NACP100M35V6.3X4.5TR13F: DescriptionCAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 50V, 10uF, SURFACE MOUNT, 2626, ROHS COMPLIANT; CategoryPassive components capacitor; File Size62KB，2 Pages; ManufacturerNichicon; Websitehttp://www.nichicon.co.jp; Environmental Compliance

Download Datasheet Parametric Compare View All

NACP100M35V6.3X4.5TR13F Overview

CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 50V, 10uF, SURFACE MOUNT, 2626, ROHS COMPLIANT

NACP100M35V6.3X4.5TR13F Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Nichicon
package instruction	, 2626
Reach Compliance Code	compliant
ECCN code	EAR99
capacitance	10 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
dielectric materials	ALUMINUM (WET)
ESR	19000 mΩ
JESD-609 code	e6
leakage current	0.005 mA
Manufacturer's serial number	NACP
Installation features	SURFACE MOUNT
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package shape	CYLINDRICAL PACKAGE
method of packing	TR, 13 INCH
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	50 V
ripple current	33 mA
size code	2626
surface mount	YES
Delta tangent	0.12
Terminal surface	Tin/Bismuth (Sn/Bi)
Terminal shape	FLAT

Preview

Download Datasheet

View All

Surface Mount Aluminum Electrolytic Capacitors

FEATURES

• CYLINDRICAL V-CHIP CONTRUCTION

• LOW PROFILE, 4.6mm MAXIMUM HEIGHT

• DESIGNED FOR REFLOW SOLDERING

CHARACTERISTICS

Rated Voltage Rating

Rated Capacitance Range

Operating Temperature Range

Capacitance Tolerance

Max. Leakage Current After 2 Minutes at 20°C

Surge Voltage & Max. Tanδ

Low Temperature

Stability

(Impedance Ratio @ 120Hz)

Load Life Test

at Rated W.V.

85°C 1,000 Hours

NACP Series

RoHS

Compliant

includes all homogeneous materials

4 ~ 50Vdc

0.1 ~ 220μF

-40° ~ +85°C

±20%(M)

0.01CV or 3μA, whichever is greater

W.V. (Vdc)

4

6.3

10

16

25

35

50

S.V. (Vdc)

5

8.0

13

20

32

44

63

0.40 0.30 0.24 0.20 0.16 0.14 0.12

Tanδ @ 120Hz/20°C

W.V. (Vdc)

4

6.3

10

16

25

35

50

Z-25°C/Z +20°C

7

4

3

2

Z-40°C/Z +20°C

15

10

8

6

4

Capacitance Change

Within ±25% of initial measured value

Less than 200% of speciﬁed value

Tanδ

Leakage Current

Less than speciﬁed value

STANDARD PRODUCT AND CASE SIZE Dφ xL (mm)

Cap.

(μF)

0.1

0.22

0.33

0.47

1.0

2.2

3.3

4.7

10

22

33

47

100

220

Working Voltage (Vdc)

4

-

4x4.5

5x4.5

6.3x4.5

6.3

-

4x4.5

5x4.5

-

10

-

5x4.5

16

-

4x4.5

5x4.5

25

-

4x4.5

5x4.5

35

-

4x4.5

5x4.5

-

50

4x4.5

5x4.5

6.3x4.5

-

DIMENSIONS (mm)

Case Size Dφ±0.5 L max. A/B±0.2 I ± 0.2

W

4x5.5

4.0

5.5

4.3

1.8 0.5 ~ 0.8

5x5.5

5.0

5.5

5.3

2.1 0.5 ~ 0.8

6.3x5.5

6.3

5.5

6.6

2.5 0.5 ~ 0.8

P±0.2

1.0

1.4

2.2

+

W

I

-

Dφ

A

0.3mm max.

L

6.3x4.5 6.3x4.5

-

P

B

6.3x4.5 6.3x4.5

-

6.3x4.5 6.3x4.5

-

6.3x4.5 6.3x4.5

PART NUMBER SYSTEM

NACP 470 M 16V 6.3x5.5 TR 13 F

RoHS Compliant

97% Sn (min.), 3% Bi (max.)

330mm (13”) Reel

Tape & Reel

Size in mm

Working Voltage

Tolerance Code M=20%

Capacitance Code in

μF,

ﬁrst 2 digits are signiﬁcant

Third digit is no. of zeros, “R” indicates decimal for

values under 10μF

Series

Please review the notes on correct use, safety and precautions found on

pages T10

&

T11

of NIC’s

Electrolytic Capacitor catalog.

Also found at

www.niccomp.com/precautions

If in doubt or uncertainty, please review your speciﬁc application - process details with

NIC’s technical support personnel:

tpmg@niccomp.com

PRECAUTIONS

10

NIC COMPONENTS CORP.

www.niccomp.com

www.lowESR.com

www.RFpassives.com

www.SMTmagnetics.com
