BC6
P
HYSICAL
P
ROPERTIES
H
OUSING
M
ATERIAL
:
Polypropylene
F
LAMMABILITY
:
UL94V-0
C
OLOR
:
Black
T
ERMINAL
T
ERMINALS
:
Bright acid tin over copper alloy
S
CREWS
:
#6-32 steel, zinc plating with clear
chromate coating. Wire clamping screw stan-
dard.
BC6 SERIES
M
ECHANICAL
P
ITCH
(T
ERMINAL
S
PACING
):
.375"
R
ECOMMENDED
PCB H
OLE
D
IA
.:
1.8mm (.073")
E
LECTRICAL
P
ROPERTIES
M
AXIMUM
C
URRENT
:
20A
O
PERATING
V
OLTAGE
:
300V
W
IRE
R
ANGE
:
12-22 AWG
O
RDERING
I
NFORMATION
E
NVIRONMENTAL
P
ROPERTIES
O
PERATING
T
EMPERATURE
R
ANGE
:
105°C max.
BC6 - P 1 08 - 08
A
A
B
C
D
Terminal Style
P=Printed
Circuit (available with 1,2,5 block style only)
T=Solder
Turret
Q=Quick
Connect
W=Solderless
Wrap
Block Style
1=Flat,
all positions filled (standard)
2=Flat,
end mounting feet with holes (required for cover
option)
3=Insulating
turret, end mounting feet with holes
(required for cover option)
4=Insulating
turret, all positions filled
5=Flat,
end positions open with mounting bushings
Screw Hardware
07=Steel
combo binder head screw
08=Steel
wire clamp combo head screw
No. of Circuits
(Not Positions)
02
to
16
circuits
B
C
Retaining Clips
Retaining Clips
clips fit around
Spring metal retaining
insulating barrel to provide permanent
insulating
Spring metal retaining clips fit around
mounting
provide permanent mounting of blocks
barrel to
of blocks to panels without
the need
without the need for
Use two
holes.
to panels
for mounting holes.
mounting
per block. Catalog #
JC/BC-Retaining.
Use two per block. Catalog # JC/BC-Retaining.
Bottom view
D
®
LR30811
E54800
Thomas & Betts Electronics/OEM Division Tel: 901-252-7766 Fax: 901-252-1312
Dimensions shown are for reference only. Dimensions are in inches.
78
Barrier Strips
Tri-Barriers
0.375" PITCH
BC6 SERIES
TERMINALS
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
A
(.375) 9,5
(.750) 19,1
(1.125) 28,6
(1.500) 38,1
(1.875) 47,6
(2.250) 57,1
(2.625) 66,7
(3.000) 76,2
(3.375) 85,7
(3.750) 95,2
(4.125) 104,8
(4.500) 114,3
(4.875) 123,8
(5.250) 133,3
(5.625) 142,9
Wire
Wrap
Insulated
W. W.
5,1
(.20)
0,8
(.032)
P. C.
Pin
L = A+
A
19,0
(.750)
19,0
(.75)
15,9
(.63)
20,3
(.80)
1,5
(.06)
1,5
(.06)
Optional End
Mounting Bushing
9,5
(.375)
Typ.
5,5
(.22)
Solder
Turret
Insulated
S. T.
6-32 Wire Clamping
Screw (Std)
1,5
(.06)
8,0
(.315)
11,5
(.46)
17,8
(.70)
14,2
(.56)
3,8
(.15)
15,5
(.61)
2,8
.11
7,9
(.31)
1,3
(.05)
0,8
Typ.
(.032)
2,8
(.11)
7,9
(.31)
Dia.
Insulated Feed-Thru
1,8
(.073)
Dia.
8,3
(.328)
Quick
Connect
Insulated
Q. C.
9,5
(.375)
Typ.
Dia.
3,8
(.150) Dia.
#6 Screw
Clearance
17,3
(.68)
18,5
(.76)
7,9
(.312)
6,3
(.25)
6,3
(.25)
PRINTED CIRCUIT BOARD MOUNTING PANEL LAYOUT
®
LR30811
E54800
Thomas & Betts Electronics/OEM Division Tel: 901-252-7766 Fax: 901-252-1312
Dimensions shown are for reference only. Dimensions are in millimeters (inches).
79
