MC100EPT21DR2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Drivers and interfaces> MC100EPT21DR2

MC100EPT21DR2: DescriptionPECL TO TTL TRANSLATOR, TRUE OUTPUT, PDSO8, SOIC-8; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size823KB，9 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

MC100EPT21DR2 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MC100EPT21DR2	-	-	View	Buy Now

MC100EPT21DR2 Overview

PECL TO TTL TRANSLATOR, TRUE OUTPUT, PDSO8, SOIC-8

MC100EPT21DR2 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Maker	Rochester Electronics
Parts packaging code	SOIC
package instruction	SOIC-8
Contacts	8
Reach Compliance Code	unknown
maximum delay	2.25 ns
Interface integrated circuit type	PECL TO TTL TRANSLATOR
JESD-30 code	R-PDSO-G8
JESD-609 code	e0
length	4.9 mm
Humidity sensitivity level	NOT SPECIFIED
Number of digits	1
Number of functions	1
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Output latch or register	NONE
Output polarity	TRUE
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	240
Certification status	COMMERCIAL
Maximum seat height	1.75 mm
Maximum supply voltage	3.6 V
Minimum supply voltage	3 V
Nominal supply voltage	3.3 V
surface mount	YES
technology	ECL
Temperature level	INDUSTRIAL
Terminal surface	TIN LEAD
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
width	3.9 mm
