Disco
™
Female Disconnects, Nylon Fully Insulated
–
Expanded Wire Entry
Type DNF-FIBX
• Continuously molded design provides reliable, consistent
performance through the applicator for a high quality termination
every time
• Disconnect can be inserted and removed from the male tab without
the use of tools for lower installed cost
• Expanded wire entry designed to accommodate wire with a larger
insulation thickness
• Fully insulated design provides protection from electrical shorts
• Internal wire stop assures proper length of insertion into terminal
barrel, providing a higher quality connection
• UL Flammability UL 94V-2/HB, maximum insulation temperature
221°F (105°C)
• UL and CSA rated up to 600 V per UL 310
B1.
Cable Ties
B2.
Cable
Accessories
B3.
Stainless
Steel Ties
L
W
H
C1.
Wiring
Duct
C2.
Surface
Raceway
Part Number
DNF18205FIBX-2K
DNF18206FIBX-2K
DNF18250FIBX-2K
DNF14205FIBX-2K
DNF14206FIBX-2K
DNF14250FIBX-2K
Wire
Range
22 – 18
AWG
Color
Code
Red
Max.
Ins.
(In.)
0.210
Figure Dimensions
(In.)
L
0.87
0.87
0.93
0.87
W
0.31
0.31
0.35
0.31
0.31
0.35
H
0.22
0.22
0.22
0.22
0.22
0.22
Tab
Size
In.
0.187/0.205 x 0.032
0.187/0.205 x 0.020
0.250 x 0.032
0.187/0.205 x 0.032
0.187/0.205 x 0.020
0.250 x 0.032
mm
4.8/5.2 x 0.8
4.8/5.2 x 0.5
6.3 x 0.8
4.8/5.2 x 0.8
4.8/5.2 x 0.5
6.3 x 0.8
CA9
Series
Crimp Die
CD9-6B
CA-800/EZ
Series
Crimp Die
CD-800-6
C3.
Abrasion
Protection
Pieces
Per
Reel
2000
2000
2000
2000
C4.
Cable
Management
16 – 14
AWG
Blue
0.240
0.87
0.93
CD9-8B
CD-800-8
2000
2000
For applicator information, see page D1.143.
D1.
Terminals
Disco
™
Female Disconnects, Nylon Fully Insulated
–
Right Angle
Type DNFR-FIB
• Continuously molded design provides reliable, consistent
performance through the applicator for a high quality termination
every time
• Right angle design for use in limited space applications
• Fully insulated design provides protection from electrical shorts
• Internal wire stop assures proper length of insertion into terminal
barrel, providing a higher quality connection
• Disconnect can be inserted and removed from the male tab
without the use of tools for lower installed cost
• UL Flammability UL 94V-2/HB, maximum insulation temperature
221°F (105°C)
• UL and CSA rated up to 600 V per UL 310
D2.
Power
Connectors
D3.
Grounding
Connectors
E1.
Labeling
Systems
D
W
H
E2.
Labels
L
E3.
Pre-Printed
& Write-On
Markers
E4.
Permanent
Identification
E5.
Lockout/
Tagout
& Safety
Solutions
F.
Index
Part Number
DNFR18205FIB-KD
Wire
Range
Color
Code
Red
Max.
Ins.
(In.)
Figure Dimensions
(In.)
L
0.57
0.57
0.57
W
0.37
0.37
0.37
0.37
0.37
0.37
H
0.21
0.21
0.21
0.21
0.21
0.21
D
0.60
0.60
0.60
0.60
0.60
0.60
Tab
Size
In.
0.187/0.205 x 0.032
0.187/0.205 x 0.020
0.250 x 0.032
0.187/0.205 x 0.032
0.187/0.205 x 0.020
0.250 x 0.032
mm
4.8/5.2 x 0.8
4.8/5.2 x 0.5
6.3 x 0.8
4.8/5.2 x 0.8
4.8/5.2 x 0.5
6.3 x 0.8
CA9
Series
Crimp Die
CA-800/EZ
Series
Crimp Die
Pieces
Per
Reel
1500
1500
1500
DNFR18206FIB-KD
22 – 18
AWG
DNFR18250FIB-KD
DNFR14205FIB-KD
DNFR14206FIB-KD
16 – 14
AWG
DNFR14250FIB-KD
0.178
Blue
0.57
0.57
0.57
CD9-9C
CD-800-9
1500
1500
1500
For applicator information, see page D1.143.
Order number of pieces required, in multiples of Standard Package Quantity.
Prime items appear in
BOLD.
