ZSPM4022-06
12V/6A Synchronous DC/DC Buck Regulator
ZSPM4022-06
Functional Diagram
Typical Applications
Servers, work stations
Routers, switches, and telecom
equipment
Base stations
Ordering Information
Product Sales Code
ZSPM4022AA1W06
ZSPM4022-06-KIT
Description
ZSPM4022-06 QFN28 5mmx6mm — Temperature range: –40C to +125C
Evaluation Kit for ZSPM4022-06, including ZSPM4022-06 Evaluation Board.
Package
7” reel with 1000 ICs
Kit
