MR2400 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> MR2400

MR2400: Description24 A, 50 V, SILICON, RECTIFIER DIODE; CategoryDiscrete semiconductor diode; File Size439KB，4 Pages; ManufacturerDigitron; Websitehttp://www.digitroncorp.com

Download Datasheet Parametric Compare View All

MR2400 Overview

24 A, 50 V, SILICON, RECTIFIER DIODE

MR2400 Parametric

Parameter Name	Attribute value
Maker	Digitron
Reach Compliance Code	unknow

Preview

Download Datasheet

View All

DIGITRON SEMICONDUCTORS

MR2400-MR2410

RECOVERY RECTIFIER

24 AMP, 50-1000V

MAXIMUM RATINGS

Operating & Storage Temperature

Maximum Thermal Resistance

Type

MR2400

MR2401

MR2402

MR2404

MR2406

MR2408

MR2410

Maximum Recurrent

Peak Reverse Voltage

50V

100V

200V

400V

600V

800V

1000V

-65°C to +150°C

10°C/W Junction to Ambient

Maximum RMS Voltage

35V

70V

140V

280V

420V

560V

700V

Maximum DC Blocking

Voltage

50V

100V

200V

400V

600V

800V

1000V

ELECTRICAL CHARACTERISTICS (@ 25°C unless otherwise specified)

Parameter

Average Forward Current

Peak Forward Surge Current

Maximum Instantaneous Forward Voltage

Maximum DC Reverse Current At Rated DC

Blocking Voltage

Typical Junction Capacitance

*Pulse Test: Pulse width 300

μsec,

Duty cycle 1%

Symbol

F(AV)

FSM

Value

24A

400A

1.18V

100μA

200pF

Test Conditions

= 150°C

8.3ms, half sine

= 24.0A

= 25°C*

= 25°C

Measure at 1.0MHz,

= 4.0V

144 Market Street

Kenilworth NJ 07033 USA

phone +1.908.245-7200

fax +1.908.245-0555

sales@digitroncorp.com

www.digitroncorp.com

Rev. 20121127
