DIGITRON SEMICONDUCTORS
UZ8706, UZ8806 SERIES
POWER ZENERS
Available Non-RoHS (standard) or RoHS compliant (add PBF suffix).
Available as “HR” (high reliability) screened per MIL-PRF-19500, JANTX level. Add “HR” suffix to base part number.
MAXIMUM RATING
Zener Voltage (V
Z
):
Continuous Current:
Surge Current ( 8.3 ms):
Surge Power:
Power:
Storage and Operating Temperature:
6.8 to 200V
See Table
See Table
See Graph
See Lead Temperature Derating Curve
-65°C to +175°C
ELECTRICAL CHARACTERISTICS
Electrical Specifications at 25°C
Nominal
Zener
Voltage
†
V
Z
@ I
ZT
+5%
Tolerance
UZ8706
UZ8707
UZ8708
UZ8709
UZ8710
UZ8712
UZ8713
UZ8714
UZ8715
UZ8716
UZ8718
UZ8720
UZ8722
UZ8724
UZ8727
UZ8730
UZ8733
UZ8736
UZ8740
UZ8745
UZ8750
UZ8756
UZ8760
UZ8770
UZ8775
UZ8780
UZ8790
UZ8110
UZ8111
UZ8112
UZ8113
UZ8114
+10%
Tolerance
UZ8806
UZ8807
UZ8808
UZ8809
UZ8810
UZ8812
UZ8813
UZ8814
UZ8815
UZ8816
UZ8818
UZ8820
UZ8822
UZ8824
UZ8827
UZ8830
UZ8833
UZ8836
UZ8840
UZ8845
UZ8850
UZ8856
UZ8860
UZ8870
UZ8875
UZ8880
UZ8890
UZ8210
UZ8211
UZ8212
UZ8213
UZ8214
Volts
6.8
7.5
8.2
9.1
10
12
13
14
15
16
18
20
22
24
27
30
33
36
40
45
50
56
60
70
75
80
90
100
110
120
130
140
Max. Zener
Impedance
§
Z
Z
@ I
ZT
Ohms
3.5
4.0
4.5
5.0
7.0
9.0
10
12
14
16
20
22
23
25
35
40
45
50
62
75
85
110
125
150
175
200
250
350
450
550
700
850
Maximum Reverse
Leakage Current
I
R
@ V
R
μA
50
30
10
3.0
2.0
1.0
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
+5%
V
R
Volts
5.2
5.7
6.2
6.9
7.6
9.1
9.9
10.6
11.4
12.1
13.7
15.2
16.7
18.2
20.5
22.8
25.1
27.3
30.4
34.2
38.0
42.5
45.6
53.2
57.0
60.8
68.4
76.0
83.6
91.2
98.8
106
+10%
V
R
Volts
4.9
5.4
5.9
6.6
7.2
8.6
9.3
10.1
10.8
11.5
12.9
14.4
15.8
17.3
19.4
21.6
23.7
25.9
28.8
32.4
36.0
40.3
43.2
50.4
54.0
57.6
64.8
72.0
79.2
86.4
93.6
100
Typ. Temp.
Coeff.
T.C. @ I
ZT
Maximum Ratings
Maximum
Continuous
Current
I
ZM
mA
140
125
115
105
95
85
80
74
63
60
52
47
43
40
35
31
28
26
24
22
20
17
15
14
12
11
10
9.5
8.5
8.0
7.2
6.8
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20120730
Type
Test
Current
I
ZT
mA
37
34
31
28
25
23
21
19
17
15.5
14.0
12.5
11.5
10.5
9.5
8.5
7.5
7.0
6.5
6.0
5.0
4.5
4.0
3.7
3.3
3.0
2.8
2.5
2.3
2.0
1.9
1.8
Maximum
Surge
Current
‡
I
S
Amps
5.00
4.50
3.90
3.37
2.77
2.25
2.25
2.25
1.65
1.65
1.12
1.12
1.12
0.825
0.825
0.825
0.675
0.562
0.562
0.450
0.450
0.390
0.337
0.337
0.277
0.225
0.225
0.225
0.165
0.112
0.112
0.112
%/°C
0.04
0.04
0.05
0.05
0.06
0.07
0.07
0.07
0.07
0.07
0.08
0.08
0.08
0.08
0.09
0.09
0.09
0.09
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
.10
.10
.10
.10
.10
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
DIGITRON SEMICONDUCTORS
UZ8706, UZ8806 SERIES
ELECTRICAL CHARACTERISTICS
Electrical Specifications at 25°C
Nominal
Zener
Voltage
†
V
Z
@ I
ZT
Volts
150
160
170
180
190
200
Max. Zener
Impedance
§
Z
Z
@ I
ZT
Ohms
1000
1100
1200
1300
1400
1500
Maximum Reverse
Leakage Current
I
R
@ V
R
μA
0.5
0.5
0.5
0.5
0.5
0.5
+5%
V
R
Volts
114
121
129
137
144
152
+10%
V
R
Volts
108
115
122
129
137
144
Typ. Temp.
Coeff.
T.C. @ I
ZT
Maximum Ratings
Maximum
Continuous
Current
I
ZM
mA
6.3
5.9
5.6
5.2
5.0
4.7
Maximum
Surge
Current
‡
I
S
Amps
0.112
0.082
0.082
0.056
0.056
0.056
POWER ZENERS
1 WATT
Type
Test
Current
I
ZT
mA
1.7
1.6
1.5
1.4
1.3
1.2
+5%
Tolerance
UZ8115
UZ8116
UZ8117
UZ8118
UZ8119
UZ8120
+10%
Tolerance
UZ8215
UZ8216
UZ8217
UZ8218
UZ8219
UZ8220
%/°C
.10
.10
.10
.10
.10
.10
† All zener voltages are measured with an automated test set using a 35 millisecond test time. Longer or shorter test times will have a corresponding effect on the measured value
due to heating effects.
§ Zener impedance is derived from the 60 cycle AC voltage created when AC current with RMS value of 10% of DC zener test current is superimposed on the test current.
Ratings are based on free air. T
A
= 25°C. For use at 1.5 watts, see derating curve.
‡ Figures shown are for a peak sinusoidal surge current of 8.3ms duration using 60 cycle AC. The 8.3 ms square pulse rating is 71% of the value shown.
MECHANICAL CHARACTERISTICS
Case:
Marking:
Polarity:
Glass
Body Painted, Alpha-Numeric
Cathode Band
Dimensions
Inches
Min
BD
BL
LD
LL
-
-
.027
.700
Max
.095
0.185
.033
-
Millimeters
Min
-
-
0.686
17.78
Max
2.413
4.699
0.838
-
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20120730
