TURRET TERMINALS
STYLES
•
Single, double and triple turrets
•
Double-ended
(feed-thru)
•
Split-type
(fork)
•
Tubular
(hollow)
•
Swage and thread mounting types available
•
Bright Tin plated for extended shelf life and
excellent solderability
•
Wide variety of sizes to suit space and wire
size requirements
ORDERING INFORMATION
Keystone standardized terminals are available for various board thicknesses.
To specify a terminal, select the “CAT. NO.” and “DASHED NUMBER” that corresponds with the board
thickness to be used.
DASH NUMBERS (Board Thicknesses)
-1 for .032 (.81) thick Board
-2 for .062 (1.57) thick Board
-3 for .093 (2.36) thick Board
-4 for .125 (3.2) thick Board
Example:
1503-1 for .032 (.81) thick Board
1503-2 for .062 (1.57) thick Board
STAKING TOOLS
For easy mounting of terminals to insulators and PC boards. Standard and
“special order” staking tools are available. Cat. No.
“TL”
designates a tool
consisting of a TOP STAKING PUNCH and a BOTTOM ANVIL. Manufactured
from steel with zinc plate. Punch and anvil are precision machined and
hardened to insure long life. Refer to page 135.
SPECIFICATIONS
MATERIAL:
Brass - Per ASTM-B16, Bright Electro-Tin per MIL-T-10727 Type 1.
Other platings available upon request.
SPECIAL TERMINALS
Custom terminals can be manufactured to your specifications. Complete facilities available to meet your
production requirements. Quotations on special terminals furnished promptly upon receipt of sample,
sketch or print.
CUSTOM BUILT STAKING TOOLS
Custom prototype and production staking tools can be furnished for Single-End,
Double-End, Fork Terminals, Extruded Lugs, Eyelets, Rivets, etc. Contact our
Engineering Department for details.
CUSTOM BUILT TERMINAL BOARDS
We are specialists in the assembly of terminals, eyelets, clips and special hardware. Quotations on special
terminal boards furnished promptly upon receipt of sample, sketch or print. Assembly service using
customer supplied materials also available. (Refer to pages 130-132 for standard terminal boards.)
TURRET TERMINALS
SINGLE, DOUBLE & TRIPLE TURRET
1528
1508
1572
1520
.145 [3.7]
.234
[6.0]
1532
.040 [1.02]
.062 [1.57]
.093 [2.36]
.094 [2.39]
.063 [1.60]
.093 [2.36]
.050 [1.27]
.075 [1.90]
.125 [3.2]
.187
[4.8]
.187 [4.8]
.093 [2.36]
.104 [2.7]
L
.047 [1.19]
.062 [1.57]
L
.072 [1.83]
L
.078 [1.98]
L
.112 [2.9]
L
Staking Tool 1528-TL
CAT. NO.
L
.051 (1.30)
1528-1
1528-2
.082 (2.08)
1528-3
.113 (2.8)
1528-4
.145 (3.6)
Staking Tool No. TL-1
CAT. NO.
L
.053 (1.35)
1508-1
1508-2
.084 (2.13)
1508-3
.115 (2.9)
1508-4
.147 (3.7)
Staking Tool No.TL-1
CAT. NO.
L
.051 (1.30)
1572-1
1572-2
.082 (2.08)
1572-3
.113 (2.8)
1572-4
.145 (3.6)
Staking Tool No. TL-2
CAT. NO.
L
.078 (1.98)
1520-1
1520-2
.109 (2.8)
1520-3
.141 (3.5)
1520-4
.172 (4.4)
Staking Tool No. TL-8
CAT. NO.
L
.078 (1.98)
1532-1
1532-2
.109 (2.8)
1532-3
.141 (3.5)
1532-4
.172 (4.4)
1593
.062 [1.57]
.094 [2.39]
.156 [4.0]
.093 [2.36]
1573
.093 [2.36]
.186
[4.7]
1502
1514
1503
.109 [2.8]
.219
[5.6]
.156 [4.0]
.281
[7.2]
.145 [3.7]
.187 [4.8]
.360
[9.2]
.125 [3.2]
L
.062 [1.57]
.072 [1.83]
L
.090 [2.29]
L
.090 [2.29]
L
.112 [2.9]
L
Staking Tool No. TL-1
CAT. NO.
L
.054 (1.37)
1593-1
1593-2
.084 (2.13)
1593-3
.115 (2.9)
1593-4
.147 (3.7)
Staking Tool No. TL-1
CAT. NO.
L
.051 (1.30)
1573-1
1573-2
.082 (2.08)
1573-3
.113 (2.8)
1573-4
.145 (3.6)
Staking Tool No. TL-2
CAT. NO.
L
.078 (1.98)
1502-1
1502-2
.109 (2.8)
1502-3
.141 (3.5)
1502-4
.172 (4.4)
Staking Tool No. TL-5
CAT. NO.
L
.078 (1.98)
1514-1
1514-2
.109 (2.8)
1514-3
.141 (3.5)
1514-4
.172 (4.4)
Staking Tool No. TL-8
CAT. NO.
L
.078 (1.98)
1503-1
1503-2
.109 (2.8)
1503-3
.141 (3.5)
1503-4
.172 (4.4)
1598
1527
1563
THREADED TURRETS
1595
.043 [1.09]
DIA. THRU
.093 [2.4]
DIA.
.125 [3.2]
HEX.
4-40
THREAD
.156 [4.0]
.125 [3.2]
2-56
THREAD
1587
.093 [2.36]
.301
[7.7]
.125 [3.2]
.145 [3.7]
.484
[12.3]
.187 [4.8]
.075 [1.9]
DIA.
.187 [4.8]
.145 [3.7]
DIA.
L
.090 [2.29]
.112 [2.9]
L
.360
[9.2]
L
Staking Tool No. TL-2
CAT. NO.
L
1598-1
.062 (1.57)
1598-2
.094 (2.39)
1598-3
.125 (3.2)
1598-4
.156 (3.9)
Staking Tool No. TL-8
CAT. NO.
L
1527-1
.078 (1.98)
1527-2
.109 (2.8)
1527-3
.141 (3.5)
1527-4
.172 (4.4)
.187 [4.8]
HEX.
4-40
THREAD
L
CAT. NO. 1563
®
CAT. NO.
1595-1
1595-2
1595-3
L
.093 (2.36)
.125 (3.2)
.188 (4.8)
CAT. NO.
1587-1
1587-2
L
.125 (3.2)
.188 (4.8)
138
Tel (718) 956-8900
•
Fax (718) 956-9040
(800) 221-5510
•
kec@keyelco.com
RoHS COMPLIANT
~
ISO 9001 CERTIFIED
www.keyelco.com
31-07 20th Road – Astoria, NY 11105-2017
