LEADED BUILT-IN CAPACITANCE CERAMIC RESONATOR
AWCR-MD
FEATURES:
• Built-in capacitors save space & components.
• Low cost timing solution.
• Small size, Light
weight
Pb in ceramic
(exempt per RoHS 2002/95/EC Annex (7))
RoHS
Compliant
| | | | | | | | | | | | | | |
Size Varies
APPLICATIONS:
• Microprocessor clocks. • Industrial controllers.
• Electric appliances.
• General timing.
• Remote controls.
ELECTRICAL CHARACTERISTICS:
Item
Frequency Range
Resonant Impedance
Frequency Tolerance
Frequency Stability
Withstanding Voltage
Rating Voltage
(1) D.C.Voltage
(2) A.C. Voltage
Load Capacitance
Insulation Resistance
Operation Temperature
Storage Temperature
Aging Rate (Fosc)
Table 2.1
Frequency range
(MHz)
1.79 MHz - 2.99 MHz
3.00 MHz - 3.49 MHz
3.50 MHz - 3.99 MHz
12.51 MHz - 13.00 MHz
13.01 MHz - 20.00 MHz
20.01 MHz - 25.99 MHz
26.00 MHz - 60.00 MHz
Requirements
n
1.79MHz to 3.99MHz
12.51MHz to 60.00MHz
See Table 2.1
± 0.5%
±0.3% max. (-25ºC to +85ºC)
50V (DC , 1 min)
6 V.D.C. max
15 Vp-p. max
See Table 2.1
100MΩ min. (DC 10V)
-25ºC to +85ºC
-55
o
C to +85
o
C
±0.3% max. (From initial value)
Standard Load Capacitance
C1=C2 (pF)
30pF± 20%
22pF± 20%
30pF± 20%
15pF± 20%
5pF± 20%
Resonant Impedance
(Ro)(Ω ) max
Ω
80
50
30
30
30
30
30
TEST CONDITION AND TEST CIRCUIT:
OPTIONS & PART IDENTIFICATION:
AWCR - XX.XXMD - C
−
X: Ceramic Resonator
C1=C2
1.Input 2.Ground 3.Output
Frequency
Frequency in MHz
Contact ABRACON for Load
Capacitance options
Blank for Bulk pack
A for AMMO pack*
* AMMO pack lead
length 13.5mm
Parts shall be measured under a condition
(Temp.: 20±15°C, Humidity: 65±20% R.H.)
unless the standard condition (Temp: 25±3°C,
Humidity: 65±10% R.H.) is regulated to measure
ABRACON IS
ISO9001:2008
CERTIFIED
Revised: 09.15.10
