VERTICAL CHIP TYPE ALUMINUM ELECTROLYTIC CAPACITORS

VERTICAL CHIP TYPE ALUMINUM ELECTROLYTIC CAPACITORS
RVS
Chip Type 105˚C Capacitors (height:5.5mm)
Series RVS
• Compatible with surface mounting for 5.5mm high capacitors.
• Supplied with carrier taping.
• Guarantees 1000 hours at 105˚C.
RVS
High temperature
RV2
Marking color : Black print
Specifications
Item
Category temperature range (˚C)
Tolerance at rated capacitance (%)
Performance
−55
to
+105
±20
Less than 0.01CV or 3 whichever is larger(after 2 minutes) C: Rated capacitance(µF); V: Rated voltage(V)
Rated voltage (V)
tanδ (max.)
6.3
0.30
10
0.26
16
0.22
25
0.16
35
0.13
(20˚C,120Hz)
(20˚C)
50
0.12
(20˚C,120Hz)
Rated voltage (V)
Ζ−25˚C
/
Ζ+20˚C
Impedance ratio (max.)
Ζ−40˚C
/
Ζ+20˚C
6.3
4
8
10
3
5
16
2
4
25
2
3
35
2
3
50
2
3
(120Hz)
Test time
Leakage current
Percentage of capacitance change
Tangent of the loss angle
1000 hours
The initial specified value or less
Within
±20%
of initial value
200% or less of the initial specified value
Leakage current (µA)
Tangent of loss angle
(tanδ)
Characteristics at high
and low temperature
Endurance (105˚C)
(Applied ripple current)
Shelf life (105˚C)
Applicable standards
Test time : 1000 hours; other items are the same as those for the endurance. Voltage application treatment : According to JIS C5101-1
JIS C5101-1, -18 1998 (IEC 60384-1 1992, -18 1993)
Outline Drawing
0.3MAX
A±0.2
0.4±0.2
Unit: mm
Coefficient of Frequency for Rated Ripple Current
Frequency(Hz)
Rated voltage(V)
6.3 to 16
25 to 35
50
50 . 60
0.80
0.80
0.80
120
1
1
1
1k
1.15
1.25
1.35
10k . 100k
1.25
1.40
1.50
D±0.5
B±0.2
(P)
(C)
(C)
Part numbering system (example: 16V47µF)
Environmental
item
L
W
( ): Reference size
RVS
Series code
16
Rated voltage
symbol
V
470
Rated capacitance
symbol
M
Capacitance
tolerance symbol
Additional
symbol
U—
Taping
symbol
øD
4
5
6.3
L
5.3±0.2
5.3±0.2
5.3±0.2
A
4.3
5.3
6.6
B
4.3
5.3
6.6
C
2.0
2.3
2.7
W
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
P
1.0
1.5
2.0
Former item
RVS
Series code
16
Rated voltage
symbol
V
470
Rated capacitance
symbol
M
Capacitance
tolerance symbol
Additional
symbol
Taping
symbol
• Soldering conditions and land size are described on page 14.
The taping spesifications are described on page 15.
Standard Ratings
Rated voltage(V)
Rated
capacitance(µF)
Item
0.1
0.22
0.33
0.47
1
2.2
3.3
4.7
10
22
33
47
100
Case
ø D(mm)
4
5
5
6.3
6.3
ESR
23
15
11
5.0
Rated ripple
current
Case
mArms ø D(mm)
4
21
5
30
5
36
6.3
61
10
ESR
43
20
13
9.2
Rated ripple
current
Case
mArms ø D(mm)
15
4
25
5
31
6.3
43
6.3
16
ESR
36
17
11
7.8
Rated ripple
current
Case
mArms ø D(mm)
4
16
5
28
6.3
40
6.3
47
25
ESR
57
27
12
8.0
Rated ripple
current
Case
mArms ø D(mm)
12
4
21
5
36
6.3
44
35
ESR
46
22
10
Rated ripple
current
Case
mArms ø D(mm)
4
4
4
4
4
4
4
14
5
23
6.3
50
50
ESR
1190
905
603
424
199
91
60
42
20
Rated ripple
current
mArms
2
3
4
5
7
10
12
17
26
(Note) Rated ripple current : 105˚C, 120Hz ; ESR : 20˚C, 120Hz
NOTE
Design, Specifications are subject to change without notice.
Ask factory for technical specifications before purchase and/or use.
31
CAT.No.2004/2005E(2004.10.1)
