OV9726
720p HD
product brief
Native 720p/30 fps HD Video for Portable Applications
lead free
available in
a lead-free
package
The OV9726 is a 1/6.5-inch native 720p/30 frames per
second (fps) high-definition (HD) CMOS image sensor,
designed specifically for ultra compact, high-performance
HD cameras for portable electronics. The OV9726 uses
OmniVision's proprietary 1.75-micron OmniBSI™ pixel
architecture to achieve superior low-light sensitivity
(1300 mV/lux-sec), reduced crosstalk and excellent
quantum efficiency to ensure high color fidelity and image
clarity. The sensor's short stack height of only 3.5 mm
enables the smallest available camera modules in its class,
making it an ideal choice for notebooks, netbooks,
webcams, mobile phones, portable media players (PMPs)
and other mobile entertainment devices.
OmniVision's native HD sensors offer the best available
image quality and camera performance as they do not
suffer from degradation or image artifacts due to scaling or
cropping, which is typically used to achieve HD resolution
from larger array sensors.
The OV9726 CMOS image sensor supports multiple
platform architectures and controllers with both parallel
and MIPI interfaces. It significantly reduces product
development time by allowing system designers to
leverage the same opto-electrical design across various
products and multiple market segments.
Exposure control, white balance and defective pixel
canceling are programmable through the SCCB interface. In
addition, OmniVision image sensors use proprietary sensor
technology to improve image quality by reducing or
eliminating common lighting/electrical sources of image
contamination, such as fixed pattern noise and smearing to
produce a clean, fully stable color image.
Find out more at www.ovt.com.
Applications
¬ Cellular and Picture Phones
¬ Notebooks
¬ PC Multimedia
¬ Portable Media Players (PMP)
¬ Entertainment
¬ Tablets
OV9726
Ordering Information
¬
OV09726-A40A
(color, lead-free, 40-pin CSP3)
¬
OV09726-G04A
(color, chip probing, 200 µm
backgrinding, reconstructed wafer)
Product Features
¬ MIPI and D-PHY specification (contains ¬ low operating voltage and low power
one clock lane and one data lane)
consumption for embedded portable
with a maximum of 600 Mbps
applications
data transfer rate
¬ supports down sample mode
¬ supports free-running clock
and VarioPixel®
and gated clock
¬ auto black level calibration
¬ supports global analog gain
¬ defect correction capability
¬ high sensitivity and low dark current
for low-light conditions
Product Specifications
¬
active array size:
1296 x 808
¬
max S/N ratio:
36 dB
¬
power supply:
¬
dynamic range:
70 dB @ 8x gain
- core:
1.5V
- analog:
2.8V (typical) or 3.3V (optional) ¬
maximum image transfer rate:
30 fps
- I/O:
1.8V (typical)
¬
sensitivity:
1300 mV/lux-sec
¬
power requirements:
- active:
95 mA
¬
scan mode:
progressive
- standby:
60 µA
- RESETB:
20 µA
¬
maximum exposure interval:
824 x t
ROW
¬
temperature range:
- operating:
-30°C to 70°C junction
¬
pixel size:
1.75 µm x 1.75 µm
temperature
- stable image:
0°C to 50°C junction
¬
dark current:
8 mV/sec @ 60°C
temperature
junction temperature
¬
output formats:
10-bit raw RGB data
¬
lens size:
1/6.5"
¬
lens chief ray angle:
25.7° non-linear
¬
input clock frequency:
6 ~ 27 MHz
¬
image area:
2300 µm x 1440 µm
¬
package/die dimensions:
- CSP3:
4325 µm x 3515 µm
- COB:
4340 µm x 3530 µm
Functional Block Diagram
column
sample/hold
row select
AMP
10-bit
ADC
MDP
MIPI
MDN
MCP
MCN
black level
compensation
array
gain
control
power
control
PLL
timing
generator
register
bank
GPIO control
defect pixel
correction
SCCB
slave
interface
XVCLK
RESET_B
GPIO_0
4275 Burton Drive
Santa Clara, CA 95054
USA
Version 1.3, May, 2012
Tel: + 1 408 567 3000
Fax: + 1 408 567 3001
www.ovt.com
OmniVision reserves the right to make changes to their products or to discontinue any product or
service without further notice. OmniVision and VarioPixel are registered trademarks of OmniVision
Technologies, Inc. The OmniVision logo and OmniBSI are trademarks of OmniVision Technologies, Inc.
All other trademarks are the property of their respective owners.
GPIO_1
SDA
SCL
