DIGITRON SEMICONDUCTORS
TVS305-TVS430
TVS505-TVS528
MAXIMUM RATINGS
Ratings
Stand off voltage, V
R
Peak pulse power (1ms)
Forward surge current (8.3ms half-sine wave)
Power, continuous
Storage and operating temperature
TVS305-TVS430
5 to 300V
150W
15A
3W
-65 to +175°
TVS505-TVS528
5 to 28V
500W
50A
5W
TRANSIENT VOLTAGE SUPPRESSORS
ELECTRICAL CHARACTERISTICS
Stand-off
voltage
V
R
V
TVS305
TVS310
TVS312
TVS315
TVS318
TVS324
TVS328
TVS348
TVS360
TVS410
TVS420
TVS430
TVS505
TVS510
TVS512
TVS515
TVS518
TVS524
TVS528
5.0
10.0
12
15
18
24
28
48
60
100
200
300
5.0
10.0
12.0
15.0
18.0
24.0
28.0
Minimum
breakdown
voltage
V
BR(min)
@
1mA
V
6.0
11.1
13.8
16.7
20.4
28.4
30.7
54
67
111
234
342
6.0
11.1
13.8
16.7
20.4
28.4
30.7
Maximum
leakage
current
I
R
@ V
R
µA
50
2
1
1
1
1
1
1
1
1
1
1
300
5
5
5
5
5
5
Maximum
peak pulse
current
I
PP
A
17
8.9
7.1
5.9
4.9
3.6
3.2
1.7
1.4
.91
.42
.28
53.7
30.3
23.8
19.8
16.3
11.9
10.7
Maximum
clamping
voltage
V
C
@ I
PP
V
8.7
16.8
21.0
25
31
42
46
82
105
160
360
520
9.3
16.5
21.0
25.2
30.5
42.0
46.5
Maximum
clamping
voltage
V
C
@ 1A
V
-
-
-
-
-
-
-
-
-
-
-
-
7.4
13.2
16.5
19.7
23.8
32.4
35.9
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
26.0
37.0
41.0
Maximum
clamping
voltage
V
C
@
5A
V
-
-
-
-
-
-
-
-
-
-
-
-
7.9
14.4
18.5
22.2
-
-
-
10A
Part number
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20120926
