ER300
THRU
ER306
3 Amp
Super Fast
Recovery Rectifier
50 to 600 Volts
DO-201AD
Features
•
•
•
•
•
•
Lead Free Finish/RoHS Compliant(Note 1) ("P" Suffix designates
RoHS Compliant. See ordering information)
•
•
•
Maximum Ratings
Superfast recovery times-epitaxial construction
Low leakage , High surge capability
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Halogen
free available upon request by adding suffix "-HF"
Operating Junction Temperature: -55°C to +150°C
Storage Temperature: -55°C to +150°C
Typical Thermal Resistance 20°C/W Junction to ambient
MCC
Device
Maximum
Maximum Maximum
Catalog
Marking
Recurrent
RMS
DC
Number
Peak Reverse
Voltage
Blocking
Voltage
Voltage
ER300
ER300
50V
35V
50V
ER301
ER301
100V
70V
100V
ER301A
ER301A
150V
105V
150V
ER302
ER302
200V
140V
200V
ER303
ER303
300V
210V
300V
ER304
ER304
400V
280V
400V
ER306
ER306
600V
420V
600V
Average Forward
Current
Peak Forward Surge
Current
Maximum
Instantaneous
Forward Voltage
ER300-302
ER303-304
ER306
Maximum DC
Reverse Current At
Rated DC Blocking
Voltage
Maximum Reverse
Recovery Time
I
F(AV)
I
FSM
3A
125A
T
A
= 55°C
8.3ms, half sine
D
A
Cathode
Mark
B
Electrical Characteristics @ 25°C Unless Otherwise Specified
D
C
V
F
0.95V
1.25V
1.70V
5µA
300µA
I
FM
= 3.0A;
T
A
= 25°C
DIMENSIONS
I
R
T
A
= 25°C
T
A
= 125°C
DIM
A
B
C
D
INCHES
MIN
.287
.189
.048
1.000
MAX
.374
.208
.052
---
MM
MIN
7.30
4.80
1.20
25.40
MAX
9.50
5.30
1.30
---
NOTE
T
rr
Typical Junction
Capacitance
C
J
35ns
I
F
=0.5A, I
R
=1.0A,
I
rr
=0.25A
35pF
Measured at
1.0MHz, V
R
=4.0V
Notes:1.High Temperature Solder Exemption Applied, see EU Directive Annex 7.
Revision: B
www.mccsemi.com
1 of 3
2013/01/01
ER300 thru ER306
RATING AND CHARACTERISTIC CURVES
MCC
TM
Micro Commercial Components
+0.5A
AVERAGE FORWARD CURRENT
(10)-AMP (10)-AAV
t
rr
0
-0.25
4.0
3.0
.375" 9.5mm LENGTH
2.0
NOTE:1.Rise Time = 7ns max.
Input Impedance = 1 megohm. 22pF
2.Rise Time = 10ns max.
Source Impedance = 50 Ohms
1.0
-1.0
SET TIME
BASE FOR
50 ns/cm
1cm
0
50
75
100
125
150
175
200
AMBIENT TEMPERATURE,
℃
Fig. 1-REVERSE RECOVERY TIME CHARACTERISTIC AND
TEST CIRCUIT DIAGRAM
Fig. 2-MAXIMUM AVERAGE FORWARD
CURRENT RATING
100
1,000
ER300 ~ ER302
INSTANTANEOUS REVERSE CURRENT,
MICROAMPERES
INSTANTANEOUS FORWARD CURRENT,
AMPERES
100
T
J
= 100
℃
ER303 ~ ER304
10
1
T
J
= 75
℃
1
ER306
1.0
T
J
= 25
℃
0.
0.1
TJ = 25
℃
PULSE WIDTH = 300uS
2% DUTY CYCLE
0.01
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
0.01
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK INVERSE VOLTAGE, VOLTS
INSTANTANEOUS FORWARD VOLTAGE, VOLTS
Fig. 3-TYPICAL REVERSE CHARACTERISTICS
PEAK FORWARD SURGE CURRENT,
AMPERES
Fig. 4-FORWARD CURRENT DERATING CURVE
100
JUNCTION CAPACITANCE, pF
200
125
75
8.3ms SINGLE HALF SINE
WAVE JEDEC METHOD
35
1
5
10
50
100
TJ = 25
f = 1.0MHz
Vsig = 50mVp-p
10
5
1
10
REVERSE VOLTAGE, VOLTS
100
NUMBER OF CYCLES AT 60Hz
Fig. 5-MAXIMUM NON-REPETITIVE SURGE CURRENT
Fig. 6-TYPICAL JUNCTION CAPACITANCE
Revision: B
www.mccsemi.com
2 of 3
2013/01/01
MCC
Micro Commercial Components
TM
Ordering Information :
Device
(Part Number)-TP
(Part Number)-AP
(Part Number)-BP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-TP-HF
Packing
Tape&Reel;
1.2Kpcs/Reel
Ammo Packing;1.2Kpcs/AmmoBox
Bulk;12Kpcs/Carton
***IMPORTANT NOTICE***
Micro Commercial Components Corp.
reserves the right to make changes without further notice to any product herein to
make corrections, modifications , enhancements , improvements , or other changes .
Micro Commercial Components
Corp .
does not assume any liability arising out of the application or use of any product described herein; neither does it
convey any license under its patent rights ,nor the rights of others . The user of products in such applications shall assume all
risks of such use and will agree to hold
Micro Commercial Components Corp .
and all the companies whose products are
represented on our website, harmless against all damages.
***LIFE SUPPORT***
MCC's products are not authorized for use as critical components in life support devices or systems without the express written
approval of Micro Commercial Components Corporation.
***CUSTOMER AWARENESS***
Counterfeiting of semiconductor parts is a growing problem in the industry. Micro Commercial Components (MCC) is taking
strong measures to protect ourselves and our customers from the proliferation of counterfeit parts. MCC strongly encourages
customers to purchase MCC parts either directly from MCC or from Authorized MCC Distributors who are listed by country on
our web page cited
below.
Products customers buy either from MCC directly or from Authorized MCC Distributors are genuine
parts, have full traceability, meet MCC's quality standards for handling and storage.
MCC will not provide any warranty
coverage or other assistance for parts bought from Unauthorized Sources.
MCC is committed to combat this global
problem and encourage our customers to do their part in stopping this practice by buying direct or from authorized
distributors.
www.mccsemi.com
Revision: B
3 of 3
2013/01/01
